Yamaha CRW4416E - CRW - CD-RW Drive User Manual

Crw4416e series
Hide thumbs

Advertisement

CRW4416E
User Guide
Guide de l'utilisateur
Bedienungsanleitung
SERIES
ON/
READ/
DISC
WRITE

Advertisement

Table of Contents
loading

  Related Manuals for Yamaha CRW4416E - CRW - CD-RW Drive

  Summary of Contents for Yamaha CRW4416E - CRW - CD-RW Drive

  • Page 1 CRW4416E SERIES User Guide Guide de l’utilisateur Bedienungsanleitung READ/ DISC WRITE...
  • Page 2 If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type of product. If you can not locate the appropriate retailer, please contact Yamaha Systems Technology, Inc. 100 Century Center Court, San Jose, CA95112, U.S.A.
  • Page 3 Laser Diode Properties CAUTION Material : GaAlAs Use of controls or adjustments or performance of Wavelength : 783-789 nm procedures other than those specified herein may Emission Duration : Continuous result in hazardous radiation exposure. Laser Output Power : Less than 44.6 W* his output is value measured at a distance 200mm from the objective lens surface on the optical pick-up block.
  • Page 4 WARNING WARNING WARNING • The temperature where CRW4416E is located should be between 5ºC and 40ºC (41ºF – 104ºF), when used in a fan-cooled system. • Do not disassemble the CRW4416E cover to reduce the risk of electric shock. • Always remove the disc before transporting CRW4416E.
  • Page 5: Important Precautions

    • Do not subject the CRW4416E and computer to impact or shock when in use, as this may impair recording or playback. • Yamaha is not responsible for any data or informa- tion losses resulting from the operation of the CRW4416E.
  • Page 6: Table Of Contents

    Chapter 1 - System Configuration ........3 Computer .................3 Software ................3 Tools ................4 Discs ................4 Chapter 2 - Installing the Yamaha CRW4416E Drive ..5 MASTER/SLAVE settings ..........5 Installing the CRW4416E drive ........7 Chapter 3 - Operation ............12 Front Panel ..............12 Loading a Disc ...............13 Ejecting the Disc ............14...
  • Page 7: Introduction

    Introduction Introduction Thank you for purchasing a Yamaha CRW4416E drive. Please read this manual before using the drive in order to make the best use of the superior CRW4416E functions. After reading, please retain this manual for future reference. CRW4416E Features...
  • Page 8: Orange Book Compatible Recording

    Introduction Orange Book Compatible Recording Track at Once In this mode, data can be recorded to disc one track at a time. Discs recorded in this mode cannot be played in CD players or CD- ROM drives other than a CD-RW or a CD-R drive until the session is closed.
  • Page 9: Chapter 1 - System Configuration

    Chapter 1 - System Configuration Chapter 1 - System Configuration Before using the CRW4416E, make sure that you have all of the items on the list of included items. In order to use the CRW4416E, you will require the following. Computer The following operating environment is required: •...
  • Page 10: Tools

    Phillips screwdriver This is used to remove the Phillips Screwdriver cover of your computer, and to install the Yamaha CRW4416E drive. Long nose pliers These are used to insert or remove the jumper pin when setting the MASTER/SLAVE settings of the Yamaha CRW4416E drive.
  • Page 11: Chapter 2 - Installing The Yamaha Crw4416E Drive

    Chapter 2 - Installing the Yamaha CRW4416E Drive Chapter 2 - Installing the Yamaha CRW4416E Drive MASTER/SLAVE settings Before you install the CRW4416E in your computer, you must make the MASTER/SLAVE setting. This setting is set by inserting a jumper pin in the jumper switch located on the rear panel of the CRW4416E drive.
  • Page 12 Chapter 2 - Installing the Yamaha CRW4416E Drive Setting the CRW4416E as the MASTER As shown in the diagram at the right, insert the CSEL SLAVE jumper pin into the right edge of the jumper MASTER switch. Note: If only the CRW4416E will be connected to the IDE interface connector, connect the CRW4416E to the end of the connector.
  • Page 13: Installing The Crw4416E Drive

