VANITY SPECIFICATIONS
VANITY COMPONENTS
Model VG09042KM
MODEL VG09042KM
FEATURES
PACKING LIST
Vanity Assembly
Mirror
Sink
For warranty purposes contact our toll free number:
TOLL FREE: (866) 591 - 7792
E-Mail: techmail@vigoindustries.com
www.vigoindustries.com
DIMENSIONS
MODEL #
VANITY
WIDTH
VG09042KM
47 5/8"
42 1/2"
47 5/8"
VANITY
VANITY
HEIGHT
DEPTH
33 1/2"
18 1/4"
3/4"
18 1/4"
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for VIGO VG09042KM
Summary of Contents for VIGO VG09042KM
- Page 1 VANITY SPECIFICATIONS VANITY COMPONENTS Model VG09042KM MODEL VG09042KM FEATURES PACKING LIST Vanity Assembly Mirror Sink DIMENSIONS MODEL # VANITY VANITY VANITY WIDTH HEIGHT DEPTH VG09042KM 47 5/8" 33 1/2" 18 1/4" For warranty purposes contact our toll free number: 42 1/2"...
-
