Neopost iX-3 Series Quick Installation Manual

iX-3 Series
Quick Installation Guide
Mailing System components :
Feeding Table
1
Unpack all components from the box, remove packaging
and any transit tape.
5
Lift Mailing System slightly on the left hand side and align the hooks to attach the
Feeding Table (b) – attach the Catch Tray to the right hand side of the Mailing System
(c).
9
Installation Process
1 LAN
OK
Mem
Select LAN and press 'OK' to test connection type.
For more help with your installation, please visit:
Mailing
System Base
Catch Tray
2
Lift the cover of the Mailing System to
reveal the Ink Cartridge (h) and Meter
locations.
6
Lower Integrated Weighing Platform release panel
at rear of the Mailing System. Place Integrated
Weighing Platform
System and slide forward to lock. Lift panel to
secure and clip cable into place.
10
Installation Process
Press the 'Next' to start the
Online service
declaration.
Next
Mem
Complete the declaration by following the screen.
support.neopost.com/ix3_install_us
Integrated Weighing Platform
3
Open the cover. Place the Meter (i) into the meter compartment and
(i)
push backwards until it snaps into position. Close the cover.
7
Connect the Integrated Weighing Platform
COM PORT on the rear of the Mailing System. Then connect the
(e) on top of the Mailing LAN Cable (f) and Power Cable
System.
11 12
Headset alignment
A C E G I K
Select letter with arrows
and press «OK»
B D F H J
Follow steps to complete alignment test.
Press the
LAN Cable
Power Cable
4
Insert the Ink Cartridge (h)
'TOP' and 'LOCK' stickers facing upwards. Push the Ink Cartridge
towards the back of the Mailing System until you hear a 'click' - close the
cover of the Mailing System.
(e) connector into the
(g) to either side of the Mailing
13
Amount
Postage Available
$ 100.00
Enter amount:
$ 10
Mem
Your Mailing System is now ready to use. Please turn over
button to add funds.
for your Quick User Guide.
Ink Meter
Cartridge
at an angle into the Mailing System with the
(h)
8
Turn on the Mailing System using the switch
behind the Power Cable (g) and follow the steps
on screen.
