  • Page 1 Change for life Service Manual GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI...
  • Page 2 1. Summary Indoor Unit: A1(Blue) A1(White) A1(Silver) A1(Champagne) Outdoor Unit: GWH09AUCXB-K6DNA1A/O GWH18AUDXD-K6DNA1A/O GWH12AUCXB-K6DNA1A/O GWH24AUDXF-K6DNA1A/O Technical Information...
  • Page 3 Remote Controller: YAA1FB18(WiFi) Model list: Indoor Outdoor Remote Model Product code Indoor model Outdoor model product code product code Controller GWH09AUCXB-K6DNA1A CB575000300 GWH09AUCXB-K6DNA1A/I CB575N00300 GWH09AUCXB-K6DNA1A/O CB575W00300 GWH09AUCXB-K6DNA1A CB575000302 GWH09AUCXB-K6DNA1A/I CB575N00302 GWH09AUCXB-K6DNA1A/O CB575W00300 GWH09AUCXB-K6DNA1A CB575000303 GWH09AUCXB-K6DNA1A/I CB575N00303 GWH09AUCXB-K6DNA1A/O CB575W00300 GWH09AUCXB-K6DNA1A CB575000304 GWH09AUCXB-K6DNA1A/I CB575N00304 GWH09AUCXB-K6DNA1A/O CB575W00300 GWH09AUCXB-K6DNA1A CB575000301 GWH09AUCXB-K6DNA1A/I CB575N00300 GWH09AUCXB-K6DNA1A/O CB575W00301 GWH12AUCXB-K6DNA1A CB575000200 GWH12AUCXB-K6DNA1A/I CB575N00200 GWH12AUCXB-K6DNA1A/O CB575W00200 GWH12AUCXB-K6DNA1A CB575000202 GWH12AUCXB-K6DNA1A/I CB575N00202 GWH12AUCXB-K6DNA1A/O CB575W00200...

  • Page 4: Specification Sheet

    2. Specifications 2.1 Specification Sheet Model GWH09AUCXB-K6DNA1A GWH09AUCXB-K6DNA1A CB575000300/CB575000302 Product Code CB575000301 CB575000303/CB575000304 Rated Voltage 220-240 220-240 Power Rated Frequency Supply Phases Power Supply Mode Outdoor Outdoor Cooling Capacity 2700 2700 Heating Capacity 3000 3000 Cooling Power Input Heating Power Input Cooling Current Input Heating Current Input Rated Input...
  • Page 5 Outdoor Unit Model GWH09AUCXB-K6DNA1A/O(LCLH) GWH09AUCXB-K6DNA1A/O(LC) Outdoor Unit Product Code CB575W00300 CB575W00301 ZHUHAI LANDA COMPRESSOR ZHUHAI LANDA COMPRESSOR Compressor Manufacturer CO.,LTD CO.,LTD Compressor Model QXF-A082zC170 QXF-A082zC170 Compressor Oil ZE-G;ES RB68GX or equivalent ZE-G;ES RB68GX or equivalent Compressor Type Rotary Rotary Compressor LRA. 15.00 15.00 Compressor RLA...
  • Page 6 Model GWH12AUCXB-K6DNA1A GWH12AUCXB-K6DNA1A CB575000200/CB575000202 Product Code CB575000201 CB575000203/CB575000204 Rated Voltage 220-240 220-240 Power Rated Frequency Supply Phases Power Supply Mode Outdoor Outdoor Cooling Capacity 3510 3510 Heating Capacity 3810 3810 Cooling Power Input Heating Power Input Cooling Current Input Heating Current Input Rated Input 1650 1650...
  • Page 7 Outdoor Unit Model GWH12AUCXB-K6DNA1A/O(LCLH) GWH12AUCXB-K6DNA1A/O(LC) Outdoor Unit Product Code CB575W00200 CB575W00201 ZHUHAI LANDA COMPRESSOR ZHUHAI LANDA COMPRESSOR Compressor Manufacturer CO., LTD CO., LTD Compressor Model FTz-AN108ACBD FTz-AN108ACBD Compressor Oil FW68DA or equivalent FW68DA or equivalent Compressor Type Rotary Rotary Compressor LRA. Compressor RLA 4.40 4.40...
  • Page 8 Model GWH18AUDXD-K6DNA1A GWH18AUDXD-K6DNA1A CB575000100/CB575000102 Product Code CB575000101 CB575000103/CB575000104 Rated Voltage 220-240 220-240 Power Rated Frequency Supply Phases Power Supply Mode Outdoor Outdoor Cooling Capacity 5300 5300 Heating Capacity 5350 5350 Cooling Power Input 1582 1582 Heating Power Input 1393 1393 Cooling Current Input Heating Current Input Rated Input...
  • Page 9 Outdoor Unit Model GWH18AUDXD-K6DNA1A/O(LCLH) GWH18AUDXD-K6DNA1A/O(LC) Outdoor Unit Product Code CB575W00100 CB575W00101 ZHUHAI LANDA COMPRESSOR ZHUHAI LANDA COMPRESSOR Compressor Manufacturer CO.,LTD CO.,LTD Compressor Model QXF-A120zH170A QXF-A120zH170A Compressor Oil FW68DA or equivalent FW68DA or equivalent Compressor Type Rotary Rotary Compressor LRA. 18.00 18.00 Compressor RLA 5.00...
  • Page 10 Model GWH24AUDXF-K6DNA1A GWH24AUDXF-K6DNA1A CB437004700/CB437004702 Product Code CB437004701 CB437004703/CB437004704 Rated Voltage 220-240 220-240 Power Rated Frequency Supply Phases Power Supply Mode Outdoor Outdoor Cooling Capacity 7100 7100 Heating Capacity 7300 7300 Cooling Power Input 2030 2030 Heating Power Input 1870 1870 Cooling Current Input Heating Current Input Rated Input...
  • Page 11 Outdoor Unit Model GWH24AUDXF-K6DNA1A/O(LCLH) GWH24AUDXF-K6DNA1A/O(LC) Outdoor Unit Product Code CB437W04700 CB437W04701 ZHUHAI LANDA COMPRESSOR ZHUHAI LANDA COMPRESSOR Compressor Manufacturer CO.,LTD CO.,LTD Compressor Model QXFS-M180zX170 QXFS-M180zX170 Compressor Oil Compressor Type Rotary Rotary Compressor LRA. 24.00 24.00 Compressor RLA 3.50 3.50 Compressor Power Input 1350 1350 Compressor Overload Protector...

