User Manual
INTELLIGENT SOUNDER BEACON BASE
BP-FD-SSB321

Advertisement

loading
Need help?

Need help?

Do you have a question about the BP-FD-SSB321 and is the answer not in the manual?

Questions and answers

Related Manuals for Blaupunkt BP-FD-SSB321

Summary of Contents for Blaupunkt BP-FD-SSB321

  • Page 1 User Manual INTELLIGENT SOUNDER BEACON BASE BP-FD-SSB321...

  • Page 2: Technical Specification

    Read through these instructions before using this device to ensure correct installation and use! I. Overview BP-FD-SSB321 Intelligent Sounder Beacon Base is addressable , low power consumption and loop powered to reduce installation cost. The Intelligent Sounder Beacon Base can be used with a detector. The detector can be mounted directly on the base.
  • Page 3 Fig.1 IV. Use and engineering application Wiring:See Fig.2.The Sounder Beacon Base is subject to a two-wire non-polarity connection: Terminals 1 and 3 are respectively connected with the terminals L1 and L2 of the loop bus of a compatible fire alarm control panel. Terminals 2 and 4 are respectively connected with the terminals 2 and 4 of (Heat Detector) BP-FD-AHD302...

  • Page 4: Installation

    3->Loop terminal (L2/L1) Fig.5 Base and wiring diagram 1) Use two M4 screws to fix the BP-FD-SSB321 bracket to ceiling via the two elliptic screw holes (see Fig.5) . 2) Twist the base onto the bracket (pay attention to aligning two arrow).
  • Page 5 CROSS RECESSED PAN HEAD SCREWS M3x9 CLAMP PLATE TOP COVER DETECTOR BUTTOM COVER BRACKET Fig 6 VI. Sound Level Data (EN54-3 approved) Tone: 667Hz-2000Hz@0.21Hz, Max Volume, dB(A)@1m Angle Horizontal Vertical Voltage 82.0 85.0 82.7 85.4 15° 80.0 83.5 81.8 84.7 45°...
  • Page 6 Tell: +381 11 318 68 68 o ce@securityshop.rs Imported/Distributed by Security Shop doo BLAUPUNKT and the BLAUPUNKT logo are trademarks of TALISMAN BRANDS (Luxembourg) S.A.R.L. and are used under license from Talisman Brands, Inc. BLAUPUNKT licensees are solely responsible for the BLAUPUNKT branded products manufactured, distributed and sold under license.
