This Owner's Manual is provided and hosted by Appliance Factory Parts.
Charbroil 461410908
Owner's Manual
Shop genuine replacement parts for Charbroil
461410908
Find Your Charbroil Grill Parts - Select From 3592 Models
-------- Manual continues below --------

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 461410908 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Thermos 461410908

Summary of Contents for Thermos 461410908

  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. Charbroil 461410908 Owner's Manual Shop genuine replacement parts for Charbroil 461410908 Find Your Charbroil Grill Parts - Select From 3592 Models -------- Manual continues below --------...
  • Page 2 MODEL 461410908 • PRODUCT GUIDE THIS GRILL IS FOR OUTDOOR USE ONLY. THIS GRILL IS FOR NATURAL GAS USE ONLY. CAUTION: WARNING: Read and follow all safety statements, assembly Failure to follow all manufacturer's instructions instructions, and use and care directions before could result in serious personal injury and/or attempting to assemble and cook.

  • Page 3: For Your Safety

    See rating label on grill for serial number. CAUTION: Indicates a potentially hazardous situation which, Date Purchased if not avoided, may result in minor or moderate injury. CAUTION For residential use only. Do not use for commercial cooking. 2 • 461410908...

  • Page 4: Table Of Contents

    California to cause cancer, birth defects, and other reproductive harm. 2. This product contains chemicals, including lead and lead compounds, known to the State of California to cause cancer, birth defects or other reproductive harm. Wash your hands after handling this product. 461410908 • 3...

  • Page 5: Use And Care

    The socket should be left attached to the gas source (house plumber with a copy of these instructions. Incorrect piping). Figure C, on the following page, shows properly connection can result in a gas leak with possibility of fire. connected hose and socket. 4 • 461410908...
  • Page 6 Order new parts by giving the serial, model number and name hoses should be used with this grill. of items needed to the Grill Service Center at 1-800-435-5194. 6. Always close gas source after performing leak test. 461410908 • 5...
  • Page 7 (3) foot clearance from walls or rails. Do not use on or under balconies. • NEVER attempt to light burner with lid closed. A buildup of non-ignited gas inside a closed grill is hazardous. 6 • 461410908...

  • Page 8: Ignitor Check

    Do not close lid when Hose Check using griddle. • Before each use, check to see Griddle if hoses are cut, worn or kinked. Grid Replace damaged hoses before using grill. Use only Normal Kinked hose specified by manufacturer. Hose Hose 461410908 • 7...

  • Page 9: Spider Alert

    To prevent flashbacks and ensure good performance the burner and venturi assembly should be removed from the grill and cleaned before use whenever the grill has been idle for an extended period. Heat Tents Burner tubes correctly engaged in valves Carry-Over Tube Valve Burner Burner Tube 8 • 461410908...

  • Page 10: Storing Your Grill

    Outdoor Cooking Collection and Design™, Patio Bistro™, PrecisionFlame™, Pro-Check™, QuickSet Grills and Design™, SmokerTents™, The Big Easy™, The Minute Grill™, The Edge™, The Tuscan Collection™, and The Urban Grill™ are Trademarks of the W.C. Bradley Company. Universal Grill Parts and Design™ is a trademark of the Thermos Company and its affiliates.

  • Page 11: Routine Care

    ** Do not let stainless steel cleaners come in contact with painted or plastic surfaces as damage may occur. ROUTINE CARE ROUTINE CARE STUBBORN STAINS AND RUST Char-Broil® Stainless Steel Char-Broil® Stainless Steel Char-Broil® Stainless Restoration Kit Grill Cleaner Grill Wipes 10 • 461410908...

  • Page 12: Parts List

    PARTS LIST – Model No. 461410908 Key Qty. Description....Part # Key Qty. Description ....Part # EE 1 Front Panel .

  • Page 13: Parts Diagram

    PARTS DIAGRAM – Model No. 461410908 Estimated assembly time: 30 minutes. NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from those on your particular grill model. However, the method of assembly remains the same.

