DSC SEM300 QUICK INSTALL GUIDE
SIMPLIFIED INSTRUCTIONS FROM YOUR FRIENDLY A.S.S. TEAM MEMBERS
We have compiled a much simpler installation manual for our customers in the hopes that we
can alleviate all complications while installing your SEM300. Following this instruction guide will
give you the best chance at setting up your Alarm.com communicator without ever having to
reach out for any assistance. If you do have any problems or questions though, please feel free
to email us at
csr@alarmsystemstore.com
1. PURCHASE ALARM.COM SERVICE AND FILL OUT REQUIRED FORM
2. DISARM THE PANEL AND POWER DOWN
3. WIRE THE SEM TO THE PANEL
4. POWER THE SYSTEM UP AND ALLOW THE SEM TO SYNC TO THE PANEL
5. BROADCAST YOUR ZONE LABELS
6. SEND A SYSTEM TEST SIGNAL
7. ENJOY YOUR NEW ALARM.COM INTERACTIVE SERVICE
and we will do our best to assist you.
STEP GUIDE:
Advertisement
Related Manuals for Alarm.Com DSC SEM300
Summary of Contents for Alarm.Com DSC SEM300
- Page 1 SEM300. Following this instruction guide will give you the best chance at setting up your Alarm.com communicator without ever having to reach out for any assistance. If you do have any problems or questions though, please feel free to email us at csr@alarmsystemstore.com...
-
Page 2: Step 1: Before You Start
STEP 1: BEFORE YOU START 1. PURCHASE AN ALARM.COM INTERACTIVE SERVICE FROM ALARM SYSTEM STORE AND COMPLETE THE INSTRUCTIONS IN THE ACTIVATION EMAIL. 2. ENSURE YOU HAVE ALL OF THE COMPONENTS NEEDED FOR YOUR SEM210 INSTALLATION: SEM300 MODULE RED BATTERY... - Page 3 STEP 3: CONNECTING THE SEM WIRING Important: If you do not know what this means, disregard this sentence. Alternate wiring is required when using this device for ETL installations. (+12v wire from the SEM will go to the +12V terminal on the panel) TO WIRE THE PANEL: Connect panel terminal 4 (GND) to SEM GND, panel terminal 6 (GREEN: DATA IN FROM KEYPAD) to GREEN (OUT), and panel terminal 7 (YELLOW: KEYPAD DATA OUT) to YELLOW...
- Page 4 STEP 4: POWER THE SYSTEM UP AND ALLOW THE SEM TO SYNC WITH THE PANEL Connect the backup battery and restore AC power to the panel. For the SEM to interact with the existing zones on the system, it must read them from the PowerSeries panel. The SEM does a zone scan to read this information.
-
Page 5: System Test
SYSTEM TEST: To fully activate your service and sync up the panel and communicator to the Alarm.com account, you will need to send a system test from the panel. To do this follow these steps: Press *6 + (master code if required) Using the >... - Page 6 THE ACTIVATION AND TESTING FOR IT. OUR CUSTOMER SERVICE (csr@alarmsystemstore.com) WILL INFORM YOU ON HOW TO TEST YOUR SYSTEM AND FINISH YOUR ACTIVATION. CONGRATULATIONS! YOU HAVE JUST INSTALLED YOUR SEM300! YOU ARE READY FOR STEP 7: ENJOY YOUR ALARM.COM INTERACTIVE PLAN...