  • Page 12: Capacity Variation Ratio According To Temperature

    2.2 Capacity Variation Ratio According to Temperature Heating operation ambient temperature range is -15ºC~30ºC Cooling Heating 9/12K 9/12K Condition Indoor:DB27°C WB19°C Conditions Indoor air flow: High Indoor:DB20°C Pipe length:5m Indoor air flow:Super High Pipe length:5m -15 -10 -5 10 15 20 25 30 35 40 45 50 Heating operation ambient temperature range is -25ºC~30ºC Cooling Heating...

  • Page 13: Cooling And Heating Data Sheet In Rated Frequency

    2.3 Cooling and Heating Data Sheet in Rated Frequency Cooling: Pressure of gas pipe connecting Inlet and outlet pipe temperature of Rated cooling condition(°C) (DB/WB) indoor and outdoor unit heat exchanger Fan speed of Fan speed of Model indoor unit outdoor unit Indoor Outdoor...

  • Page 14: Outline Dimension Diagram

    3. Outline Dimension Diagram 3.1 Indoor Unit Φ55 Φ55 Model (-The first three characters) 707.5 157.5 Technical Information...

  • Page 15: Outdoor Unit

    3.2 Outdoor Unit GWH09AUCXB-K6DNA1A/O GWH12AUCXB-K6DNA1A/O Unit:mm GWH18AUDXD-K6DNA1A/O Unit:mm Technical Information...
  • Page 16 GWH24AFE-K6DNA2I/O Unit:mm Technical Information...

  • Page 17: Refrigerant System Diagram

    4. Refrigerant System Diagram Outdoor unit Indoor unit Gas pipe side Valve 4-Way valve Di s charge Heat Suction Accumlator exchanger Compressor (evaporator) Heat exchanger Liquid pipe (condenser) side Valve Strainer Capillary Strainer COOLING HEATING Connection pipe specification: Liquid pipe:1/4" Gas pipe:3/8"...

  • Page 18: Function And Control

    6. Function and Control 6.1 Remote Controller Introduction Introduction for icons on display screen Introduction for buttons on remote controller NOTE: ● This is a general use remote controller. It could be used for the air conditioner with multifunction. For the functions which the model doesn't have, if press the corresponding button on the remote controller, the unit will keep the original running status.
  • Page 19 ● Hold " " button above 2s to set your required swing angle. button When reaching your required angle, release the button. This button is used for setting Fan Speed in the sequence that NOTE: ● Press this button continuously more than 2s, the main unit will goes from AUTO, , then back to Auto.
  • Page 20 clean it once every three months. After the auto clean function is button turned on, you can leave the room. When auto clean is finished, Press this button under cooling mode can select 25 C(77 F) fast the air conditioner will enter standby status. ●...

