Summary of Contents for iTechworld PS1800 PRO
- Page 1 USER GUIDE PS1800 PRO PORTABLE POWER STATION...
-
Page 2: Table Of Contents
CONTENTS Product Overview Overview Package Contents XT60 Port AC Input Overload Protection LCD Features UPS Mode UPS Connections EB1536 Connection Charging Solar Panel Charging AC Charger Charging Car/Vehicle Charging Fault Resolution Specifications Safety Precautions Contact Us Back Page... -
Page 3: Product Overview
PRODUCT OVERVIEW Package Contents XT60 to 50A Anderson AC Charger Car Charger User Guide Cable Storage Bag MAIN POWER CONTROL AC 240V OUTPUT PORTS USB CONTROL AC 240V OUTPUT CONTROL LIGHT CONTROL PARALLEL PORTS DC CONTROL AC 240V INPUT PORT LCD DISPLAY XT60 INPUT PORT AIR INTAKE/OUTLET... - Page 4 POWER CONTROL BUTTON This is the master power button, a long press to turn on and a long press to turn off the unit (hold the button until the screen turns on/off). When not in use, please turn the unit off. USB CONTROL BUTTON Make sure the power station is on before pressing the USB control button.
-
Page 5: Xt60 Port
AIR INTAKE/OUTLET (BUILT-IN COOLING FAN) The PS1800 PRO utilises an internal cooling fan to ensure it operates within the appropriate temperature range. When the PS1800 PRO experiences a high output/ input, it automatically turns on the fan. The fan may turn on intermittently to keep the internal temperatures within the operating range. -
Page 6: Ac Input
Use the included wall socket to get 1500W fast charging, which can fully charge the PS1800 PRO from 0 to 100% in 1 hour. The PS1800 PRO should be charged directly by the wall socket, please do not use extension cords. -
Page 7: Lcd Features
LCD FEATURES REMAINING DISCHARGE TIME BATTERY LEVEL INDICATOR EXPANSION BATTERY STATUS BATTERY PROGRESS BAR PARALLEL OPERATION STATUS AC OUTPUT STATUS TOTAL INPUT POWER USB OUTPUT STATUS AC CHARGING STATUS USB-C OUTPUT STATUS XT60 INPUT STATUS CIGARETTE PORT OUTPUT STATUS HIGH/LOW TEMPERATURE LED LIGHT STATUS FAN STATUS TOTAL OUTPUT POWER... -
Page 8: Ups Mode
UPS MODE The PS1800 PRO has a bypass function, which means power will not pass through the battery; it will be taken directly from the AC output. In this mode, the power source is the power grid, when there is an emergency power outage, the power source will switch to the battery within 1Oms and protect the connected appliance. -
Page 9: Eb1536 Connection
After successful parallel connection, the PS1800 PRO can commence charging or discharging. Keep in mind, the PS1800 PRO will charge at a slower rate when it' s almost full and will release power faster when used. If there' s no incoming charge, the unit with a higher state of charge will charge the unit with a lower state of charge. -
Page 10: Charging
CHARGING SOLAR PANEL CHARGING Do not charge the PS1800 PRO via a solar panel that has a voltage exceeding 90V. Supports 1200W max solar input (solar panels not included), the charging time depends on the solar panel input. To ensure proper operation, please verify that there is no regulator in the line. -
Page 11: Ac Charger Charging
AC CHARGER CHARGING Use the AC charger provided to charge this unit. It will only require 1 hour to fully charge the PS1800 PRO. CAR/VEHICLE CHARGING it’ s important to use the car charger that was provided with the unit for charging. -
Page 12: Fault Resolution
3 - If the overload protector has not been and buzzes activated, proceed as follows: directly press the AC output button to restore the output function. The PS1800 PRO Remove all loads, disconnect the power has surpassed the source from this product, and wait for the unit... -
Page 13: Specifications
SPECIFICATIONS General Specifications Model name PS1800 PRO Dimensions 218 x 403 x 295mm Weight 17.5Kg Capacity 1536Wh Max parallel capacity 4608Wh XT60 input 12-90V 1200W max 50/60Hz (frequency switch available), rated at AC output 1800W Pure Sine Wave. Built in overload and short circuit protection. -
Page 14: Safety Precautions
SAFETY PRECAUTIONS For safe operation and optimal performance, the PS1800 PRO Portable Power Station must be operated correctly. Please carefully read, under stand, and follow all instructions and guidelines in this user guide. Failure to follow these instructions may result in damage to the unit, property, death, or serious injury. -
Page 15: Limitations Of Use
WARNING: Do not drop the power station. WARNING: When not using the power station, turn off the power and unplug the power cord. WARNING: Do not use the power station and its accessories to connect equipment if there is a defect. WARNING: Do not use the power station in an environment where it will get wet, the unit is not waterproof. -
Page 16: Contact Us
When it comes to energy storage and creation at iTechworld, we take pride in being one of the biggest names in the industry. Based in Australia, we are a family-owned and operated business. With many more innovative products on the horizon we are committed to constantly raising the bar to provide bigger and better benefi ts to all our customers Australia-wide.
