HPE Aruba Networking
AP-600H-MNT1 Mount Kit
Installation Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the Enterprise Aruba AP-600H-MNT1 and is the answer not in the manual?

Questions and answers

Summary of Contents for HP Enterprise Aruba AP-600H-MNT1

  • Page 1 HPE Aruba Networking AP-600H-MNT1 Mount Kit Installation Guide...
  • Page 2 Copyright Information © Copyright 2023 Hewlett Packard Enterprise Development LP. Open Source Code This product includes code licensed under certain open source licenses which require source compliance. The corresponding source for these components is available upon request. This offer is valid to anyone in receipt of this information and shall expire three years following the date of the final distribution of this product version by Hewlett Packard Enterprise Company.
  • Page 3: Package Contents

    Chapter 1 AP-600H-MNT1 Mount Kit AP-600H-MNT1 Mount Kit The AP-600H-MNT1 mount kit is for securing a supported access point to a single-gang wall box or a flat surface. Package Contents Table 1: Package Contents Item Quantity AP-600H-MNT1 Mount bracket #6-32 x 1 Phillips drive screw M2.5 x 14 T8H security type tamper proof Torx screw M2.5 x 6.5 T8H security type tamper...
  • Page 4 Chapter 2 Installation Installation Installation with Wall Box To mount an access point on a wall box, follow these steps: 1. If the wall box is not already exposed, unscrew and remove the existing wall plate. Figure 1 Removing Existing Wall Plate 2.
  • Page 5 4. Screw the mount bracket onto the wall box using the two #6-32x1 Philips screws. Figure 2 Attaching Mount Bracket to Single-gang Wall Box 5. Route an active Ethernet cable to the E0 port located on the back of the access point. Make sure the Ethernet cable is in the groove on the bottom of the access point.
  • Page 6 Figure 3 Routing Ethernet Cable 6. Align the slots and holes on the back of the access point against the guide posts and slots on the mount bracket, and then slide the access point down to attach the access point to the mount bracket.
  • Page 7 Figure 4 Aligning Slots and Holes on Access Point with Mount Bracket and Slide Down 7. Insert and fasten the M2.5 x 14 T8H Torx screw or the M2.5 x 6.5 T8H Torx screw to the security screw hole on the access point . The M2.5 x 14 T8H Torx screw and the M2.5 x 6.5 T8H Torx screw are provided for defferent access points.
  • Page 8 Figure 5 Fastening T8H Torx Screw to Security Screw Hole 8. (Optional) If the access point requires a DC power adapter, a power cable may be inserted into the socket located on the side of the access point. Installation on Flat Surface To mount an access point to a flat surface, follow these steps: 1.
  • Page 9 4. Screw the two wood screws into the plastic anchors to secure the mount bracket against the wall. Figure 6 Screwing Mount Bracket Directly to Solid Wall 5. Repeat the step 5 to step 8 in the Installation with Wall Box section to complete the installation.
