PARTS AND FEATURES Bowl Clamping Plate Beater Shaft Beater Height Adjustment Screw Bowl** (not shown) Pouring Shield* Speed Control Lever 3 L Stainless Steel Bowl* Motor Head Pastry Beater* and Scraper Attachment Hub Flat Beater Attachment Knob Flex Edge Beater* Motor Head Locking Lever Wire Whip (not shown)
Stand Mixer to the nearest Authorised Service Facility for examination, repair, or electrical or mechanical adjustment. 10. The use of attachments/accessories not recommended or sold by KitchenAid may cause fire, electric shock, or injury. 11. Do not use the appliance outdoors.
ELECTRICAL REQUIREMENTS Power: 300 W MAX for 5KSM125 - 5KSM195 Series 275 W MAX for 5K45, 5KSM45, 5KSM95 Series Voltage: 220-240 V~ Frequency: 50-60 Hz NOTE: If the plug does not fit in the outlet, contact a qualified electrician. Electrical Shock Hazard Do not modify the plug in any way.
SPEED CONTROL GUIDE SPEED ACTION ATTACHMENT DESCRIPTION For slow stirring, combining, mashing, starting all mixing Flat Beater, procedures. Use to add flour and STIR Flex Edge dry ingredients to batter and to add Beater* liquids to dry ingredients. Do not use Speed 1 to mix or knead yeast doughs.
ACCESSORY GUIDE ACCESSORY USES Cakes, creamed frostings, candies, Flat Beater and Flex Edge Beater* for cookies, pie pastry, biscuits, meat loaf, normal to heavy mixtures mashed potatoes Eggs, egg whites, heavy cream, boiled Wire Whip for mixtures that need air frostings, sponge cakes, mayonnaise, incorporated some candies...
Page 7
PRODUCT ASSEMBLY LIFTING/LOWERING THE MOTOR HEAD To put down Motor Head: Push the To lift Motor Head: Push the locking lever locking lever to UNLOCK and gently bring to the UNLOCK position and lift the head. the head down. The locking lever will Once lifted, the lever will automatically go automatically go back in LOCK position back in LOCK position to keep the head...
PRODUCT ASSEMBLY To remove accessory: Repeat steps 1 and 2. Press accessory upward as far as possible and turn to the left. Then pull accessory from the Beater Shaft. BEATER TO BOWL CLEARANCE Your Stand Mixer is adjusted at the factory so the Flat Beater just clears the bottom of the Bowl.
Page 9
PRODUCT ASSEMBLY PLACING/REMOVING THE POURING SHIELD* To place Pouring Shield*: Turn speed From the front of the Stand Mixer, slide control to “0” (OFF). Unplug Stand Mixer. the Pouring Shield* over the Bowl until Attach your chosen accessory. See the the shield is centred.
PRODUCT ASSEMBLY USING THE POURING SHIELD* Use the Pouring Shield* to avoid having ingredients splashing out of the Bowl when mixing, as well as to easily pour ingredients in the Bowl while mixing. For best results, rotate the shield so the Motor Head covers the U-shaped gap in Pour the ingredients into the Bowl the shield.
PRODUCT USAGE OPTIONAL ATTACHMENTS KitchenAid offers a wide range of optional attachments such as food grinders or pasta makers. They may be attached to the Stand Mixer attachment power shaft, as shown here. Loosen Attachment Knob by turning it To attach: Turn speed control to counterclockwise.
Page 12
PRODUCT USAGE Loosen Attachment Knob by turning it To remove: Turn speed control to counterclockwise. Rotate attachment “0” (OFF). Unplug Stand Mixer. slightly back and forth while pulling out. Replace Attachment Hub cover. Tighten Attachment Knob by turning it clockwise. NOTE: See the Use and Care Guide of each specific attachment for recommended speed settings and operating times.
CARE AND CLEANING IMPORTANT: Allow the appliance to cool completely before putting on or taking off parts, and before cleaning the appliance. Electrical Shock Hazard Plug into an earthed outlet. Do not remove earth prong. Always be sure to unplug Stand Mixer before cleaning.
