R32
INSTALLATION MANUAL
AIR CONDITIONER (SPLIT TYPE)
Scan QR CODE to access installation and owner's manual on website.
https://www.toshiba-carrier.co.th/manuals/default.aspx
Manual are available in EN/IT.
Indoor unit
RAS-B05, 07, 10, 13, 16, 18S4KVG-E
Outdoor unit
RAS-05, 07, 10, 13, 16, 18E2AVG-E
1144180142
Advertisement
Table of Contents
Related Manuals for Toshiba RAS-B05S4KVG-E
Summary of Contents for Toshiba RAS-B05S4KVG-E
- Page 1 INSTALLATION MANUAL AIR CONDITIONER (SPLIT TYPE) Scan QR CODE to access installation and owner’s manual on website. https://www.toshiba-carrier.co.th/manuals/default.aspx Manual are available in EN/IT. Indoor unit RAS-B05, 07, 10, 13, 16, 18S4KVG-E Outdoor unit RAS-05, 07, 10, 13, 16, 18E2AVG-E 1144180142...
-
Page 2: Accessory Parts
ACCESSORY PARTS ACCESSORY PARTS Indoor Unit Part name Part name Installation plate × 1 Wireless remote controller × 1 Battery × 2 Remote controller holder × 1 Ultra Fresh filter × 1 Mounting screw × 6 Flat head wood screw × 2 Owner’s Manual ×... -
Page 3: Installation Diagram Of Indoor And Outdoor Units
INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR UNITS INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR UNITS RAS-B05, 07,10S4KVG-E RAS-B13, 16,18S4KVG-E For the rear left, bottom left and left piping Wall Hook Installation plate Cut out a piece of SPACER from indoor unit packaging box, roll it and insert between the indoor unit and wall to Flat head wood screw... -
Page 4: Indoor Unit
INDOOR UNIT INDOOR UNIT Mounting the installation plate Installation Place (Unit : mm) • A place which provides the spaces around the indoor unit as shown in the diagram Hook • A place where there are no obstacles near the air inlet and outlet •... -
Page 5: How To Connect Remote Controller For Wire Operation
When the installation plate is directly mounted How to Connect Remote Controller on the wall for Wire Operation 1. Securely fit the installation plate onto the wall by screwing it in the upper and lower parts to hook up the indoor unit. 2. -
Page 6: Piping And Drain Hose Installation
*Remark : 1. Recommend to use double insulation lead wire for connect For remote controller remote controller and air conditioner. 2. For wire operation, 1 remote controller can control only 1. Remove cover of remote controller by sliding down and take it out. 1 indoor unit. -
Page 7: Indoor Unit Fixing
In case of right or left piping Indoor Unit Fixing • After scribing slits inside of the front panel with a knife or a 1. Pass the pipe through the hole in the wall and hook the indoor unit on the making-off pin, cut them with a pair installation plate at the upper hook. -
Page 8: Outdoor Unit
OUTDOOR UNIT OUTDOOR UNIT Installation Place CAUTION 1. Install the outdoor unit without anything blocking the air discharging. • A place which provides the spaces around the outdoor unit as shown in 2. When the outdoor unit is installed in a place always exposed to strong the diagram. - Page 9 Evacuating CAUTION • Do not scratch the inner surface of the flared part when removing After the piping has been connected to the indoor unit, you can perform the burrs. air purge together at once. • Flare processing under the condition of scratches on the inner surface of flare processing part will cause refrigerant gas leak.
- Page 10 Packed valve handling precautions • Open the valve stem all the way out, but do not try to open it beyond the stopper. Pipe size of Packed Valve Size of Hexagon wrench 12.70 mm and smallers A = 4 mm 15.88 mm A = 5 mm Pump down process...
-
Page 11: Electrical Works
ELECTRICAL WORKS ELECTRICAL WORKS Model RAS-B05S4KVG-E RAS-B07S4KVG-E RAS-B10S4KVG-E RAS-B13S4KVG-E RAS-B16S4KVG-E RAS-B18S4KVG-E Power source 50Hz, 220 – 240V Single phase Maximum running current 5.0A 5.4A 7.2A 7.4A 9.0A 9.25A Circuit breaker rating Power supply cable H07RN-F or 60245 H07RN-F or 60245 IEC66 H07RN-F or 60245 IEC66 (1.25 mm... - Page 12 In Case of Indoor Unit Connect With 1:1 Outdoor Unit Power Supply Input at Outdoor Unit Terminal Block (Recommend) Indoor Unit Outdoor Unit Stripping length of the Connecting cable Connecting cable 1 2 3 connect to 1 2 3 connecting cable Earth line Terminal block 50 mm...
- Page 13 Power supply input Wiring Diagram for 1:1 Outdoor Unit Power input at Outdoor Terminal Block (Recommend) Indoor Terminal Block Outdoor Terminal Block Power input Power input at Indoor Terminal Block (Optional) Indoor Terminal Block Power input Outdoor Terminal Block CAUTION 1.
- Page 14 In Case of Indoor Unit Connect With Inverter Multi System (IMS) Indoor Unit Stripping length of the Connecting cable Connecting cable connect to 1 2 3 Connecting cable Terminal block Earth line 50 mm 10 mm 10 mm Earth line 70 mm Connecting cable...
-
Page 15: Gas Leak Test
OTHERS OTHERS Gas Leak Test Test Operation To switch the TEST RUN (COOL) mode, press [RESET] button for 10 seconds. (The beeper will make a short beep.) Check places for the indoor unit. OPERATION / RESET Button Check places for the outdoor unit. - Page 20 1144180142...
