- Page 1 HSH728155M, HSG72.1..M, HSG72.054M Free standing cooker [en] Instructions for installation and use...
- Page 3 Ú Table of contents [ en ] Ins t r u c t i o n s f o r i n s t a l l a t i o n a n d u s e INSTRUCTION MANUAL ............4 Energy and environment tips ..........
- Page 4 INSTRUCTION MANUAL Safety precautions Please read this instruction manual carefully. This will enable ã= Risk of scalding! you to operate your appliance safely and correctly. Never pour water into the hot cooking compartment. This will Keep the instruction manual and assembly instructions in a produce hot steam.
- Page 5 Cooking on gas burners releases extra heat and moisture. Faults in the gas installation/smell of gas ■ Adjacent units may become damaged over time. For long If you notice a smell of gas or faults in the gas installation, you cooking times, switch on the cooker hood or ventilate the must room.
- Page 6 Your new appliance Get to know your appliance. You will find information about the Model HSG728155M: control panel and hob, as well as the oven, types of heating and accessories. HSG727155M, HSG727125M, HSG723054M, HSG728155M and HSH728155M Details may vary, depending on the appliance model. Model HSG727155M, HSG727125M or HSG723054M: Explanation Splatter guard...
- Page 7 The control panel Control knob for hotplates Explanation This control knob is used to adjust the heat setting of the gas Function button for oven lighting burner hotplates. Function button for rotary spit The symbol above the control knob shows the gas burner to which the control knob belongs.
- Page 8 The oven Function button for rotary spit This function button is used to switch the rotary spit on and off. Gas burners Setting Meaning Accessories The accessories can be inserted into the oven at 5 different Explanation levels. Grill gas burner (2.0 kW) You can pull out the accessories two thirds of the way without them tipping.
- Page 9 This compartment can be used to store hob or oven The storage compartment accessories. Open the storage compartment by folding down the fascia ã= panel. Risk of fire! Never leave combustible items in the storage compartment. Your new appliance Get to know your appliance. You will find information about the control panel and hob, as well as the oven, types of heating and accessories.
- Page 10 The control panel Control knob for hotplates Explanation This control knob is used to adjust the heat setting of the gas Function button for oven lighting burner hotplates. Function button for rotary spit The symbol above the control knob shows the gas burner to which the control knob belongs.
- Page 11 The oven Function button for rotary spit This function button is used to switch the rotary spit on and off. Gas burners Setting Meaning Accessories The accessories can be inserted into the oven at 5 different Explanation levels. Grill gas burner (2.0 kW) You can pull out the accessories two thirds of the way without them tipping.
- Page 12 This compartment can be used to store hob or oven The storage compartment accessories. Open the storage compartment by folding down the fascia ã= panel. Risk of fire! Never leave combustible items in the storage compartment. Your new appliance Get to know your appliance. You will find information about the control panel and hob, as well as the oven, types of heating and accessories.
- Page 13 The control panel Control knob for hotplates Explanation This control knob is used to adjust the heat setting of the gas Function button for oven lighting burner hotplates. Function button for rotary spit The symbol above the control knob shows the gas burner to which the control knob belongs.
- Page 14 You can pull out the accessories two thirds of the way without The oven them tipping. This allows meals to be removed easily. Gas burners The accessories may become deformed when they become hot. As soon as they have cooled down, the deformation Explanation disappears with no effect on the function.
- Page 15 Before using the oven for the first time In this section, you can find out what you must do before using Press the control knob for the grill, turn it anti-clockwise to — your gas oven or gas hob to prepare food for the first time. position and keep the control knob pressed for a few Read the Safety information section beforehand.
- Page 16 Switching off the gas burner Operating electric hotplates Û Turn the control knob for the required hotplate to position For model HSG725154M: If the flame goes out Make sure that the hotplates are dry before use. Switch off the control knob. Wait for one minute and repeat Switching on the hotplate steps 1 to 3.
- Page 17 Using the combination mode Using the rotary spit The rotary spit can be used to cook joints such as rolled joints Tips on using the combination mode and poultry with excellent results. The meat is roasted Please note the following points when using the combination thoroughly and evenly.
- Page 18 Remove the rotary spit as follows: Switching on the rotary spit Press the function button for rotary spit mode. Carefully open the appliance door. Carefully remove the rotary spit from the holder. The button simply locks into place and operation starts. Switching off the rotary spit Press the function button for rotary spit mode.
