TriTech motion detector
ISW-ZDL1-WP11G
Pet friendly
Animaux acceptés
≤ 10
en Installation and Operation Guide
1
Optional mounting brackets / Support de
montage en option: B328, B335, B338
6
5 sec
11
90 sec
Green
Vert
Yellow
Jaune
Red
Rouge
© 2013 Bosch Security Systems, Inc.
1 ≤ 45 kg (100 lbs)
2 ≤ 27 kg (60 lbs)
2
7
Refer to the instruction manual that came with the
control panel to complete the pairing process.
Reportez-vous aux instructions fournies avec le
panneau de commande pour terminer le processus
<3 min
d'appariement
12
=
12
=
12
=
13
2.2 - 2.7 m
(7.5 - 9 ft)
3
4
8
9
80 sec
13
9
6x 1.5 V
Duracell MN1500 AA Alkaline
131 mm
Panasonic AM-3PIX AA Alkaline
(5.2 in)
0°C to +49°C
51 mm
67 mm
(+32°F to +120°F)
(2.0 in)
(2.6 in)
0 - 93% Non-Condensing humidity
5
2 sec
10
2 sec
15 sec
10 sec
14
F.01U.284.862 | 02 | 2013.09 | 1
15