  • Page 21: Function Introduction For Combination Buttons

    Under off status, press "MODE" and "WiFi" buttons simultaneously for 1s, WiFi module will restore factory settings. NOTE: ● This function is only available for some models. When selecting " " (Auto LED) with remote controller, LED indicator on indoor unit will adjust the luminance automatically Function introduction for combination buttons according to the ambient intensity of illumination.
  • Page 22 function function is for limiting power of the whole unit. Press "SLEEP" and "MODE" buttons simultaneously, the remote controller will circularly display as the following: ● Maximum power limited under the mode is lower than that of mode. ● If you want to cancel the power limiting function, press the button till the icon in remote controller is not displayed.

  • Page 23: Operating Systems

    GREE+ App Download Linkage Scan the QR code or search "GREE+" in the application market to download and install it. When "GREE+" App is installed, register the account and add the device to achieve long-distance control and LAN control of Gree smart home appliances.
  • Page 24 6.3 Ewpe Smart App Operation Manual Control Flow Chart Internet Cloud intelligent Cellular/ Home Wi-Fi home Other Wi-FI appliances Home wireless router Home Wi-Fi Operating Systems Requirement for User's smart phone: iOS system Android system Support iOS7.0 and Support Android 4.4 and above version above version Download and installation...
  • Page 25 6.4 Brief Description of Models and Functions ●Indoor Unit General timer and clock timer functions are compatible by 1.Basic function of system equipping remote controller with different functions. (1)Cooling mode (6) Memory function (1) Under this mode, fan and swing operates at setting status. memorize compensation temperature, off-peak energization value.
  • Page 26 After power recovery, compressor can only be started up after C, compressor stops operation and outdoor fan will stop 30s 180+T s at least. later. Indoor fan will be in residual-heat blowing status. ④ When unit is turned off under heating mode or changed to other (13) SE control mode The unit operates at SE status.

  • Page 27: Notes For Installation And Maintenance

    7. Notes for Installation and Maintenance Safety Precautions: Important! 12. Make sure all wires and pipes are connected properly and the valves are opened before energizing. 13. Check if there is electric leakage on the unit body. If yes, Please read the safety precautions carefully before please eliminate the electric leakage.

  • Page 28: Safety Precautions For Installing And Relocating The Unit

    Safety Precautions for Installing and Relocating the Unit: To ensure safety, please be mindful of the following precautions. WARNINGS 1. When installing or relocating the unit, be sure to 5.When installing the unit, make sure that connection keep the refrigerant circuit free from air or substances pipe is securely connected before the compressor other than the specified refrigerant.

  • Page 29: Installation Notes

    has running fire (such as fire source,working coal gas ware, Safety Precautions for Refrigerant operating heater). ●It is not allowed to drill hole or burn the connection pipe. ●To realize the function of the air conditioner unit, a special ●The air conditioner must be installed in a room that is larger refrigerant circulates in the system.

  • Page 30: Safety Instructions For Transportation And Storage

    ●The refrigerant should be recycled into the specialized surveyed to make sure that there are no flammable hazards or storage tank. ignition risks. “ NO Smoking ” signs shall be displayed. ●Ventilated area Filling the refrigerant ●Use the refrigerant filling appliances specialized for R32. Ensure that the area is in the open or that it is adequately Make sure that different kinds of refrigerant wont contaminate ventilated before breaking into the system or conducting any hot...
  • Page 31 ●Removal and evacuation terminals not made to original specification, damage to seals, incorrect fitting of glands, etc. When breaking into the refrigerant circuit to make repairs – or Ensure that the apparatus is mounted securely. for any other purpose –conventional procedures shall be used. Ensure that seals or sealing materials have not degraded to the However, for flammable refrigerants it is important that best point that they no longer serve the purpose of preventing the...
  • Page 32 JF00305011 GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI Add: West Jinji Rd, Qianshan, Zhuhai,Guangdong, China, 519070 Tel: (+86-756) 8522219 Fax: (+86-756) 8669426 E-mail: global@cn.gree.com For product improvement, specifications and appearance in this manual are subject to change without prior notice.
