OSP furniture 519117HC Operating Instructions

FAUTEUIL DE DIRECTION AVEC DOSSIER EN
MAILLE ET SIÈGE EN CUIR RECONSTITUÉ
ÉTAPE 1 ÉTAPE 2
3
7R
1
2
ÉTAPE 4 ÉTAPE 5
8
4
11
6
Enlever toutes les pièces du carton, les organiser selon les numéros de pièce indiqués sur la liste et vous assurer que les quantités
des pièces sont correctes.
ÉTAPE 1 Insérer cinq roulettes (2) dans la Base (1), les pousser très fort jusqu'à ce que vous entendiez ou sentiez la roulette (2) s'enclencher.
Insérer le vérin pneumatique (3) dans la base (1).
ÉTAPE 2 Fixer les bras (7L et 7R) au Coussin du siège (5) avec trois vis longues (10) pour chaque bras (7). RESSERRER COMPLÈTEMENT
TOUTES LES VIS AVEC CLÉ ALLEN (12).
ÉTAPE 3 Fixer la plaque du siège (4) au coussin du siège (5) avec la flèche vers l'avant du siège avec quatre vis moyennes (9). RESSERRER
COMPLÈTEMENT TOUTES LES VIS AVEC CLÉ ALLEN (12).
ÉTAPE 4 Fixer le support du dossier (11) à l'arrière du plaque du siège (4) à l'aide quatre vis courtes (8). RESSERRER COMPLÈTEMENT
TOUTES LES VIS AVEC CLÉ ALLEN (12).
ÉTAPE 5 Placer le siège assemblé sur le vérin pneumatique (3) et mettre de la pression vers le bas.
ATTENTION : AVANT D'UTILISER LE FAUTEUIL, VOUS ASSURER D'AVOIR RESSERRÉ COMPLÈTEMENT TOUTES LES VIS.
519117HC / 519117MC
ISNTRUCTIONS DE MONTAGE
ÉTAPE 3
10
9
5
5
7L
PIÈCE
1. Base . . . . . . . . . . . . . . . . . . . . . . . 1
2. Roulettes . . . . . . . . . . . . . . . . . . . . 5
3. Vérin pneumatique . . . . . . . . . . . . 1
4. Plaque du siège . . . . . . . . . . . . . . . 1
5. Coussin du siège . . . . . . . . . . . . . . 1
6. Coussin du dossier . . . . . . . . . . . . 1
7. Bras (7L et 7R) . . . . . . . . . . . . . . . 2
8. Vis courte . . . . . . . . . . . . . . . . . . . . 3
9. Vis moyen . . . . . . . . . . . . . . . . . . . 4
10. Vis longue . . . . . . . . . . . . . . . . . . 6
11. Support du dossier (préinstallé) . . 1
12. Clé Allen (non montré) . . . . . . . . . 1
3
4
519117MC
QTÉ
