USER'S MANUAL
Model No. PFEL57914.1
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today,
go to www.proformservice.com/
registration.
CUSTOMER CARE
For service at any time, go to
www.proformservice.com.
Or call 1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PFEL57914.1 and is the answer not in the manual?

Questions and answers

Related Manuals for ICON Health & Fitness PFEL57914.1

Summary of Contents for ICON Health & Fitness PFEL57914.1

  • Page 1 USER’S MANUAL Model No. PFEL57914.1 Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.proformservice.com/ registration. CUSTOMER CARE For service at any time, go to www.proformservice.com.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 5 STANDARD SERVICE PLANS...

  • Page 6: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary PROFORM reading this manual, please see the front cover of this ® ENDURANCE 720 E elliptical. The ENDURANCE 720 manual. To help us assist you, note the product model E elliptical provides an impressive selection of features number and serial number before contacting us.

  • Page 7: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 8: Assembly

    ASSEMBLY • To hire an authorized service technician to • To identify small parts, see page 7. assemble this product, call 1-800-445-2480. • In addition to the included tool(s), assembly • Assembly requires two persons. requires the following tools: one Phillips screwdriver •...
  • Page 9 3. Press the Cover Mounts (106) on the underside of the Rear Stabilizer Cover (15) into the Rear Stabilizer (2). 4. With the help of a second person, place some of the packing materials (not shown) under the front of the Frame (1). Have the second per- son hold the Frame to prevent it from tipping while you complete this step.
  • Page 10 5. Orient the Upright (4) as shown. Have a second Wire person hold the Upright near the Frame (1). See the inset drawing. Locate the wire tie in the lower end of the Upright (4). Tie the wire tie to the Main Wire (110).
  • Page 11 7. Using a plastic bag to keep your fingers clean, apply some of the included grease to the Pivot Axle (35) and to two 16mm Wave Washers (54). Insert the Pivot Axle (35) through the Upright (4) and center it. Tip: It may be helpful to use a rubber mallet.
  • Page 12 9. Untie and discard the wire tie on the Main Wire (110). While a second person holds the Console (7) near the Upright (4), connect the wires on the Console to the Main Wire (110) and to the Sensor Wires (63). Insert the excess wire into the Upright (4).
  • Page 13 11. Orient the Right Pedal Arm (58) as shown. Apply grease to the axle on the Right Pedal Arm (58). Attach the Right Pedal Arm (58) to the Right Roller Arm (59) with an M8 x 14mm Shoulder Screw (126), a Small Axle Cover (55), and an M8 Washer (97).
  • Page 14 13. Orient the Rear Upright Cover (81) as shown. Attach the Rear Upright Cover (81) to the Upright (4) with four M4 x 16mm Screws (101); start all the Screws, and then tighten them. Orient the Front Upright Cover (117) as shown. Attach the Front Upright Cover (117) around the Upright (4) by pressing it onto the Rear Upright Cover (81).
  • Page 15 15. Identify the Right Upper Body Leg Inner Cover (83) and orient it as shown. Attach the Right Upper Body Leg Inner Cover (83) to the Right Upper Body Leg (60) with an M4 x 16mm Screw (101) and an M5 Washer (94).
  • Page 16 17. Orient the Rear Console Cover (80) as shown. Attach the Rear Console Cover (80) to the Upright (4) with two M4 x 16mm Screws (101). Orient the Front Console Cover (79) as shown. Attach the Front Console Cover (79) around the Upright (4) by pressing it onto the Rear Console Cover (80).

  • Page 17: How To Use The Elliptical

    HOW TO USE THE ELLIPTICAL HOW TO PLUG IN THE POWER CORD A temporary adapter may 2-pole Receptacle This product must be grounded. If it should mal- be used to function or break down, grounding provides a path of connect the Adapter least resistance for electric current to reduce the risk power cord...
  • Page 18 HOW TO MOVE THE ELLIPTICAL HOW TO LEVEL THE ELLIPTICAL Due to the size and weight of the elliptical, moving If the elliptical it requires two persons. Stand in front of the elliptical, rocks slightly hold the upright, and place one foot against one of the on your floor wheels.
  • Page 19 HOW TO ADJUST THE POSITIONS OF THE PEDALS Upper Each pedal can be adjusted to several positions. To Body Arms adjust each pedal, simply pull the pedal handle out- ward, move the pedal to the desired position, and then release the pedal handle into an adjustment hole beneath the pedal.

