Elimko E-KC-101 Series User Manual

E-KC-101 SERIES ISOLATED HEAD-MOUNTED TYPE
TEMPERATURE CONVERTER USER MANUAL
The E-KC-101 converter is designed for use in an industrial environment.
 The package of the
cert f cate.
 After open ng the package, please v sually check whether the type of the transm tter s su table
for the order, whether the above-ment oned parts are m ss ng and whether the transm tter has
been damaged dur ng sh pment.
 Before nstall ng and operat ng the controller, please read the user manual thoroughly.
 The nstallat on and conf gurat on of the controller must only be performed by a person qual f ed n nstrumentat on.
 Keep the un t away from flamable gases, that could cause explot ons.
 Do not use alcohol or other solvents to clean the transm tter. Use a clean cloth soaked n water t ghtly squeezed
to gently w pe the outer surface of the transm tter.
 It s not used n med cal appl cat ons.
1. DESCRIPTION
The E-KC-101 is a head mount type isolated
two wire temperature transmitter.
The transmitter converts the measured
values to a 4 to 20 mA DC signal for
transmission. Thermocouples (TC) and
resistance thermometers (RTD) can be
used as a temperature sensor. The
transmitter also accepts resistance and DC mV as an input signal.
The transmitter is configurable via by PC using proprietary software
available from Elimko.
2. TECHNICAL SPECIFICATIONS
2.1. Operating Range and
(at 24 V supply voltage and 25°C ± 3°C ambient temperature)
STANDARD
SENSOR
Pt-50 IEC 60751
Pt-100 IEC 60751
Pt-500 IEC 60751
Pt-1000 IEC 60751
Ni-50 DIN 43760
RTD
Ni-100 DIN 43760
Ni-120 DIN 43760
Ni-200 DIN 43760
Ni-500 DIN 43760
Ni-1000 DIN 43760
B
E
J
K
IEC 60584
N
T/C
R
S
T
L
DIN 43710
U
mV
ohm
If the input type and scale is not specified while ordering, factory settings are;
Input Type : Pt-100, and Scale : 0-200°C.
Electromagnetic Compatibility:
The E-KC-100 meets the requirements of
TS EN 61326-1.
KY-KC101-0224-1
E-KC-101 converter conta ns; the
M easuring Accuracy
LOWER
TOP MINIMUM
LIMIT
LIMIT SCALE
-200°C 840°C 25°C ±0.50°C
-200°C 840°C 25°C ±0.25°C
-200°C 840°C 25°C ±0.25°C
-200°C 840°C 25°C ±0.25°C
-60°C 180°C 25°C ±0.25°C
-60°C 180°C 25°C ±0.25°C
-60°C 180°C 25°C ±0.25°C
-60°C 180°C 25°C ±0.25°C
-60°C 180°C 25°C ±0.25°C
-60°C 180°C 25°C ±0.25°C
100°C 1800°C 100°C ±2.00°C
-200°C 840°C 50°C ±0.50°C
-200°C 1120°C 50°C ±0.50°C
-200°C 1360°C 50°C ±0.50°C
-200°C 1300°C 50°C ±0.50°C
-40°C 1760°C 100°C ±1.00°C
-40°C 1760°C 100°C ±1.00°C
-200°C 400°C 50°C ±0.50°C
-200°C 900°C 50°C ±0.50°C
-200°C 600°C 50°C ±0.50°C
-200mV 1000mV 25mV ±0.075mV
500  50 
0 W ±0.50°C
Converter , user manual and guarantee
2.2. General Specifications
Ele ctrical
Supply Voltage
Voltage Drop
Isolation Voltage, Test
Isolation Voltage, Operation
Environmental Conditions:
Operating Temperature
Max. Permissible Humidity
Protection Class
Calibration Temp.
Mechanical:
Dimensions
Weight (approx.)
Connection Cables
Resistance Thermometer (RTD) / Resistance Input:
Sensor Connection Test
ACCURACY
A/D D/A
Maximum Wire Resistance
2-Wire Compensation
Resistance
Measurement Current
Error Signaling
Thermocouple (TC) / mV Input:
Input Impedance
Maximum Wire Resistance
Cold Junction
Compensation (CJC)
±0.1%
Error Signaling
Span
Output:
Output Signal
Load Resistance
Malfunction Indication
Output Update
Operating Influences:
Ambient Temperature
CJC Error (For TC Inputs)
EMC Immunity
Other:
Warm-Up Time
Damping (Configurable)
Memory
:
9.0 - 36 V DC
9.0 V
1.0 kV AC
50 V AC
-20°C to +70°C
< 95% RH
IP00
25°C ±3°C
Ø 44.0 mm x 21.5 mm
40 g
Max. 1.5 mm² (AWG 16)
2-Wire, 3-Wire, 4-Wire
(Configurable)
50 
Maximum 100 Ω
(Configurable)
< 150 µA
Wire Break, Short Circuit
> 10 M
500 
Constant, Internal NTC,
External Pt-100 (Configurable)
Wire Break
4 - 20 mA or 20 - 4 mA
< ((Vsupply - 9) / 0.021) 
3.8 mA or 21.0 mA
(Configurable)
10 per second
< ± 0.01% / °C
< ± 1.0 °C
< ± 0.5% Span
5 minutes
0 to 60 seconds
(Configurable)
Maximum Write-Erase
Operation: 10.000 times
KY-KC101-0224-1
(with no condensation)
