Elimko E-KC-200-H Series Quick Start Manual

E-KC-200-H SERIES HEAD-MOUNTED TYPE TEMPERATURE
CONVERTER WITH HART PROTOCOL
KY-KC200H-0224-1
1. DESCRIPTION
The E-KC-200-H is a head mount type
loop powered temperature transmitter
®
with HART protocol. The transmitter
converts the measured values to a 4 to
20 mA DC signal for transmission.
Thermocouples (TC) and resistance
thermometers (RTD) can be used as a temperature sensor.
The transmitter also accepts resistance and DC mV as an input
signal.
The transmitter is configurable via HART communication
interface or by PC using proprietary software available from
Elimko.
2. TECHNICAL SPECIFICATIONS
2.1. General Specifications
Ele ctr cal :
Supply Voltage
Voltage Drop
Isolat on Voltage, Test
Isolat on Voltage, Operat on
Env ronmental Cond t ons:
Operat ng Temperature
Max. Perm ss ble Hum d ty
Protect on Class
Cal brat on Temp.
Mechan cal:
D mens ons
We ght (approx.)
Connect on Cables
Res stance Thermometer (RTD) / Res stance Input:
Sensor Connect on Test
Maximum Wire Resistance
2-Wire Compensation
Resistance
Measurement Current
Error S gnal ng
Thermocouple (TC) / mV Input:
Input Impedance
Max mum W re Res stance
Cold Junction
Compensation (CJC)
Error S gnal ng
Output:
Output S gnal
Load Res stance
Malfunct on Ind cat on
Output Update
Operat ng Influences:
Amb ent Temperature
CJC Error (For TC Inputs)
EMC Immun ty
Other:
Warm-Up T me
Commun cat on
Damp ng (Conf gurable)
Memory
Electromagnetic Compatibility:
The E-KC-200-H meets the requirements of TS EN 61326-1.
KY-KC200H-0224-1
®
9.0 - 36 V DC
9.0 V
1.0 kV AC
50 V AC
-20°C to +70°C
(with no condensation)
< 95% RH
IP00
25°C ±3°C
Ø 44.0 mm x 21.5 mm
60 g
Maximum 1.5 mm² (AWG 16)
2-Wire, 3-Wire, 4-Wire
(Configurable)
50 
Maximum 1000 
(Configurable)
< 150 µA
Wire Break, Short Circuit
> 10 M
500 
Constant, Internal NTC,
External Pt-100 (Configurable)
Wire Break
4 - 20 mA or 20 - 4 mA
< ((Vsupply - 9) / 0.021) 
3.8 mA or 21.0 mA
(Configurable)
10 per second
< ± 0.01% / °C
< ± 1.0 °C
< ± 0.5% Span
5 Minutes
HART 7
0 to 60 seconds
(Configurable)
Maximum Write-Erase
Operation: 10.000 times
E-KC-200-H converter is designed for use in
an industrial environment.
 The package of the E-KC-200 H converter
conta ns; the Converter
guarantee cert f cate.
After open ng the package, please v sually check

whether the type of the transm tter s su table for the
order, whether the above-ment oned parts are m ss ng
and whether the transm tter has been damaged dur ng
sh pment.

Before nstall ng and operat ng the controller, please
read the user manual thoroughly.

The nstallat on and conf gurat on of the controller
must only be performed by a person qual f ed n
nstrumentat on.

Keep the un t away from flamable gases, that could
cause explot ons.

Do not use alcohol or other solvents to clean the
transm tter. Use a clean cloth soaked n water t ghtly
squeezed to gently w pe the outer surface of the
transm tter.

It s not used n med cal appl cat ons.
2. TECHNICAL SPECIFICATIONS
2. . 2 Operating Range and
(at 24 V supply voltage and 25°C ± 3°C ambient temperature)
LOWER
STANDARD
SENSOR
LIMIT
Pt-50 IEC 60751 -200°C
Pt-100 IEC 60751 -200°C
Pt-500 IEC 60751 -200°C
Pt-1000
IEC 60751 -200°C
Ni-50 DIN 43760 -60°C
RTD
Ni-100 DIN 43760 -60°C
Ni-120 DIN 43760 -60°C
Ni-200 DIN 43760 -60°C
Ni-500 DIN 43760 -60°C
Ni-1000 DIN 43760 -60°C
B 100°C
E -200°C
J -200°C
K -200°C
IEC 60584
N -200°C
T/C
R -40°C
S -40°C
T -200°C
L -200°C
DIN 43710
U -200°C
mV -200mV
ohm
If the input type and scale is not specified while ordering, factory settings are;
Input Type : Pt-100, and Scale : 0-200°C.
3. DIMENSIONS
1
Figure 1.
Mechanical
Dimensions of
E-KC-200-H
6
ø = 6.0 mm
ø = 44.0 mm
KY-KC200H-0224-1
, user manual and
M easuring Accuracy
ACCURACY
TOP MINIMUM
LIMIT SCALE A/D
840°C 25°C ±0.50°C
840°C 25°C ±0.25°C
840°C 25°C ±0.25°C
840°C 25°C ±0.25°C
180°C 25°C ±0.25°C
180°C 25°C ±0.25°C
180°C 25°C ±0.25°C
180°C 25°C ±0.25°C
180°C 25°C ±0.25°C
180°C 25°C ±0.25°C
1800°C 100°C ±2.00°C
840°C 50°C ±0.50°C
1120°C 50°C ±0.50°C
1360°C 50°C ±0.50°C
1300°C 50°C ±0.50°C
1760°C 100°C ±1.00°C
1760°C 100°C ±1.00°C
400°C 50°C ±0.50°C
900°C 50°C ±0.50°C
600°C 50°C ±0.50°C
1000mV 25mV ±0.075mV
0  500  50 
±0.50°C
Lid
2
ø = 7.2 mm
3
4
5
33.0 mm
D/A
±0.1%
Span
Lid
21.5 mm
