E-KC-102 SERIES HEAD MOUNTED TYPE
TEMPERATURE CONVERTER USER MANUAL
The E-KC-102 converter is designed for use in an industrial environment.
m
The package of the E-KC-102 converter
cert f cate.
m
After open ng the package, please v sually check whether the type of the transm tter s su table
for the order, whether the above-ment oned parts are m ss ng and whether the transm tter has
been damaged dur ng sh pment.
m
Before nstall ng and operat ng the controller, please read the user manual thoroughly.
m
The nstallat on and conf gurat on of the controller must only be performed by a person qual f ed n nstrumentat on.
m
Keep the un t away from flamable gases, that could cause explot ons.
m
Do not use alcohol or other solvents to clean the transm tter. Use a clean cloth soaked n water t ghtly squeezed
to gently w pe the outer surface of the transm tter.
m
It s not used n med cal appl cat ons.
1. DESCRIPTION
E-KC-102 series two wire transmitters are microprocessor based
industrial instruments in plastic case. E-KC-102 transmitters are used
to convert the thermocouple and resistance thermometer signals into
standard 4-20 mA The configuration of the transmitter is done by
PC, using a software programme supplied by Elimko.
The RS 232 connection hardware is also available from Elimko.
2. TECHNICAL SPECIFICATIONS
2.1. OPERATING RANGE and EASURING ACCURACY M
(at 24 V supply voltage and 25°C ± 3°C ambient temperature)
LOWER
STANDARD
SENSOR
LIMIT
RTD Pt-100 IEC 60751 -200°C
B 100°C
E -200°C
J -200°C
K -200°C
IEC 60584
N -200°C
T/C
R -40°C
S -40°C
T -200°C
L -200°C
DIN 43710
U -200°C
mV -2000mV
If the input type and scale is not specified while ordering, factory settings are;
For KC-102-RT Input Type : Pt-100, and Scale
For KC-102-TC Input Type : Type K, and Scale
KY-KC100-0224-1
conta ns; the Converter
ACCURACY
UPPER MINIMUM
LIMIT SPAN A/D D/A
850°C 50°C ±0.25°C
1800°C 100°C ±2.00°C
840°C 50°C ±0.50°C
1120°C 50°C ±0.50°C
1360°C 50°C ±0.50°C
1300°C 50°C ±0.50°C ±0.1%
Span
1760°C 100°C ±1.00°C
1760°C 100°C ±1.00°C
400°C 50°C ±0.50°C
900°C 50°C ±0.50°C
600°C 50°C ±0.50°C
500mV 25mV ±0.075mV
: 0-200°C,
: 0-400°C.
, user manual and guarantee
2.2. General Specifications
Ele ctrical :
10.0 - 30 V DC
Supply Voltage
Voltage Drop
10.0 V
Environmental Conditions:
Operating Temperature -10°C to +55°C
IP 00,
IP 66 (DIN 43729 mounted on
Protection Class
type B head)
Cal brat on Temp. 25°C ±3°C
Mechan cal:
D mens ons Ø 44.0 mm x 21.5 mm
40 g
We ght (approx.)
Max. 1.5 mm² (AWG 16)
Connect on Cables
Res stance Thermometer (RTD) / Res stance Input:
Sensor Connect on
3-wire or 4-wire (Configurable)
100 W
Maximum Wire Resistance
Wire Break (Output current
Error Signaling
can be configured Up / Down.)
Thermocouple (TC) / mV Input:
Input Impedance > 10 MW
100 W
Maximum Wire Resistance
Cold Junction Constant, Internal NTC,
Compensation (CJC) External Pt-100 (Configurable)
W re Break (Output current
Error S gnal ng
can be conf gured Up / Down.)
Output:
Output Signal 4 - 20 mA or 20 - 4 mA
Load Resistance
[V
supply
(600
Operating Influences:
Ambient Temperature < ± 0.01% / °C
CJC Error (For TC Inputs)
< ± 1.0 °C
EMC Immunity
< ± 0.5% Span
Electromagnetic Compatibility:
The E-KC-102 meets the requirements of
TS EN 61326-1.
Elimko
KY-KC102-0524-1
W
-10]× 50
W
at 22 V DC)
