Seiko KINETIC 7L22 Instructions Manual

Seiko KINETIC 7L22 Instructions Manual

Analogue quartz watch
Hide thumbs

Advertisement

Table of Contents

Cal. 7L22
INSTRUCTIONS
BEDIENUNGSANLEITUNG
INSTRUCTIONS
ISTRUZIONI
INSTRUCCIONES
INSTRUÇÕES
(P.
3)
(S. 16)
(P.
29)
(P.
42)
(P.
57)
(P.
70)
(83
)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KINETIC 7L22 and is the answer not in the manual?

Questions and answers

Related Manuals for Seiko KINETIC 7L22

Summary of Contents for Seiko KINETIC 7L22

  • Page 1 Cal. 7L22 INSTRUCTIONS BEDIENUNGSANLEITUNG (S. 16) INSTRUCTIONS ISTRUZIONI INSTRUCCIONES INSTRUÇÕES...
  • Page 2 Tenere poi il manuale a portata di mano, per ogni eventuale futura, ulteriore consultazione. ® Usted es ahora un orgulloso propietario de un Reloj SEIKO KINETIC Cal. 7L22. Para los mejores resultados, por favor lea las instruciones de este librito cuidadosamente antes de utilizar su Reloj ®...

  • Page 3: Table Of Contents

    CONTENTS Page FEATURES ........................HOW TO CHARGE AND START THE WATCH ............POWER RESERVE IN YOUR SEIKO KINETIC WATCH ..........REMARKS ON THE KINETIC E.S.U................ENERGY DEPLETION FOREWARNING FUNCTION ........... TIME/CALENDAR SETTING ..................FOR MODELS WITH SCREW LOCK TYPE CROWN ..........

  • Page 4: Features

    FEATURES SEIKO KINETIC Cal. 7L22 is an analogue quartz watch equipped with an Automatic Generating System developed by SEIKO. It generates the electric energy to power the watch, utilizing the movement of the arm, and stores it in the KINETIC ELECTRICITY STORAGE UNIT (KINETIC E.S.U.), which requires no periodical replacement unlike...

  • Page 5: Power Reserve In Your Seiko Kinetic Watch

    POWER RESERVE IN YOUR SEIKO KINETIC WATCH The electric energy generated while the watch is worn on your wrist is stored in the KINETIC ELECTRICITY STORAGE UNIT (KINETIC E.S.U.). It is a power source completely different from conventional batteries for watches, and therefore, does not require any periodical replacement.

  • Page 6: Remarks On The Kinetic E.s.u

    REMARKS ON THE KINETIC E.S.U. Do not pull the crown out to the second click with the intention of stopping the second hand just to save energy. By doing so, a large amount of current flows through the built-in IC. Therefore, pulling out the crown to the second click will not save energy but, in fact, consume more energy than usual.

  • Page 7: Time/Calendar Setting

    TIME/CALENDAR SETTING Second hand 1. Pull out the crown to the first click and turn it counterclockwise to set the previous day’s date. 2. Pull out the crown to the second click when the second hand is at the 12 o’clock position, and advance the hands by turning the crown counterclockwise to set the desired date.

  • Page 8: Stopwatch

    STOPWATCH The stopwatch can measure up to 45 minutes in 1/5 second increments. The measured time is indicated by two STOPWATCH hands that move independently of the hands for time indication. After 48 minutes, the stopwatch will stop automatically. TIPS ON READING THE HANDS The STOPWATCH second hand turns a full circle in 60 seconds.
  • Page 9 Ex. ) 9 minutes 58 seconds Be careful not to misread 9 minutes 58 seconds as 10 minutes 58 seconds even if the STOPWATCH minute hand is close to the 10 minutes position. STOPWATCH second hand reading: STOPWATCH minute hand reading: The STOPWATCH second hand almost The STOPWATCH minute hand almost points to “58”.
  • Page 10 STOPWATCH OPERATION Before using the stopwatch, be sure to reset the STOPWATCH hands to “0” position. 1) Check that the watch is operating normally. * If the watch has stopped completely or if the second hand is moving at two-second intervals, charge the watch sufficiently.

  • Page 11: Tachymeter

    TACHYMETER (for models with tachymeter scale) To measure the hourly average speed of a vehicle U s e t h e s t o p w a t c h t o Ex. 1 d e t e r m i n e h o w m a n y seconds it takes to go 1 km or STOPWATCH 1 mile.
  • Page 12 To measure the hourly rate of operation Ex. 1 U s e t h e s t o p w a t c h t o measure the time required to complete 1 job. STOPWATCH second hand: Tachymeter scale indicated 20 seconds by STOPWATCH second hand gives the average...

  • Page 13: Notes For Using The Watch

    Wear the watch daily for at least 10 hours. Even if the watch is worn on your arm, it will not be charged while your arm is not in motion. POWER RESERVE IN YOUR SEIKO KINETIC WATCH Precaution on see-through case-back models:...
  • Page 14 TIME/CALENDAR SETTING Do not set the date between 9:00 p.m. and 1:00 a.m. Otherwise, it may not change properly. If it is necessary to set the date during that time period, pull out the crown to the second click and turn it counterclockwise to advance the time ahead of 1:00 a.m., and push the crown to the first click to set the date and then reset the correct time.

  • Page 15: Specifications

    SPECIFICATIONS Frequency of crystal oscillator ......32,768 Hz (Hz = Hertz … Cycles per second) Loss/gain (monthly rate) ........Less than 15 seconds (worn on the wrist at normal temperature range 5° C ~ 35° C) (41° F ~ 95° F) Operational temperature range ......
