VANITY SPECIFICATIONS
VANITY COMPONENTS
Model VG09040KM
MODEL VG09040KM
FEATURES
PACKING LIST
Vanity Assembly
Mirror
Sink
For warranty purposes contact our toll free number:
TOLL FREE: (866) 591 - 7792
E-Mail: techmail@vigoindustries.com
www.vigoindustries.com
DIMENSIONS
MODEL #
VANITY
WIDTH
VG09040KM
24"
18 7/8"
24"
VANITY
VANITY
HEIGHT
DEPTH
33 3/4"
18 1/4"
3/4"
18 1/4"
Advertisement
Table of Contents
Related Manuals for VIGO VG09040KM
Summary of Contents for VIGO VG09040KM
- Page 1 VANITY SPECIFICATIONS VANITY COMPONENTS Model VG09040KM MODEL VG09040KM FEATURES PACKING LIST Vanity Assembly Mirror Sink DIMENSIONS MODEL # VANITY VANITY VANITY WIDTH HEIGHT DEPTH VG09040KM 24" 33 3/4" 18 1/4" For warranty purposes contact our toll free number: 18 7/8"...
-
Page 2: Front View
22 7/8" 12 5/8" wood support open area 3/4" shelf drawer 3/4" 19 5/8"" 1 5/8" 1 5/8" BACK VIEW SIDE VIEW dimensions with out sink top (where applicable) MODEL VG09040KM THE MEASUREMENTS IN INCHES ARE ROUNDED TO THE NEAREST 1/8"... - Page 3 Open space for Rough-In Plumbing Should be at the same height as the center of the 2"x6" Backing Material 3/4" shelf drawer 3/4" 19 5/8"" FLOOR 1 5/8" BACK VIEW MODEL VG09040KM THE MEASUREMENTS IN INCHES ARE ROUNDED TO THE NEAREST 1/8"...
-
Page 4: Prepare Site
NOTICE: Siliconized acrylic caulk must be used to secure the lavatory to the vanity. Do not use 100% silicone sealant, which will damage the finish of the vanity. Observe all local plumbing and building codes. Two people should install this product. Vigo Industries reserves the right to make revisions in the design of products without notice, as specified in the Price List. -
Page 5: Installation
Always consult your licensed contact with any questions or concerns. Handle with care. Vitreous china/Glass/Acrylic can break or chip if the product is 4. Connect Trap to drain assembly. Vigo recommends installing the Vigo brand handled carelessly. corresponding sink and pop up. Figure #4 depicts the complete assembly of the Prior to installation, unpack the new vanity components and inspect it for Vigo brand sink, vanity and pop up. - Page 6 When installing your faucet it is highly recommended to remove the top drawer. This will allow you to have access to the hollow pin and supply lines of the faucet in order for you to complete your installation. Vigo brand vanities have two typical styles for the drawer assembly. Vigo offers multiple methods for removal of the drawers.
- Page 7 For commercial uses, additional limitations apply. VIGO warrants the Product to be free from defects in workmanship and materials under normal use and service for a period of five (5) years from the initial date of purchase by the owner or end-user, contractor, or builder, from VIGO or an authorized VIGO dealer.
