Seiko 7D Series Technical Instruction

No. PROSESS
Assembling the
switching unit
<91> Set the main plate.
91 Set the main plate.
↓
Set the lead pin for
90
RZ1.
↓
<86> Set the rechargeable battery
Set the hour and
89
connection (+).
minute stator.
↓
Set the second
88
<87> Set the generating stator.
stator.
*Distinction from the 5J-series
↓
counterpart
Set the generating
87
See the red-circled parts, which
stator.
are shaped to identify the
↓
7J-series generating stator.
Set the
rechargeable
86
battery connection
(+).
↓
st
Set the 1
intermediate wheel
*When mounting, take care not to
85
for calendar
distort or deform the generating
corrector.
stator. (To prevent deterioration
↓
of electric power generation)
Set the clutch
84
wheel.
7 D * * T e c h n i c a l I n s t r u c t i o n
No.1
ILLUSTRATIONS AND SPECIAL INSTRUCTIONS
<88> Set the second stator.
* When mounting, take care not to distort
or deform the second stator.
(To prevent deterioration of the motor)
<89> Set the hour and minute
stator.
* When mounting, take care not to
distort or deform the hour and
minute stator.
(To prevent deterioration of the
motor.)
<84> Set the clutch wheel.
<85> Set the 1st intermediate wheel
for calendar corrector.
<90> Set the lead pin for RZ1.
*Ensure that the lead pin for RZ1 is tightly
mounted without any clearance.
