Power Max 826 OTE Snowthrower
Model No. 37777-Serial No. 315000001 and Up
WARNING
CALIFORNIA
Proposition 65 Warning
This product contains a chemical or chemicals
known to the State of California to cause cancer,
birth defects, or reproductive harm.
The engine exhaust from this product
contains chemicals known to the State of
California to cause cancer, birth defects,
or other reproductive harm.

Introduction

This machine is intended to be used by residential
homeowners or professional, hired operators. It is
designed for removing snow from paved surfaces, such
as driveways and sidewalks, and other surfaces for
traffic on residential or commercial properties. It is not
designed for removing materials other than snow, nor is
a model with a pivoting scraper designed for clearing off
gravel surfaces.
Read this information carefully to learn how to operate and
maintain your machine properly and to avoid injury and
machine damage. You are responsible for operating the
machine properly and safely.
You may contact Toro directly at www.Toro.com for machine
and accessory information, help finding a dealer, or to register
your machine.
Whenever you need service, genuine Toro parts, or additional
information, contact an Authorized Service Dealer or Toro
Customer Service and have the model and serial numbers of
your machine ready. Figure 1 identifies the location of the
model and serial numbers on the machine. Write the numbers
in the space provided.
© 2014-The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
This manual identifies potential hazards and has safety
messages identified by the safety alert symbol (Figure 2),
which signals a hazard that may cause serious injury or death
if you do not follow the recommended precautions.
This manual uses 2 words to highlight information.
Important calls attention to special mechanical information
and Note emphasizes general information worthy of special
attention.
Contents
Introduction .................................................................. 1
Safety ........................................................................... 2
Setup ............................................................................ 7
Register at www.Toro.com.
g018884
Figure 1
1. Model and serial number location
Model No.
Serial No.
Figure 2
1. Safety alert symbol
Training ................................................................. 3
Preparation............................................................. 3
Operation............................................................... 3
Clearing a Clogged Discharge Chute .......................... 4
Maintenance and Storage.......................................... 4
Toro Snowthrower Safety ......................................... 4
Safety and Instructional Decals ................................. 5
Original Instructions (EN)
All Rights Reserved *3385-232* A
Printed in the USA
Form No. 3385-232 Rev A
Operator's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 37777 and is the answer not in the manual?

Questions and answers

Summary of Contents for Toro 37777

  • Page 1: Table Of Contents

    You are responsible for operating the Figure 2 machine properly and safely. 1. Safety alert symbol You may contact Toro directly at www.Toro.com for machine and accessory information, help finding a dealer, or to register your machine. This manual uses 2 words to highlight information.
  • Page 2: Safety

    1 Installing the Upper Handle........7 Maintenance ..............19 2 Installing the Traction Control Linkage ....8 Recommended Maintenance Schedule(s) ......19 3 Installing the Chute ..........9 ................20 4 Installing the Chute Control Rod ......10 Preparing for Maintenance........20 5 Connecting the Wire to the Headlight......10 Checking the Engine Oil Level .........20 6 Checking the Engine Oil Level .......11 Checking and Adjusting the Skids and...
  • Page 3: Training

    • Improperly using or maintaining this machine could Never attempt to make any adjustments while the engine result in injury or death. To reduce this potential, is running (except when specifically recommended by comply with the following safety instructions. manufacturer). •...
  • Page 4: Clearing A Clogged Discharge Chute

    Run the machine a few minutes after throwing snow to prevent freeze-up of the rotor blades. Toro Snowthrower Safety The following list contains safety information specific to Toro machines or other safety information that you must know. • Rotating auger/impeller can amputate or injure fingers or hands.
  • Page 5: Safety And Instructional Decals

    Safety and Instructional Decals Important: Safety and instruction decals are located near areas of potential danger. Replace damaged decals. 121–6817 1. Cutting dismemberment, impeller and cutting dismemberment, auger hazards—keep bystanders a safe distance from the snowthrower. 121–6823 1. Fast 3. Slow 2.
  • Page 6 Briggs & Stratton Part No. 273676 3. Fast 1. Stop 2. Slow Briggs & Stratton Part No. 277588 1. Primer 3. Ignition key out Briggs & Stratton Part No. 275949 (Engine—Stop) 1. Choke on (Choke) 2. Choke off (Run) 2. Ignition key in (Engine—Run) Briggs &...
  • Page 7: Setup

