PAC RP4-VW11 Quick Start Manual

RP4-VW11
Introduction and Features
The RP4-VW11 interface allows the replacement of a factory radio in select Volkswagen vehicles with LSFT-CAN databus
radios. Using this interface will retain factory features such as steering wheel controls (SWC) and the factory Volkswagen
amplifier when the original radio is removed. Use of this interface also allows you to program two radio functions to each
SWC button by using short press long press dual command functionality. The RP4-VW11 also provides data bus driven
outputs such as retained accessory power (RAP), vehicle speed signal (VSS), illumination, reverse trigger and parking
brake.
Important Notes
1. These instructions apply to R.1.5.4.7 or later revisions. The revision info can be found on a small white sticker on the interface
and packaging.
2. The radio select rotary switch on the side of the interface must be adjusted to the proper radio setting before plugging the
interface into the vehicle (see next page for setting chart).
3. The interface comes pre-programmed for all of the vehicles factory SWC functions and does not require programming unless
you wish to re-assign the SWC functions or utilize short press long press dual command functionality. The SWC can always
be restored to default settings by pressing and releasing the program button on the side of the interface once and waiting 7
seconds for the LED to flash 4 times.
4. The LED will flash whenever a user programmable SWC button is pressed.
5. The SWC will not function when the vehicle is in Accessory mode.
6. When used in any of the following vehicles equipped with a Multi Function Display (MFD): The audio screen will
display the SWC functions as they are pressed on the steering wheel. It will also display "Programming Mode" whenever the
programming button on the side of the interface is pressed. The Blue / White remote input wire must be hooked up, and the
MFD must be in audio mode for these features to be displayed.
A. 2009-2014 CC
B. 2010-2012 Eos
7. When used in any of the following vehicles equipped with a MFD: The up and down arrows on the SWC that also control
the MFD come programmed with functions, but the SWC will control both the radio and the MFD. These buttons can be
removed by reprogramming the interface and not programming these buttons.
A. 2006-2009 Golf, GTI, Jetta, Passat
B. 2007-2009 Eos, Rabbit
8. In vehicles equipped with factory Bluetooth, the telematics module must be disconnected in order to use the Phone and Voice
buttons. Not disconnecting the telematics module will result in the MFD switching to phone mode every time the Phone or
Voice buttons are pressed.The telematics module can usually be found under the passenger seat.
9. The RAP feature is not available in 2010+ vehicles equipped with a premium amplified system.
10. The parking brake wire will output a negative (-) trigger at all times until the vehicle is moving at a speed of approximately 3
mph or faster.
Wiring Connection Chart
Interface Connector
Red / White Parking Brake
Output (-)
Purple / White Vehicle Speed
Red Accessory Output
Orange / White Illumination Output
Green Reverse Output (+)
Pacific Accessory Corporation
C. 2010-2014 Golf
D. 2010-2014 GTI
Vehicle Connector
Yellow
Black
Blue/White
Output
White
White / Black
(10 amp)
Grey
Grey / Black
(+)
Green
Green / Black
Purple
Purple / Black
© 2018 AAMP Global. All rights reserved. PAC is a Power Brand of AAMP Global.
Radio Replacement and Steering Wheel Control
E. 2010-2015 Jetta
F. 2010-2014 Passat
Battery +12v
Ground
Amp Turn On Input
Front L + input
Front L - input
Front R + input
Front R - input
Rear L + input
Rear L - input
Rear R + input
Rear R - input
PAC-audio.com
Interface for Volkswagen Vehicles
G. 2010-2011 Rabbit
H. 2011-2014 Tiguan
SWC Connector
Blue / Yellow Kenwwod, Newer
JVC
3.5mm Jack Alpine, JVC,
Clarion, Fusion,
Pioneer, Sony,
Boyo, Dual,
Lightning Audio,
Visteon or Advent
Rev: 5
Date: 050918
Page 1
