Contents
- Buzzer sounds/Indicator on
- If the outboard motor was submerged
- Emergency gear shifting
This troubleshooting guide is for reference purposes and
supplements the owner's manual that came with your
outboard motor. Always refer to the Owner's manual for
clarification and more detail on the processes shown in this
document.
Photos in this guide may not match your actual model.
It is recommended that you download this PDF and store it in
your device.
Web instruction manual, Official owner's manual PDF
available at:
https://www.hondappsv.com/
Troubleshooting Guide
BF300A, BF350A
EN
Advertisement
Related Manuals for Honda BF300A
Summary of Contents for Honda BF300A
- Page 1 Troubleshooting Guide BF300A, BF350A Contents - Buzzer sounds/Indicator on - If the outboard motor was submerged - Emergency gear shifting This troubleshooting guide is for reference purposes and supplements the owner’s manual that came with your outboard motor. Always refer to the Owner’s manual for clarification and more detail on the processes shown in this document.
- Page 2 Buzzer sounds/Indicator on Warning System Activation Engine Oil Pressure Warning System Informs low engine oil pressure with indicator and buzzer sounds. Overheat Warning System Informs engine overheats with indicator and buzzer sounds. Multi-function Display Low oil pressure indicator (red)+Buzzer continuously on Overheat indicator (red)+Buzzer continuously on The power reduction system decreases the engine speed to protect the engine until the malfunction is...
- Page 3 Buzzer sounds/Indicator on PGM-FI Warning System Informs PGM-FI malfunction with indicator and buzzer sounds. ACG Warning System Informs AC generator malfunction with indicator and buzzer sounds. Multi-function Display PGM-FI Indicator (red) +Buzzer continuously on (at long intervals) ACG Indicator (red) +Buzzer continuously on (at long intervals)
-
Page 4: Warning Level
Buzzer sounds/Indicator on Water Separator Warning System Informs water contamination in the water separator with buzzer sounding (at short intervals). Warning Level Warning level is shown as the warning system activates. ・Warning Level 1: an errors that require special attention ・Warning Level 2: except Level 1 warnings Power reduction This outboard motor is equipped with the power... - Page 5 Buzzer sounds/Indicator on Battey switch notification This function alerts the operator that the battery switch is OFF and must be turned to the ON position. If the battery switch is OFF, a buzzer will sound three times during the following situations. When starting the engine When using the power trim/tilt switch When turning the battery switch OFF while the...
-
Page 6: Overheat Warning System
If the overheat warning system stays activated, stop the engine. Tilt up the outboard motor and check the water intakes for obstructions. If there are no obstructions at the water intakes, return to the closest boat landing and contact your closest authorized Honda outboard motor dealer. - Page 7 Check the battery. If the battery is OK, consult with an authorized Honda outboard motor dealer. PGM-FI warning system Consult with an authorized Honda outboard motor dealer. When the water separator buzzer sounds Check the water separator for water contamination.
- Page 8 If the outboard motor was submerged A submerged outboard motor must be serviced immediately after it is recovered from the water in order to minimize corrosion. As soon as possible, take the outboard motor to a Honda outboard motor dealer for inspection and service.
- Page 9 Emergency gear shifting If the gear cannot be shifted, perform shift operation manually according to the following procedures and return to your base at possible engine speed. 1. Set the shift lever or remote control lever to the neutral position. Stop the engine.
- Page 10 Emergency gear shifting Insert the phillips screwdriver with the grip of the tool kit into the hole of the shift actuator. 5. Shift gear into neutral by moving the shaft. - Grasp the shaft of the inserted Phillips screwdriver close to the shift pivot. Operate in a stable posture that makes it easy to apply force.