    Setup Loose Parts Use the chart below to verify that all parts have been shipped. Procedure Description Qty. Handle bolts Curved washers Install the upper handle. Locknuts Hairpin cotter Install the traction control linkage. Flat washer Carriage bolt Install the chute. Flat washer Carriage bolts Install the chute control rod.
  • Page 8: Installing The Traction Control Linkage

    Installing the Traction Control Linkage g019378 Figure 6 Parts needed for this procedure: Hairpin cotter 6. Pull up on the speed control rod and insert the trunnion Flat washer into the hole in the speed selector lever (Figure 5). Note: If the trunnion does not fit into the hole Procedure when you lift up on the speed control rod, rotate the trunnion upward or downward on the speed control...
  • Page 9: Installing The Chute

    Installing the Chute Parts needed for this procedure: Carriage bolt Flat washer Procedure 1. Place the chute on the frame and the align the discharge chute mount to the chute support. g019379 Figure 8 1. Carriage bolt 3. Nut 2. Flat washer 2.
  • Page 10: Installing The Chute Control Rod

    Installing the Chute Control Parts needed for this procedure: Carriage bolts Locknuts Procedure g018885 1. Unwrap the Quick Stick and rotate it so that it is Figure 10 upright and in the center. 2. Hold the blue trigger cap down and pull the lever fully 5.
  • Page 11: Connecting The Wire To The Headlight

    Engine Oil Capacities Model Engine Oil Capacity 37777 18 to 20 oz. (0.53 to 0.59 l) 1. Remove the dipstick and slowly pour oil into the oil fill tube to raise the oil level to the Full mark on the G016761 dipstick.
  • Page 12: Checking The Tire Pressure

    1. Start the engine; refer to Starting the Engine. 2. Move the speed selector to Position R1; refer to Operating the Speed Selector. 3. Squeeze the left hand (traction) lever to the hand-grip Checking the Tire Pressure (Figure 15). No Parts Required Procedure The tires are overinflated at the factory for shipping.
  • Page 13: Product Overview

    Product Overview Figure 18 1. Snow cleanout tool (attached to the handle) Operation Note: Determine the left and right sides of the machine from the normal operating position. Freewheeling or Using the Self-propel Drive g018887 You can operate the snowthrower with the self-propel feature engaged or disengaged (freewheeling).
  • Page 14 approved for use. Never use gasoline that contains more than 10% ethanol by volume, such as E15 (contains 15% ethanol), E20 (contains 20% ethanol), or E85 (contains up to 85% ethanol ). Using unapproved gasoline may cause performance problems and/or engine damage which may not be covered under warranty.
  • Page 15: Starting The Engine

    Starting the Engine 1. Check the engine oil level. Refer to Checking the Engine Oil Level in Maintenance. 2. Turn the fuel shutoff valve 1/4 turn counterclockwise to open it (Figure 22). g018891 Figure 22 Figure 24 3. Insert the ignition key (Figure 23). 5.
  • Page 16: Stopping The Engine

    Stopping the Engine 1. Move the throttle to the Slow position, and then to the Stop position (Figure 28). g018893 Figure 27 1. Electric-starter button 3. Recoil starter Figure 28 2. Electric starter plug-in Note: To use the electric starter, connect a power 2.
  • Page 17: Operating The Speed Selector

    (refer to Checking and Adjusting the Traction Cable) or take the machine to an Authorized Service Dealer for service. Important: To operate the traction drive, you must operate the machine with the self-propel feature engaged. Refer to Freewheeling or Using the Self-propel Drive.
  • Page 18: Unclogging The Discharge Chute

    Moving the Discharge Chute Unclogging the Discharge Chute Hold the blue trigger cap down and move the Quick Stick to the left to move the discharge chute to the left; move the Quick Stick to the right to move the discharge chute to the WARNING right (Figure 34).
  • Page 19: Operating Tips

