Thermostat 553
Quick Setup Guide
Exterior
Wall
Thermostat
Base
1
3
(83 mm)
Behind
Door
Stud
/
"
4
Gang
Box
1 of 4
Zoning
Interior
Wall
5 feet
1.5 m
Thermostat
Base
© 2013
553 _ Q
04/13
Replaces: New
Stud
Wall
553_Q - 04/13
Advertisement
Related Manuals for Watts Industries Tekmar tekmarNet 553
Summary of Contents for Watts Industries Tekmar tekmarNet 553
- Page 1 553 _ Q 04/13 ® tekmarNet Thermostat 553 Zoning Replaces: New Quick Setup Guide Location Interior Wall Behind Door 5 feet 1.5 m Exterior Wall Remove Mounting Base Install Mounting Base Stud Thermostat Thermostat Base Base Stud ” (83 mm) Wall Gang A Watts Water Technologies Company...
- Page 2 Switch Settings Switch Position Action LOCK Access level adjustment is not available. tekmarNet Switch Thermostat 553 Settings Two Stage Heat, One Stage Cool, Fan UNLOCK Access level www.tekmarcontrols.com adjustment is available. Back of Thermostat Wiring tekmarNet ® 4 Wiring Example See 553_A for complete wiring details.
- Page 3 Install the Thermostat Thermostat Base Thermostat Front Push User Interface Display Humidity, Heat & Adjust Cool settings, Floor or the Time Outdoor temperature Adjust the Schedule Room Temperature Away Key Turn the Fan on Switch between Auto, Heat, Cool, Off & Return to the Emergency Mode ‘Home’...
- Page 4 Critical Settings The following settings are essential to the successful operation of the system. Step 1: Set switch setting #1 and tekmarNet ® system control located in the mechanical room to Unlock to change Access level to Installer. Return to Lock setting once installation has been completed.
