A.R.T. Furniture 233242-2802TP Assembly Instructions

Thank you for purchasing this quality product from A.R.T. Furniture. Be sure to check all
packing material for parts which may have come loose inside the carton during shipment.
Identify and count all parts and compare with the parts list below.
Note: Some furniture is heavy, it is recommended that two people assemble this item to avoid
injury or damage.
Step 1
Hardware List
A
B
C
D
E
F
G
H
I
J
K
Page 1
Step 2
Step 3
Qt.
6
24
4
! KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE !
ASSEMBLY INSTRUCTIONS
233242-2802TP Gwynn Curio China TOP
233242-2802BS Gwynn Curio China BASE
Back View
Step 1
Attach the TOP and BASE with mending plates
(attached to back of TOP) and wood screws (A),
as shown in Diagram A
The skid is packaging material. Please take
it off when you use product.
Step 2
Remove packing material at inside back of case.
Wrench(J)
Step 3
Mending Plate
TOP
BASE
Raise Unit
Lower Unit
Plastic Cap(K)
Holes in Bottom Panel.
One in each corner
11/2016