    Yearly or before storage • Have an Authorized Service Dealer inspect and replace the traction drive belt and/or the auger/impeller drive belt, if necessary. Important: You can find more information about maintaining and servicing your machine at www.Toro.com.
  • Page 20: Preparing For Maintenance

    Important: Refer to your engine operator's manual for additional maintenance procedures. For engine adjustments, repairs, or warranty service not covered in this manual, contact an Authorized Briggs & Stratton Servicing Dealer. Checking and Adjusting the Service Interval: Before each use or daily Skids and Scraper Preparing for Maintenance Service Interval: Yearly—Check the skids and the scraper...
  • Page 21: Checking And Adjusting The Traction Cable

    Checking and Adjusting the 4. Tighten the jam nut (Figure 39), ensuring there is slight tension on the cable. Traction Cable 5. If the traction cable is properly adjusted but a problem remains, contact an Authorized Service Dealer. Service Interval: After the first 2 hours—Inspect the traction cable and adjust it if necessary.
  • Page 22: Checking The Auger Gearbox Oil Level

    EP gear oil lubricant to the gearbox until the oil level is 3/8 inch below the filler opening. Model Engine Oil Capacity 37777 18 to 20 oz. (0.53 to 0.59 l) Note: Do not use synthetic oil. 6. Install the pipe plug in the gearbox.
  • Page 23: Lubricating The Hex Shaft

    Lubricating the Hex Shaft 9. Install the back cover and return the machine to the operating position. Service Interval: Yearly—Lubricate the hex shaft. Lightly lubricate the hex shaft yearly with automotive engine Replacing the Spark Plug oil (Figure 45). Service Interval: Yearly—Replace the spark plug. Use a Champion QC12YC or equivalent spark plug.
  • Page 24: Adjusting The Discharge Chute Latch

    Adjusting the Discharge Chute Latch If the discharge chute does not lock into the desired position or does not unlock so that you can move it to another position, adjust the discharge chute latch. 1. Loosen the clamp fastener on the chute support plate until the cable is free.
  • Page 25 Figure 55 Figure 51 6. Insert the wire connector straight into the back of the headlight until it is securely in place (Figure 56). 2. Turn the base of the bulb counterclockwise until it stops (Figure 52). Figure 52 3. Remove the bulb straight out from the back of the headlight (Figure 53).
  • Page 26: Storage

    Storage WARNING • Gasoline vapors can explode. • Do not store gasoline more than 30 days. • Do not store the machine in an enclosure near an open flame. • Allow the engine to cool before storing it. Preparing the Machine for Storage 1.
  • Page 27: Troubleshooting

    Troubleshooting Problem Possible Cause Corrective Action Electric starter does not turn (electric-start 1. The power cord is disconnected at the 1. Connect the power cord to the outlet models only) outlet or the machine. and/or the machine. 2. The power cord is worn, corroded, or 2.
  • Page 28 5. Unclog the discharge chute. 6. The auger/impeller drive belt is loose 6. Install and/or adjust the auger/impeller or is off the pulley. drive belt; refer to www.Toro.com for servicing information or take the machine to an Authorized Service Dealer.
  • Page 29 Notes:...
  • Page 30: Emission Control Warranty Statement

    Such use will not reduce the warranty obligations of The Toro Company. 10. Add-on or modified parts that are not approved by The Toro Company may not be used. The use of a non-approved add-on or modified parts by the purchaser will be grounds for disallowing a warranty claim.
  • Page 31 1. Fuel System Parts • Carburetor and internal parts • Cold starting enrichment (primer or choke) • Fuel pump • Fuel line, fittings, and clamps • Fuel tank, cap, and tether • Carbon canister 2. Air Induction System • Air cleaner •...
  • Page 32: The Toro Total Coverage Guarantee

    Countries Other than the United States or Canada Customers who have purchased Toro products exported from the United States or Canada should contact their Toro Distributor (Dealer) to obtain guarantee policies for your country, province, or state. If for any reason you are dissatisfied with your Distributor's service or have difficulty obtaining guarantee information, contact the Toro importer.
