Kaboodle W-62000 Installation Manual

step 2
Follow these
instructions to
install your parts
and accessories.
Things you need to know
• Always read the full instructions prior to installation.
• Consider possible obstructions to your parts and accessories,
like hinges inside the cabinet or adjacent cabinet doors and
handles, prior to installation.
• Make sure you leave plumbing and electrical work
to qualified trades people. Never try this yourself.
• Make sure you always use safety gear like a mask, ear muffs
and glasses when using tools.
• This hardware is designed to be installed in cabinets with
either a left hand or right hand open set up.
• Tip: After marking out the pre-drill holes as per the
instructions, take the part that is to be installed and align
Hardware included
A B
basket frame x 1 base frame x 1
G H
large spanner x 1
M
handle screw x 2
Tools you will need
To put your kaboodle kitchen accessory together you will need the following tools.
Cordless drill with:
Spirit level
(optional) • Number 2 screw tip
• 2mm drill bit
C
large basket x 2
I
short bolt x 6 front support rail x 1
Tape
measure
blind corner pullout baskets
the appropriate holes with the markings to ensure they
match up prior to pre-drilling the holes.
• If you have any questions, contact us on:
Australia: 1800 666 078 Monday to Friday between
8:00am and 6:00pm AEST, New Zealand: 0800 522 663
Monday to Friday between 8:00am and 5:00pm NZST
or email: info@kaboodlegroup.com.au
• Note: Illustrations found in this installation guide serve as a
reference and may vary when compared to the actual product.
D
base frame cover x 2
J
fixing screws x 12
Screw
Pencil driver
installation guide
E F
allen key x 1 small spanner x 1
K L
short basket x 2
Adjustable
Safety
square
gear
handle x 2
Clamps
(optional)