    Chapter 2 - Installing the Yamaha CRW4416E Drive Installing the CRW4416E drive The following steps will differ slightly depending on the type of com- puter you are using. For details on removing the cover from your computer, and installing or removing internal devices, refer to the manual for your computer.
  • Page 14 Chapter 2 - Installing the Yamaha CRW4416E Drive 3. Your hands or body may be holding a charge of static elec- tricity. Touch a metallic portion of the chassis or power supply to release any such charge. 4. Remove the front cover of a vacant half-height drive bay.
  • Page 15 Chapter 2 - Installing the Yamaha CRW4416E Drive 6. Connect the IDE interface connector. Connect the 40-pin IDE interface connector to the IDE interface located on the rear panel of the CRW4416E drive. Position the connector so that the colored line is at pin 1 (your lower right).
  • Page 16 Chapter 2 - Installing the Yamaha CRW4416E Drive AUDIO cable To the CRW4416E 4-pin connector (large) To the Sound Card (Sound Blaster compatible) 4-pin connector (small) 8. Connect the power supply cable. Connect the +12V and +5V 4-pin power cable to the power supply interface located on the rear panel of the CRW4416E drive.
  • Page 17 Chapter 2 - Installing the Yamaha CRW4416E Drive 9. Tighten the four fastening screws securely. V O L O N / D IS C R E A W R IT 10. Attach the cover of your computer. 11. Connect the power cable to an AC outlet, and switch on your computer.
  • Page 18: Chapter 3 - Operation

    Chapter 3 - Operation Chapter 3 - Operation Front Panel READ/ DISC WRITE 1 Disc tray The disc is inserted and ejected here. Pressing the eject button will open the tray. 2 Headphone jack This stereo mini jack allows you to connect headphones and listen to audio.
  • Page 19: Loading A Disc

    Chapter 3 - Operation 6 Eject button This button is used to open or close the tray. 7 Manual Eject hole This is used to manually eject a disc that cannot be ejected in the nor- mal way. It is for emergency use only. Loading a Disc 1.
  • Page 20: Ejecting The Disc

    Chapter 3 - Operation Ejecting the Disc If the CRW4416E is powered on: Press the eject button to eject the disc. Note: You cannot eject the disc if the ATAPI command prohibits the eject operation while the CRW4416E is reading data. Caution: Be sure to remove the disc after it is completely ejected.
  • Page 21: Manual Eject (Emergency Use)

    Chapter 3 - Operation Manual Eject (emergency use) Here we explain how to eject the disc when it cannot be ejected in the normal way; for example, the power is shut off inadvertently or the loading mechanism fails. This technique should be used only as a last resort.
  • Page 22: Troubleshooting

    Troubleshooting Troubleshooting If CRW4416E is not performing as expected, look up the symptoms in the following table, and take the appropriate corrective action. Symptoms Corrective action The power to the CRW4416E is off • Check the DC power cable connection. The CRW4416E is not recognized by •...
  • Page 23: Appendix

    Appendix Appendix Specifications Interface ATAPI (E-IDE) Data Capacity 650MB (74 minutes disc) 550MB (63 minutes disc) Record/Read Speed Writing (CD-RW): 2X speed, 4X speed (when 4X compatible discs are used) Writing (CD-R): 1X speed (real-time), 2X speed, 4X speed playback: 9 - 16X speed [Max] (partial CAV) Note) Read CD-DA : 10X speed [Max] Read Video CD: 6X speed [Max] CD-DA output is 1X speed playback only...
  • Page 24: Front Panel Indicator Key

    Appendix Front Panel Indicator Key on: green flashing: green — off on: orange flashing: orange Status ON/DISC READ/WRITE Reset — — Ready (no disc) — Inserting disc — Ejecting disc — Ready (disc inserted) — Seeking Preparing to write Writing Writing (test mode) Playback...
  • Page 25 AUSTRIA, EASTERN EUROPE and French: Pour plus de détails sur les produits, RUSSIA veuillez vous adresser à Yamaha ou au distributeur Yamaha Europa GmbH le plus proche figurant dans la liste suivante : Multi Media Division...
