Page 1
User manual Bedienungsanleitung Mode d’emploi Manual del usuario Uživatelská příručka Instrukcja obsługi Manuale utente Bruksanvisning Manual de utilizare Használati utasítás Korisnički priručnik Εγχειρίδιο χρήστη Serial PCI Express x1 Card 4 x Serial RS-232 Product-No: 90410 User manual no: 90410-a www.delock.com...
Page 2
English Description The PCI Express card by Delock expands a PC by four external serial RS-232 ports. Different devices such as scanner, protocol converter, IoT devices etc. can be connected to this card. Low Profile Form Factor By using the included low profile brackets, the PCI Express card can be also installed into a Mini-PC.
Page 3
English Package content • PCI Express card • 4 x low profile bracket • Driver CD • User manual Safety instructions • Protect the product against moisture • Avoid static electricity when installing the card Hardware Installation Turn off your PC and unplug the power cord. Open the housing.
Page 4
English Support Delock If you have further questions, please contact our customer support support@delock.de You can find current product information on our homepage: www.delock.com Final clause Information and data contained in this manual are subject to change without notice in advance. Errors and misprints excepted.
Page 5
Deutsch Systemvoraussetzungen • Linux Kernel 3.18 oder höher • Windows Server 2012 R2/Server 2016 • Windows 7/7-64/8.1/8.1-64/10/10-64/11 • PC mit einem freien PCI Express Steckplatz und einem freien Slot Sicherheitshinweise • Produkt vor Feuchtigkeit schützen • Vermeiden Sie statische Aufladung beim Einbau der Karte Hardwareinstallation Schalten Sie Ihren PC aus, ziehen Sie das Netzkabel.
Page 6
Français Configuration système requise • Linux Kernel 3.18 ou version ultérieure • Windows Server 2012 R2/Server 2016 • Windows 7/7-64/8.1/8.1-64/10/10-64/11 • PC avec une slot PCI Express libre et une fente arrière libre Instructions de sécurité • Protéger le produit contre l’humidité •...
Page 7
Español Requisitos del sistema • Linux Kernel 3.18 o superior • Windows Server 2012 R2/Server 2016 • Windows 7/7-64/8.1/8.1-64/10/10-64/11 • PC con una ranura PCI Express libre y una ranura trasera Instrucciones de seguridad • Proteja el producto contra el polvo •...
Page 8
České Systémové požadavky • Linux Kernel 3.18 nebo vyšší • Windows Server 2012 R2/Server 2016 • Windows 7/7-64/8.1/8.1-64/10/10-64/11 • PC s jedním volným PCI Express slotem a jedním zadním slotem Bezpečnostní pokyny • Chraňte produkt před vlhkostí • Při instalaci karty se vyvarujte působení statické elektřiny Instalace hardware Vypněte PC a odpojte přívodní...
Page 9
Polsku Wymagania systemowe • Linux Kernel 3.18 lub nowszy • Windows Server 2012 R2/Server 2016 • Windows 7/7-64/8.1/8.1-64/10/10-64/11 • PC z wolnym slotem PCI Express i jednym tylnym gniazdem Instrukcje bezpieczeństwa • Produkt należy zabezpieczyć przed wilgocią • Podczas instalacji karty należy się zabezpieczyć przed elektrycznością...
Page 10
Italiano Requisiti di sistema • Linux Kernel 3.18 o superiore • Windows Server 2012 R2/Server 2016 • Windows 7/7-64/8.1/8.1-64/10/10-64/11 • PC con uno slot PCI Express libero e uno slot posteriore Istruzioni per la sicurezza • Proteggere il prodotto dall'umidità •...
Page 11
Svenska Systemkrav • Linux Kernel 3.18 eller högre • Windows Server 2012 R2/Server 2016 • Windows 7/7-64/8.1/8.1-64/10/10-64/11 • Dator med en ledig PCI Express-kortplats och en bakre plats Säkerhetsinstruktioner • Skydda produkten mot fukt • Undvik statisk elektricitet när du installerar kortet Hårdvaruinstallation Stäng av datorn och koppla ifrån strömsladden.
Page 12
Română Cerinte de sistem • Linux Kernel 3.18 sau superior • Windows Server 2012 R2/Server 2016 • Windows 7/7-64/8.1/8.1-64/10/10-64/11 • PC cu un slot PCI Express gratuit și un slot în spate spate Instrucţiuni de siguranţă • Protejaţi produsul împotriva umidităţii •...
Page 13
Magyar Rendszerkövetelmények • Linux Kernel 3.18 vagy újabb • Windows Server 2012 R2/Server 2016 • Windows 7/7-64/8.1/8.1-64/10/10-64/11 • PC egy szabad PCI Express illesztőhellyel és egy hátsó nyílással Biztonsági óvintézkedések • Óvja a terméket a nedvességtől. • Kerülje az elektrosztatikus kisüléseket a kártya telepítése közben. Hardvertelepítés Kapcsolja ki a PC-t és húzza ki a hálózati tápkábelt.
Page 14
Hrvatski Preduvjeti sustava • Linux Kernel 3.18 ili noviji • Windows Server 2012 R2/Server 2016 • Windows 7/7-64/8.1/8.1-64/10/10-64/11 • Računalo s jednim slobodnim PCI Express utorom i jednim stražnjim utorom Sigurnosne upute • Zaštitite proizvod od vlage • Izbjegavajte statički elektricitet prilikom umetanja kartice Ugradnja hardvera Isključite računalo i odvojite kabel za napajanje.
Page 15
ελληνικά Απαιτήσεις συστήματος • Linux Kernel 3.18 ή νεότερο • Windows Server 2012 R2/Server 2016 • Windows 7/7-64/8.1/8.1-64/10/10-64/11 • PC με μία ελεύθερη υποδοχή PCI Express και μία πίσω υποδοχή Οδηγίες ασφάλειας • Προστατεύστε το προϊόν από την υγρασία • Αποφύγετε στατικό ηλεκτρισμό όταν εγκαθιστάτε την κάρτα Εγκατάσταση...
Page 16
Products with a CE symbol fulfill the EMC directive (2014/30/EU) and RoHS directive (2011/65/EU+2015/863+2017/2102), which were released by the EU-comission. The declaration of conformity can be downloaded under documents: https://www.delock.de/produkte/G_90410/merkmale.html WEEE-notice The WEEE (Waste Electrical and Electronic Equipment)-directive, which became effective as European law on February 13th 2003, resulted in an all out change in the disposal of disused electro devices.