  • Page 14: Assembly

    ASSEMBLY – Model No. 461410908 CAUTION: Ends of screws have sharp points A Place bottom shelf on table or grill container. B Insert tabs on short leg assembly into bottom shelf. C Attach leg assembly with two screw on each side.
  • Page 15 B Slide wheel and wheel spacer onto axle rod. Insert assembly into large hole in bottom shelf. Attach other wheel, wheel spacer, washer and hitch pin. Stand cart upright. 1” Hitch Pin Wheel Spacer Flat Washer Qty: 1 Qty: 2 Qty: 1 Turn cart upside down Hub on wheel faces into grill bottom 14 • 461410908...
  • Page 16 C Attach rail and legs with two screws in each corner. #10-16 X 1/2" Self-Tap Screw Qty: 10 A Place tabs on front panel beside leg tabs. B Insert push pins into front panel and legs. Push Pin Qty: 2 461410908 • 15...
  • Page 17 B With the lid closed, carefully lower the grill head onto the cart. Open lid and attach four screws inside grill bottom and into casting seat. #10-24 X 3/8" Machine Screw Qty: 2 #10-16 X 3/4" Self-Tap Screw Fiber Washer Qty: 4 Qty: 4 16 • 461410908...
  • Page 18 B Fascia tabs must insert into 2 slots in front of shelf, then slide towards leg. C Fasten fascia with 1 screw into second hole through control panel and leg. D Hook "S" hooks into holes on right shelf. #10-16 X 1/2" Self-Tap Screw Qty: 5 461410908 • 17...
  • Page 19 D Place bezel onto side valve and attach with #8-32x3/8” screws. Qty: 2 #10-16x1/2" #10-24 Self-Tap Screw Wing Nut Qty: 5 Qty: 2 Sideburner Body Sideburner Drip Pan Note position of holes in the pan. Fascia Bezel #8-32x 3/8” Machine Screw Qty: 2 18 • 461410908...
  • Page 20 C Place sideburner grid and griddle onto sideburner body Sideburner #10-24 Sideburner Clip Wing Nut Qty: 1 Qty:2 Sideburner tube and valve properly engaged. Sideburner Clip Long Ignitor Wire NOTE: Remove grid from sideburner before using griddle. 461410908 • 19...
  • Page 21 C Note correct position to hold ignitor button. Push button onto ignitor module and turn right 1/4 turn to lock in place. D Attach condiment basket to front panel. Insert push pin into condiment basket. Turn 1/4 Back of button Correct position Push Pin Qty: 1 20 • 461410908...
  • Page 22 See Use & Care section for important safety instructions. Please read “Connecting Your Grill to the Natural Gas Source”, “Leak Test”, and “Burner Flame Check” before using grill. Grease Tray Grease Clip Grease Cup 461410908 • 21...

  • Page 23: Troubleshooting - Electronic Ignition

    • Electrodes are wet. • Has moisture accumulated • Use paper towel to remove moisture. on electrode and/or in burner ports? • Electrodes cracked or • Inspect electrodes for • Replace cracked or broken electrodes. broken “sparks at cracks. crack”. 22 • 461410908...

  • Page 24: Gas Issues

    • Reconnect wires or replace electrode/wire assembly. • Wires are loose or disconnected. • Wires are shorting (sparking) between • Replace ignitor wire. ignitor and electrode. • Dead battery. • Replace with a new AAA-size alkaline battery. 461410908 • 23...

  • Page 25: Troubleshooting

    • Grease buildup or food particles in • Clean carry-over tube(s) with wire brush. light from other end(s) of carryover tube(s). burner(s). Burner does not carry • Grease buildup in ports • Clean ports of burner. flame around to other side. 24 • 461410908...

  • Page 26: Warranty

    Consumer returns will not be accepted unless a valid Return Authorization is first acquired by calling 1-800-435-5194 and then clearly marked on the outside of the package and the package is shipped freight/postage pre-paid to the address above. 461410908 • 25...
  • Page 27 Page intentionally blank 26 • 461410908...

  • Page 28: Registration Card

    Merci d’avoir bien voulu remplir ce questionnaire. Vos réponses nous aideront et aideront d’autres compagnies à vous communiquer des offres spéciales susceptibles de vous intéresser. Si vous préférez ne pas recevoir d’informations concernant ces offres spéciales, veuillez cocher ici 461410908 • 27...

  • Page 29: Do Not Return This Product To The Store

    STOP Should you encounter a problem with our product CALL US FIRST Do not return this product to the store. WE CAN HELP GRILL SERVICE CENTER 1-800-435-5194 HOURS 8AM-6PM EST Mon-Fri Please ensure your warranty registration is complete. Grilling Safety Checklist Read and understand owners manual.
