Milwaukee 48351511 Manual

IMPORTANT SAFETY INSTRUCTIONS
READ AND UNDERSTAND ALL
WARNING
INSTRUCTIONS. Failure to follow
all instructions listed below, may result in electric
shock, fire and/or serious personal injury.
SAVE THESE INSTRUCTIONS
THIS OPERATOR'S
IMPORTANT SAFETY
INSTRUCTIONS.
• Make sure that all pieces of this device and
the tool are
operation.
• Always use common sense and be cautious
when using tools. It is not possible to anticipate
every situation that could result in a dangerous
outcome. Do not use this tool if you do not
understand these operating instructions or you
feel the work is beyond your capability; contact
MILWAUKEE Tool or a trained professional for
®
additional information or training.
• Maintain labels and nameplates. These carry
important information. If unreadable or missing,
contact a MILWAUKEE
replacement.
FUNCTIONAL DESCRIPTION
11
10
1. Non-marring
ceiling pad
2. Spring rod
3. Swivel back plate
4. Clamp body
5. Jaw grip
6. Lead screw
Cat. No.
48351511
MANUAL CONTAINS
AND OPERATING
securely mounted
service facility for a
®
2
3
9
7. Metal mounting plate
8. Quick adjustment
knob
9. Extension
11. Reference marks
TELESCOPING LASER POLE
ADDITIONAL BATTERY SAFETY RULES
WARNING
short circuit, never immerse your tool, battery pack
or charger in fluid or allow a fluid to flow inside them.
Corrosive or conductive fluids, such as seawater,
before
certain
bleach-containing products, etc., can cause a short
circuit.
WARNING
Cat. No. ................................................... 48351511
Usable Range ...................................... 0 - 365.8 cm
Macro Adjustment ..........................147.5 - 365.8 cm
Laser Compatibility ................ MILWAUKEE
WARNING
Others may be hazardous.
Assembling Laser Mounting Pole
Make sure that all pieces of this device and the tool
are securely mounted before operation.
4
Review height needed. Assemble pole sections
1.
to desired height.
2.
Attach screw-on bottom floor pad.
3.
Attach swivel head by firmly pushing cup section
5
into ball section until pieces snap into place.
4.
Loosen clamp using quick adjustment knob.
5.
Place clamp onto pole and use quick adjustment
6
knob to tighten clamp into place.
7
Twist the quick adjustment knob anticlockwise to
1.
disengage threads.
2.
Slide jaw to desired position by pushing and
pulling lead screw.
3.
Twist the quick adjustment knob clockwise to
reengage threads and tighten the clamp.
8
1
SYMBOLOGY
Read operator's manual
To reduce the risk of fire, personal
injury, and product damage due to a
industrial chemicals,
Do not charge non-rechargeable
batteries.
SPECIFICATIONS
ASSEMBLY
Only use accessories specifically
recommended
OPERATION
Quick Release Feature
and bleach or
lasers
®
for this tool.
