- Page 1 Space Saver Installation, commissioning and user manual SS2E | SS3E | SS80E Issue 002 | May 2025 ENGLISH | UK | IRL | SmithsEP.co.uk Issue 02 - May 2025 | SmithsEP.co.uk | 1...
-
Page 2: Table Of Contents
Contents Introduction Introduction The following items are included in the carton: Declaration of conformity • Product complete with grille and pre-wired Symbols used in this guide mains cable Important safety and installation instructions 3/4 • Fixing screws (2) Application • Wireless controller Product Information Accessory grilles are available in different colours and finishes. -
Page 3: Symbols Used In This Guide
Symbols This manual contains information and prescriptions marked by the following symbols: Ignoring these safety High temperature Ignoring these safety provisions marked by surface. provisions marked by the symbol “caution: Take utmost care the symbol “caution: electricity” may to prevent people hazard”... -
Page 4: Application
Important safety and installation instructions Prior to installation, read these installation and operating instructions. The installation and operation should also be in accordance with national regulations and accepted codes of good practice. 6. Electrical connection IMPORTANT: Connection to the power supply is by means of a power cable which can be fitted with a plug-type connection or a two pole isolating switch with a minimum contact opening of 3 mm. -
Page 5: Product Information
Product dimensions and performance SS2E SS80E Plug Plug Heat output Heat output Power Power Heat Output Fused Mains Cable Heat Output Fused Mains Cable Consumption Consumption (kW) spur (kW) spur (kW) (kW) 1kW/2kW 1kW/2kW 0.6kW/1.2kW 0.6kW/1.2kW Voltage: 230V SS3E WALL CONTROLLER Mains cable PROG MODE... -
Page 6: Installation - Heater
Installation - Heater 2. Electrical connection - Heater 1. Cut the opening in the plinth • Isolate the electrical supply and connect the heater electric cable to the fused spur • To ensure adequate airflow, a minimum • The fused spur must not be directly above the clearance of 20mm (10mm for SS80E product) heater, but should be accessible after between the top of the product and any... -
Page 7: Installation - Controller
5. Overlay grille (optional) • Maximum Temperature Setting This can be set to limit the maximum temperature set by the user. • Open Window Detect Will switch off the heating to limit the loss of energy when it detects a sudden temperature drop as a result of an open window or door, switching back on when it detects it has been closed again. -
Page 8: Pairing - Controller With Heaters
HHPS01 Wireless Controller – Quick Set Up 1. Ensure the heater is installed and connected to the mains power supply. DO NOT TURN THE MAINS POWER ON AT THE WALL UNTIL ASKED IN THE INSTRUCTIONS BELOW. 2. Unpackage the controller and install the batteries. - Page 9 5. To set the required thermostat temperature press the TEMP button to bring up the adjustment icon on the screen. Use the + and – buttons to select the required temperature. The radiator symbol will appear when heating is demanded. 6.
-
Page 10: Commissioning
Commissioning SS2E SS3E 1. Before switching the heater on, please ensure 1. Before switching the heater on, please ensure the fascia grille is free from obstruction the fascia grille is free from obstruction 2. Ensure your fused spur is switched ON 2. - Page 11 SS80E 1. Before switching the heater on, please ensure the fascia grille is free from obstruction 2. Ensure your fused spur is switched ON 3. Ensure the heater is paired with the wireless controller 4. Ensure the controller is switched on and calling for heat 5.
-
Page 12: Fault Finding
Commissioning - see page 10 Fault finding In the event of any difficulty, please contact us on +44 (0) 1245 324560. Fault Checking/Solution Check the power supply is switched ON Check fuse in fused spur Check the fan switch is set to ON Fan does not run/no heat output Check the battery in the controller and replace if necessary Check the wireless controller thermostat is calling for heat... -
Page 13: User Manual
Space Saver User manual SS2E | SS3E | SS80E Issue 002 | May 2025 ENGLISH | UK | IRL | SmithsEP.co.uk Issue 02 - May 2025 | SmithsEP.co.uk | 13... -
Page 14: Important Safety Guidance
Important safety and installation instructions Please read this user manual before operating this appliance. The operation should also be in accordance with national regulations and accepted codes of good practice. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. -
Page 15: Introduction
How it works - Heater • Open Window Detect Will switch off the heating to limit the loss of energy when it detects a sudden temperature Cooler air is drawn in by the fan and heated as it drop as a result of an open window or door, passes through the heating element before being switching back on when it detects it has discharged gently back into the room. -
Page 16: How To Operate
How to operate SS2E Manual Mode Boost Mode 1. Ensure your fused spur is switched ON 1. Ensure your fused spur is switched ON 2. Ensure the wireless controller is ON, and 2. Ensure the wireless controller is ON, and paired paired 3. -
Page 17: Frost Protect Mode
SS2E Frost Protect Mode Auto Mode 1. Ensure your fused spur is switched ON 1. Ensure your fused spur is switched ON 2. Ensure the wireless controller is ON, and 2. Ensure the wireless controller is ON, and paired paired 3. - Page 18 How to operate SS3E Manual Mode Boost Mode 1. Ensure your fused spur is switched ON 1. Ensure your fused spur is switched ON 2. Ensure the wireless controller is ON, and 2. Ensure the wireless controller is ON, and paired paired 3.
