- Page 1 Anleitung RT_SP_260_260_D_SPK1:_ 17.09.2010 7:24 Uhr Seite 1 Original operating instructions Planer Thicknesser RT-SP 260 Art.-Nr.: 41.990.02 I.-Nr.: 11012...
- Page 2 Anleitung RT_SP_260_260_D_SPK1:_ 17.09.2010 7:24 Uhr Seite 2 Read and follow the operating instructions and safety information before using for the first time.
- Page 3 Anleitung RT_SP_260_260_D_SPK1:_ 17.09.2010 7:24 Uhr Seite 3 44 24...
- Page 4 Anleitung RT_SP_260_260_D_SPK1:_ 17.09.2010 7:25 Uhr Seite 4...
- Page 5 Anleitung RT_SP_260_260_D_SPK1:_ 17.09.2010 7:25 Uhr Seite 5...
- Page 6 Anleitung RT_SP_260_260_D_SPK1:_ 17.09.2010 7:25 Uhr Seite 6...
- Page 7 Anleitung RT_SP_260_260_D_SPK1:_ 17.09.2010 7:25 Uhr Seite 7...
- Page 8 Anleitung RT_SP_260_260_D_SPK1:_ 17.09.2010 7:25 Uhr Seite 8 35/36...
- Page 9 Anleitung RT_SP_260_260_D_SPK1:_ 17.09.2010 7:26 Uhr Seite 9...
- Page 10 Anleitung RT_SP_260_260_D_SPK1:_ 17.09.2010 7:26 Uhr Seite 10...
- Page 11 Anleitung RT_SP_260_260_D_SPK1:_ 17.09.2010 7:26 Uhr Seite 11...
- Page 12 Anleitung RT_SP_260_260_D_SPK1:_ 17.09.2010 7:26 Uhr Seite 20 41 Pointer Important! 42 Thicknessing table When using the equipment, a few safety precautions 43 Plastic spring must be observed to avoid injuries and damage. 44 Feeding roller Please read the complete operating instructions and 45 Belt cover safety regulations with due care.
- Page 13 6. Noise emission values Sound and vibration values were measured in accordance with EN 61029. RT-SP 260 Operation Idle speed Sound pressure level L 94.8 dB(A) 80.7 dB(A) Sound power level L 104.8 dB(A) 91.1 dB(A)
- Page 14 Anleitung RT_SP_260_260_D_SPK1:_ 17.09.2010 7:26 Uhr Seite 22 7. Technical data of the RT-SP 260 that the machine’s moving parts run smoothly. Check that the voltage on the rating plate is the same as your supply voltage before you connect AC motor: 230 V ~ 50 Hz the machine to the power supply.
- Page 15 Anleitung RT_SP_260_260_D_SPK1:_ 17.09.2010 7:26 Uhr Seite 23 9.6 Fitting the parallel stop (Fig. 19) 10. Using the plane Slide the parallel stop (6) into the parallel stop guide (32) and fasten it with the ratchet lever (16). 10.1 Using the switches (Fig. 3) Item A: Surfacing mode 9.7 Fitting the transport handles (Fig.
- Page 16 Anleitung RT_SP_260_260_D_SPK1:_ 17.09.2010 7:26 Uhr Seite 24 11.2 Removing the planing table (Fig. 39/40) 14. Changing the place of To remove the planing table (14), follow the above installation (Fig. 49) instructions in section 9.4 in reverse order. Lift the machine with the aid of the transportation 11.3 Turning the chip housing over (Fig.
- Page 17 Anleitung RT_SP_260_260_D_SPK1:_ 17.09.2010 7:26 Uhr Seite 25 15.3 Cleaning and maintenance Clean dust off the drive gear unit of the thicknessing plane with a brush or compressed air. Lubricate all clamping points and chains at regular intervals with a few drops of engine oil. Keep the belt (46) free of oil and grease at the same time, however.
- Page 18 EH 05/2012 (01)
- Page 19 EH 05/2012 (01)
- Page 20 The Einhell Express Guarantee is valid for a period of 2 years starting from the purchase date of the product. Claims made under the Einhell Express Guarantee should be submitted before the end of this guarantee period and within two weeks of the defect being noticed.
