Instructions–Parts List
Gun Washer Kit
For air–assisted electrostatic guns, to clean exterior gun surfaces
and interior fluid passages without getting solvent into the air
passages or turbine. For professional use only.
See page 2 for kit part numbers and descriptions.
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
See manual 308393 for complete gun washer
warnings and instructions.
Observe all warnings. Read and understand all instruction manuals before operating equipment.
To reduce the risk of serious injury, including splashing fluid or solvent in the eyes or on the skin, shut off the air to
the pump, relieve all system pressure, and drain the solvent from the gun washer tank before installing the kit.
WARNING
308411D
Model 24P675 Shown
EN
TI20641a
Advertisement
Table of Contents
Related Manuals for Graco 24P675 Shown
Summary of Contents for Graco 24P675 Shown
- Page 1 Read all warnings and instructions in this manual. Save these instructions. See manual 308393 for complete gun washer warnings and instructions. Model 24P675 Shown TI20641a WARNING Observe all warnings. Read and understand all instruction manuals before operating equipment. To reduce the risk of serious injury, including splashing fluid or solvent in the eyes or on the skin, shut off the air to...
- Page 2 Models Gun Washer Kit Air–Assisted Electrostatic Spray Gun Part No. 236659 PRO AA4500 Part No. 245271 PRO Xs4 AA Part No. 24P675 Pro Xp AA 308411...
-
Page 3: Installation
Installation Install Gun Support, Trigger Lock, and Fluid Inlet Adapter 1. Relieve the gun washer system pressure. 2. Remove a gun support (A) or spray nozzle (B) from one of the four cleaning stations. See Fig. 1. NOTE: To ease removal of the spray nozzle, re- move the metal platform from the gun washer tank. - Page 4 PRO AA4500 Gun Install Air Cap Blank and Tip Housing 3. Using the parts from the kit, press the two washers (3) into the tip housing (2) and press the tip hous- WARNING ing into the air cap blank (1). See Fig. 5. 4.
-
Page 5: Parts List
PRO AA4500 Gun 11. Place the gun in its hanging bracket, with the WARNING nozzle pointing down as shown in Fig. 7, until it is used again. To reduce the risk of electrostatic shock, fire, or explosion; which could result in serious injury and property damage, be sure to follow these precautions. - Page 6 PRO Xs4 AA Gun Install Air Cap Blank and Tip Housing 3. Using the parts from the kit, press the two washers (3) into the tip housing (2) and press the tip hous- WARNING ing into the air cap blank (1). See Fig. 9. 4.
- Page 7 PRO Xs4 AA Gun 11. Place the gun in its hanging bracket, with the WARNING nozzle pointing down as shown in Fig. 11, until it is used again. To reduce the risk of electrostatic shock, fire, or explosion; which could result in serious injury and property damage, be sure to follow these precautions.
- Page 8 Pro Xp AA Gun Install Air Cap Blank and Tip Housing 3. Using the parts from the kit, press the washer (3) into the air cap blank (1). See Fig. 13. WARNING 4. Install the kit parts on the gun. Tighten the retain- To reduce the risk of serious injury, including ing nut (E) until the air cap blank (1) is snug.
- Page 9 Pro Xp AA Gun 11. Place the gun in its hanging bracket, with the WARNING nozzle pointing down as shown in Fig. 15, until it is used again. To reduce the risk of electrostatic shock, fire, or explosion; which could result in serious injury and property damage, be sure to follow these precautions.
-
Page 10: Graco Standard Warranty
Graco distributor to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