  • Page 20: Console Diagram

    CONSOLE DIAGRAM MAKE YOUR FITNESS GOALS A REALITY WITH Upload your workout results to the iFit cloud IFIT.COM and track your accomplishments. With your new iFit-compatible fitness equipment, you can use an array of features on iFit.com to make your Set calorie, time, or distance goals for your fitness goals a reality: workouts.

  • Page 21: Features Of The Console

    FEATURES OF THE CONSOLE HOW TO TURN ON THE POWER The advanced console offers an array of features IMPORTANT: If the elliptical has been exposed to cold temperatures, allow it to warm to room tem- designed to make your workouts more effective and perature before you turn on the power.

  • Page 22: How To Use The Manual Mode

    HOW TO USE THE MANUAL MODE Calories (Cals.)—This display mode will show the approximate number of calories you have burned. 1. Begin pedaling or press any button on the console to turn on the console. Calories per Hour (Cals./Hr)—This display mode will show the approximate number of calories you See HOW TO TURN ON THE POWER on are burning per hour.
  • Page 23 Incline—This tab will show a profile of the incline with your palms resting against the contacts. Avoid moving your hands or gripping the contacts settings of the workout. A new segment will appear at the end of each minute. tightly. As you exercise, the workout intensity level bar When your pulse is detected, a heart symbol will will indicate the approximate intensity level of your...
  • Page 24 HOW TO USE AN ONBOARD WORKOUT in the display for a few seconds to alert you. The resistance of the pedals and the incline level of the 1. Begin pedaling or press any button on the frame will then change. console to turn on the console.
  • Page 25 HOW TO USE A SET-A-GOAL WORKOUT Note: The calorie goal is an estimate of the number of calories that you will burn during 1. Begin pedaling or press any button on the the workout. The actual number of calories that console to turn on the console.
  • Page 26 HOW TO USE AN IFIT WORKOUT Press the Map button, the Train button, or the Lose Wt. button to download the next workout of that You must have an iFit module to use an iFit workout. type in your schedule. To purchase an iFit module at any time, go to www.iFit.com or call the telephone number on the Press the Compete button to compete in a race...
  • Page 27 6. Follow your progress with the display. Next, press the play button on your personal audio player. Adjust See step 4 on page 22. the volume level using the volume increase and decrease buttons on The My Trail tab will show a map of the trail or it will the console or the volume control show a track and the number of laps you complete.
  • Page 28 HOW TO CHANGE CONSOLE SETTINGS To view distance in miles, select ENGLISH. To view distance in kilometers, select METRIC. 1. Select the settings mode. Demo—The console features a display demo To select the settings mode, press the gear button. mode, designed to be used if the elliptical is dis- The settings information will appear in the display.

  • Page 29: Fcc Information

    FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 30: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE HOW TO ADJUST THE REED SWITCH Inspect and tighten all parts of the elliptical regularly. If the console does not display correct feedback, the Replace any worn parts immediately. reed switch should be adjusted. To adjust the reed switch, first press the power switch to the off posi- To clean the elliptical, use a damp cloth and a small tion and unplug the power cord.

  • Page 31: How To Adjust The Drive Belt

    HOW TO ADJUST THE DRIVE BELT See EXPLODED DRAWING C on page 39. Remove the M4 x 19mm Screws (5) and the M4 x 48mm Screw If the pedals slip while you are pedaling, even while (107) from the Left and Right Shields (73, 74). Then, the resistance is adjusted to the highest level, the drive remove the Right Shield.

  • Page 32: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 33: Suggested Stretches

    SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch; never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
  • Page 34 NOTES...

  • Page 35: Part List

    PART LIST Model No. PFEL57914.1 R1014A Key No. Qty. Description Key No. Qty. Description Frame Roller Rear Stabilizer Right Pedal Ramp Large Axle Cover Upright 16mm Wave Washer M4 x 19mm Screw Small Axle Cover Front Stabilizer Roller Arm Bushing...
  • Page 36 Key No. Qty. Description Key No. Qty. Description M4 x 16mm Screw M4 x 19mm Self-tapping Screw M8 Locknut Bumper M6 x 12mm Screw M8 x 14mm Shoulder Screw M10 x 122mm Screw Tablet Holder M10 Split Washer Left Pedal Plate Cover Mount Left Pedal Handle M4 x 48mm Screw...

  • Page 37: Exploded Drawing

    EXPLODED DRAWING A Model No. PFEL57914.1 R1014A...
  • Page 38 EXPLODED DRAWING B Model No. PFEL57914.1 R1014A...
  • Page 39 EXPLODED DRAWING C Model No. PFEL57914.1 R1014A...

  • Page 40: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