- Page 19 SS3E Frost Protect Mode Auto Mode 1. Ensure your fused spur is switched ON. 1. Ensure your fused spur is switched ON 2. Ensure the wireless controller is ON, and 2. Ensure the wireless controller is ON, and paired paired 3.
- Page 20 How to operate SS80E Manual Mode Boost Mode 1. Ensure your fused spur is switched ON 1. Ensure your fused spur is switched ON 2. Ensure the wireless controller is ON, and 2. Ensure the wireless controller is ON, and paired paired 3.
- Page 21 SS80E Frost Protect Mode Auto Mode 1. Ensure your fused spur is switched ON 1. Ensure your fused spur is switched ON 2. Ensure the wireless controller is ON, and 2. Ensure the wireless controller is ON, and paired paired 3.
-
Page 22: Fault Finding
Fault finding This Space Saver is covered by a free 5-year parts and labour guarantee. Please refer to the Fault finding table below for advice. In the event of difficulty, please contact us on +44 (0) 1245 324560. Fault Checking/Solution Check the power supply is switched ON Check fuse in fused spur Check the fan switch is set to ON... -
Page 23: Installation And User Manual - Controller
HHPS01 Controller Installation and control user manual PROG MODE TIME TEMP HHPS01 WIRELESS CONTROLLER Issue 002 | May 2025 ENGLISH | UK | IRL | SmithsEP.co.uk Issue 02 - May 2025 | SmithsEP.co.uk | 23... -
Page 24: Introduction
Contents Introduction Introduction In the event of items missing or visible damage please contact us on 01245 324560. Declaration of conformity Product dimensions Keep the batteries out of reach of children • Do NOT use if the battery compartment is Pairing the heater to the HHPS01 not secure Basic Operation... -
Page 25: Declaration Of Conformity
Declaration of conformity Product dimensions In accordance with UK Government Guidance. THE APPLIANCES DETAILED HEREON HAVE BEEN INSPECTED AND TESTED, AND CONFORM TO THE REQUIREMENTS OF THE FOLLOWING UK STATUTORY INSTRUMENTS WHERE APPLICABLE: Electrical Equipment (Safety) Regulations 2016 SI. 2016 1101 Electromagnetic Compatibility Regulations 2016 PROG MODE... -
Page 26: Pairing The Heater To The Hhps01
Overview The HHPS01 wireless controller can control an unlimited number products provided they are within range. To do this, the controller must be paired with each heater. The heater will not operate until it has been paired to the controller. Pairing the heater to the HHPS01 In order to pair your appliance with the controller you must:... -
Page 27: Boost Mode
Boost mode The boost feature increases the room temperature for 15 minutes. To amend the set temperature when in BOOST mode, activate the display and then press TEMP. Next, use the + and - buttons to change the temperature. Once the temperature is set, you Auto mode can leave the display to return to the main screen and the settings will be saved. -
Page 28: Keys Locking
Displaying the time/temperature Keys locking The HHPS01 can display either the time & day Press and hold TIME and TEMP together for 5 or the room temperature when in one of the 4 seconds. The display will show the symbol. standard operating modes. -
Page 29: Setting The Automatic Program Schedule
Setting the automatic program schedule An example of one day program on HHPS01 PROGRAM 1 PROGRAM 2 PROGRAM 3 PROGRAM 4 PROGRAM 5 PROGRAM 6 °C 19°C 22°C 22°C 16°C 10°C 4°C 06.00 08.00 12.00 14.00 16.00 22.00 Logic diagram for setting program on HHPS01 Step 3: Press the PROG button. -
Page 30: Automatic Program Overview
Set program inactive Step 8: Press the PROG button. The temperature If you do not require the use of all 6 programs should flash. Use the they can be deactivated. When in programming + and - buttons to mode select the program you want to make select a frost protection inactive and press the TIME button. -
Page 31: Setup Menu
Step 4: Use the + and - 5 - Set maximum buttons to select the day temperature to copy the programs to. Step 5: Press the TIME 6 - Enable/disable open window button to copy the detection programs. The ‘TO’ will flash to confirm the programs have been copied. -
Page 32: Choosing A Position In A Room
B - Program mode select. Choose between a 7-day, 5-day 2-day or a 24 hour timer. C - Select operating mode: 1 = temperature control 2 = manual control The bracket acts as a holder for the controller. The controller can be removed from the D - Enable/disable SL bracket easily to... -
Page 33: Registering Your Product
Registering your product Disposal As part of the policy of continuous product Thank you for purchasing a Smith’s product. It has improvement, Smith’s Environmental Products LTD been designed and manufactured to the highest reserves the right to alter specification without quality standards to ensure it gives you efficient prior notice. - Page 34 Notes 34 | SmithsEP.co.uk | Issue 02 - May 2025...
- Page 35 Notes Issue 02 - May 2025 | SmithsEP.co.uk | 35...
- Page 36 Happy to help To view the full product information download the datasheet at: Smith’s Environmental Products Ltd is one of the leading manufacturers of heating and cooling www.SmithsEP.co.uk products in the UK. We are committed to achieving the highest standards and our faith is For product information, customer services or supported by a free parts and labour guarantee sales support call us on +44 (0) 1245 324900...