- Page 19 Hook the other end into the holder. If the flame goes out Switch off the control knob. Wait one minute and switch the burner on again. ã= Risk of fire! If the flame goes out, gas will escape. Never leave the gas burner unattended during operation.
- Page 20 How to use the timer The timer runs independently of the oven. Elapsed cooking time An audible signal sounds once the time has elapsed. Setting the duration Turn the control knob once round clockwise, as far as the limit stop, and then turn it anti-clockwise to set it to the required time.
- Page 21 Close the appliance door a little further. Area Cleaning agents Lift the door upwards and at an angle to remove it. Door panels ã= Risk of injury! The lower edge of the door may have sharp edges. Clean the door and glass panels with care.
- Page 22 Cleaning the hook-in racks Cleaning the hook-in racks Clean the hook-in racks with washing-up liquid and a sponge or You can remove the hook-in racks for easier cleaning. brush. The hook-in racks are all fixed to the side walls of the cooking compartment at four points.
- Page 23 Screw the glass cover of the oven light bulb back on. Replacing the oven light bulb Remove the tea towel and switch the circuit breaker back on. If the oven light bulb fails, it must be replaced. Replacement heat-resistant bulbs can be obtained from the after-sales Press the function button the oven lighting until it locks into service or from specialist retailers.
- Page 24 Tested for you in our cooking studio. Here you will find a selection of dishes and the ideal settings for Boiling and frying them. We will show you which type of heating and which Cookware temperature are best suited for your dish. You can find information about suitable accessories and the height at which For dishes which require a lot of liquid, use deep-sided pots ■...
- Page 25 The bottom of a fruit flan is too light. Place the cake one level lower the next time. The fruit juice overflows. Next time, use the deeper universal pan, if you have one. Small baked items made out of yeast There should be a gap of approx.
- Page 26 For model HSG728155M, HSG727155M, HSG727125M, HSG725154M, HSG723054M or HSH728155M: Dish Shelf height Operating mode Temperature in °C Preheating Cooking time time in minutes in minutes — Toast — Beef rissoles, 6 x 100 g — Steak, 5 x 150 g —...
- Page 27 INSTALLATION INSTRUCTIONS Safety precautions Read and store these instructions carefully. Safe use can only When installing the appliance you must observe the building be guaranteed if the appliance has been installed by a regulations that are currently applicable and the regulations set professional and in accordance with these assembly by the local electricity and gas suppliers (e.g.
- Page 28 Appliance dimensions Adjacent units Take note of the specified dimensions. Adjacent units must be made of non-combustible material. Adjacent unit fronts must be heat-resistant up to at least 90 °C. HSG727155M, HSG727125M, HSG725154M: If the appliance is installed close to other kitchen units, you A=95-160 mm;...
- Page 29 Guidelines for ventilation This appliance may only be set up in a sufficiently ventilated Please note that the air volume required for combustion must room and according to the applicable regulations and not be below 2 m³/h per kW of power (see kW total power on ventilation requirements.
- Page 30 Loosen the screw contacts. Install a mains cable. Note: The cable must comply with the specifications in the section "Type of mains cable". < Connect the yellow-green wire to terminal ( Note: This wire must be at least 10 mm longer than the other wires.
- Page 31 Installing the safety valve Checking for leaks The installation of a safety valve for opening and closing the After connecting the gas line, check the connections for leaks gas supply is a compulsory requirement. Fit the safety valve using soapy water. between the gas supply line to the appropriate room and the appliance.
- Page 32 Through the gas tap opening in the control panel, loosen the Oven burner internal setting screw. Replacing the nozzles Remove the removable floor of the oven by undoing the 2 screws at the front and pulling the floor out upwards and towards the front.
- Page 33 To reassemble, follow the instructions in the reverse order Through the gas tap opening in the control panel, loosen the and pay attention to the 4 screws in the back wall of the internal setting screw. cooking compartment when inserting the removable floor. Replace the control knob and heat the oven for 15 minutes.
- Page 34 General nozzle table Type of gas mbar Nozzle Type of burner Output (W) Consumption max. Number Bypass Natural gas 115Y High output burner 3,000 286 l/h Standard burner 1750 167 l/h Economy burner 1000 95 l/h 130k Wok burner 3600 343 l/h Oven burner 4300...
- Page 36 Robert Bosch Hausgeräte GmbH Carl-Wery-Straße 34 81739 München Germany www.bosch-home.com *9000722962* 911130 9000722962...
