- Page 1 ASSEMBLY INSTRUCTIONS HZDQ TLCFLS-5004 TLCFLS-5005 CEI L IN G FAN WI T H LI GHT...
- Page 2 ASSEMBLY INSTRUCTIONS Thank you for selecting this product. Before use,please carefully read this operation manual to understand the correct use of this product. Special attention should be paid to important safety warnings and the operation manual should be kept for reference.Note : our company reser ves the right to improve the product and instructions contained therein which may be changed without notice.
-
Page 3: Safety Guidelines
ASSEMBLY INSTRUCTIONS SAFETY GUIDELINES 1. To avoid possible electric shock , turn off the electricity in the main fuse box or on the circuit panel before you begin the fan installation, maintain the fan or install any accessories. 2. Read all instructions and safety guidelines carefully before installing your fan and follow all the instructions. -
Page 4: Product Instruction
ASSEMBLY INSTRUCTIONS BEFORE YOU START Tools and Materials Required are not good at performing electrical work. It’ s the licensed electrician who installs the fan, if required by the local code. Do not use the fan with a dimmer switch. Turn o External Hexagonal Wire Stripper Phillips... -
Page 5: Installing The Fan
ASSEMBLY INSTRUCTIONS INSTALLING THE FAN Tools required: phillips screwdriver, a pair of pliers, straight slot screwdriver, adjustable wrench, step ladder, and wire cutters. INSTALLING THE MOUNTING BRACKET The ceiling fan must be installed in the location where there is 12"(300mm) spacing from the tips of all blades to the nearest objects or walls. - Page 6 ASSEMBLY INSTRUCTIONS 3.For concrete ceiling, drill two holes in the ceiling and secure the mounting bracket to the ceiling with two 0.32"(8mm) (distance between the two holes should be appropriate) expansion screws, flat washers nuts provided and tighten with a spanner. (Expansion screws are not included in the screw package and need to be purchased separately) 4.
-
Page 7: Make The Electric Connections
ASSEMBLY INSTRUCTIONS MAKE THE ELECTRIC CONNECTIONS WARNING: To avoid possible electrical shock , be sure the electricity is turned off in the main fuse box before wiring. 1.Attaching the safety rope to the hook of the Hanging Bracket makes it easier to connect the wire and install the motor 2.Connect the fan to the remote control. - Page 8 ASSEMBLY INSTRUCTIONS HANG THE MAINFRAME ON THE CEILING 1.The connected receiver and wire are placed in the space between the host and the Hanging Bracket 2.Lift the main engine and clamp it into the original removed screws, turn the main engine so that it will not fall, and then screw the two removed screws back and lock it.
-
Page 9: Installing The Blade
ASSEMBLY INSTRUCTIONS INSTALLING THE BLADE Step 1. Remove the three rubber fastening pieces Step 2. Place the blades on the fan motor assembly and align the two holes Step 3. Making sure the blade is straight, attach 2 blade bolts. Step 4. - Page 10 ASSEMBLY INSTRUCTIONS LAMP SHADE MOUNTING Carefully install the lamp shade into the main body and turn clockwise to lock. Installation is now finished. Turn on the power . Then the fan lights are on. Test and pair your fan immediately using the remote control.
-
Page 11: Remote Control Setting And Operation
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS REMOTE CONTROL SETTING AND OPERATION 1. Restore electricity to the outlet box by turning the electricity on at the main fuse box. 2. Remove the batter y cover from the remote control transmitter, install the batter y, and replace the cover. Note: 1). -
Page 12: Maintenance And Cleaning
ASSEMBLY INSTRUCTIONS HOW TO USE BALANCING KITS NOTE: ceiling fans tend to move during operation due to the fact that they are mounted on a Sponge cushion. if the fan was mounted rigidly to the ceiling, it would cause excess vibration, movement of a few centimeters is quite acceptable and does not suggest any problems TO REDUCE FAN WOBBLE: PLEASE CHECK THAT ALL SCREWS WHICH SECURE THE MOUNTING BRACKET... -
Page 13: Troubleshooting
ASSEMBLY INSTRUCTIONS TROUBLESHOOTING Your fan may occasionally jerk for ward or backward upon starting up. This is normal and does not affect the fan operation. Tr y these troubleshooting steps before contacting customer ser vice. SYMPTOM POSSIBLE SOLUTIONS 2. Check the functionality of circuit breaker or fuse panel and wall switch. The fan 3.
