DeLOCK 89048 User Manual

Declaration of conformity
Products with a CE symbol fulfill the EMC directive (2014/30/EU) and
RoHS directive (2011/65/EU+2015/863+2017/2102), which were released by the
EU-comission.
The declaration of conformity can be downloaded under documents:
https://www.delock.de/produkte/G_89048/merkmale.html
WEEE-notice
The WEEE (Waste Electrical and Electronic Equipment)-directive, which became
effective as European law on February 13th 2003, resulted in an all out change
in the disposal of disused electro devices. The primarily purpose of this directive
is the avoidance of electrical waste (WEEE) and at the same time the support of
recycling and other forms of recycling in order to reduce waste. The WEEE-logo
on the device and the package indicates that the device should not be disposed
in the normal household garbage. You are responsible for taking the disused
electrical and electronical devices to a respective collecting point. A separated
collection and reasonable recycling of your electrical waste helps handling the
natural resources more economical. Furthermore recycling of electrical waste is
a contribution to keep the environment and thus also the health of men. Further
information about disposal of electrical and electronical waste, recycling and
the collection points are available in local organizations, waste management
enterprises, in specialized trade and the producer of the device.
Cet appareil
se recycle
Points de collecte sur www.quefairedemesdechets.fr
EU Import: Tragant Handels- und Beteiligungs GmbH
Beeskowdamm 13/15, 14167 Berlin, Germany
Support Delock
If you have further questions, please contact our customer support
support@delock.de
You can find current product information on our homepage: www.delock.com
Final clause
Information and data contained in this manual are subject to change without notice
in advance. Errors and misprints excepted.
Copyright
No part of this user's manual may be reproduced, or transmitted for any purpose,
regardless in which way or by which means, electronically or mechanically, without
explicit written approval of Delock.
Edition: 04/2025
LED indicator
LED No. Function
LED1 PCI Express Reset Indicator
LED3 PCI Express Status Indicator
LED7 USB8 controller (U17) Status
Indicator
LED8 USB12 controller (U22) Status
Indicator
LED9 USB16 controller (U27) Status
Indicator
LED10 USB2 controller (U32) Status
Indicator
LED11 ECC Error Indicator
LED12 Fatal Error Output
LED13 USB 5V Power good
State LED
Pattern
Normal Off
Lane is disabled Off
Controller disabled Off
Controller disabled Off
Controller disabled Off
Controller disabled Off
Normal Off
Normal Off
Normal Off
User manual
Mode d'emploi
Uživatelská příručka
Manuale utente
Manual de utilizare
Korisnički priručnik
PCI Express x4 Card to
4 x external USB 5 Gbps Quad Channel
English
Jumper
Jumper USB Port
1 USB8
3 USB12
5 USB16
7 USB2
State LED
Pattern
Error On
Lane is enabled, On
5.0 GT/s
Controller enabled On
Controller enabled On
Controller enabled On
Controller enabled On
Error On
Error On
Error On
Bedienungsanleitung
Manual del usuario
Instrukcja obsługi
Bruksanvisning
Használati utasítás
Εγχειρίδιο χρήστη
User manual no: 89048-a
1500 mA
On
On
On
On
State LED Pattern
Lane is enabled 2.5 GT/s, Blinking, 0.5 seconds On,
reduced Lanes are up 0.5 seconds off
Product-No: 89048
www.delock.com
900 mA
Off
Off
Off
Off
