- Page 1 HP 9000 D Class Enterprise Servers A4838A Mounting Kit Guide for HP A3764A and HP A3765A Cabinets Part No. A3764-90003 Edition 1 - September 1997 E0997 Printed in: USA...
-
Page 2: Legal Notices
Legal Notices The information in this document is subject to change without notice. Hewlett-Packard makes no warranty of any kind with regard to this manual, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. -
Page 3: Printing History
D Class family of computers. The procedures in this guide are intended for trained and experienced HP field service personnel. At the time of publication, this family of computers included the following models:... - Page 4 Preface-iv...
- Page 5 A4838A Kit Contents Introduction The HP 9000 D2xx and D3xx Enterprise Class of servers can be mounted into an A3764A or A3765A cabinet to consolidate the pieces of the core system. The cabinet is offered as a factory integrated cabinet (A3764A) with one to four D Class computers mounted, or a field integrated (A3765A) cabinet with no computers mounted by the factory.
-
Page 6: Required Tools
Introduction Required Tools Required Tools Before beginning the installation process, make sure you have the necessary tools. • Standard hand tools. • T10, T15, and T25 Torx driver. D Class Mounting Procedures Before starting any of the following procedures, be sure the D Class computer has been recently backed up. - Page 7 Introduction D Class Mounting Procedures Figure 1-1 Carrier Tray Mounting Diagram 6. Align the tray carrier over the extended rails so that the four mounting holes match those in the rails and the alignment pins on the rails match the tray. Insert the four mounting screws from the bottom of the rails, give the mounting screws a few turns, but do not tighten at this time.
- Page 8 Introduction D Class Mounting Procedures 9. Remove the five screws holding the skid plate on the front end of the chassis. Refer to Figure 1-2. This plate is not needed on the computer when it is mounted in the cabinet. Figure 1-2 Skid Plate WARNING The next step requires at least two CEs to lift the computer.
- Page 9 Introduction D Class Mounting Procedures Figure 1-3 D Class Mounting Diagram 11.From the front, insert two screws up through the bottom of the tray into the computer chassis. 12.From the back insert three mounting screws through the tray tabs into the computer chassis.
- Page 10 Introduction D Class Mounting Procedures If the D Class computer installed into the cabinet has a power select switch CAUTION (located on the back of the computer), be sure it is set to the 220V setting. 13.From the bottom, firmly tighten the four screws attaching the tray and computer to the rail assemblies ( from Figure 1-1).
- Page 11 Introduction D Class Mounting Procedures a. Hook the tabs on the top of the bezel into the slots along the top, front of the chassis , and swing the bezel downward. b. Push the bottom of the bezel against the chassis until the bezel snaps into place.
- Page 12 Introduction D Class Mounting Procedures Chapter 1...
