KID Trax Tough Toddler Quad KT1575AZ Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Owner's Manual
Age: 18–30 months
Weight: Maximum 44 lbs (20 kg)
Maximum Speed: 1.5 MPH
KT1575AZ / KT1585AZ / KT1591AZ
Battery: 6 volt
Tough Toddler Quad
Made in China
Styles and colors may vary.
WARNING
This manual contains important safety and use
information. Keep this manual for future reference.
• An adult must read this entire manual
• Adult supervision is required at all times

Advertisement

loading
Need help?

Need help?

Do you have a question about the Tough Toddler Quad KT1575AZ and is the answer not in the manual?

Questions and answers

Related Manuals for KID Trax Tough Toddler Quad KT1575AZ

Summary of Contents for KID Trax Tough Toddler Quad KT1575AZ

  • Page 1 Owner's Manual Age: 18–30 months Weight: Maximum 44 lbs (20 kg) Maximum Speed: 1.5 MPH KT1575AZ / KT1585AZ / KT1591AZ Battery: 6 volt Tough Toddler Quad Made in China Styles and colors may vary. WARNING This manual contains important safety and use information.
  • Page 2 Safety WARNING FAILURE TO FOLLOW THE SAFETY INSTRUCTIONS LISTED BELOW MAY RESULT IN SERIOUS INJURY OR DEATH. The owner’s manual contains assembly, use and maintenance instructions. Child Safety Warnings • Adults supervising children must read and understand this • Riding a motorized ride-on toy can be a dangerous activity, entire manual before allowing any child to use this product.
  • Page 3 WARNING Battery and Charging Warnings The following safety hazards may result in serious injury or death to the user of the ride-on: • Do not mix old and new batteries. • Contact between the positive and negative terminals may result in fire or explosion. Avoid direct contact between the •...

  • Page 4: Parts Checklist

    Parts Checklist Pre-Ride Safety Checklist To be performed by a supervising adult Part name Before every ride, it is important to carry out the following safety checks. Do not ride a battery-powered ride-on toy that is Handlebar cover not in proper working condition! Replace any worn or broken parts as needed.
  • Page 5 Parts Before you begin assembling, check that all parts listed are present..
  • Page 6 Assembly: Install the gearbox and rear axle ❶ Remove the battery cover. • Remove the gearbox from the interior of the battery compartment ❷ Insert the gearbox into the opening of the rear wheel well. ❶ ❷ ❸ Insert the rear axle. ❹...
  • Page 7 Attach the wire connectors and rear wheels ❺ Connect the white wire connectors. ❻ Connect the red wire connectors. ❼ Re-attach the battery cover. ❼ ❺ ❻ ❽ Attach the rear wheels • Slide a washer and wheel onto each end of the axle. Note: The gear wheel inserts into the gearbox •...
  • Page 8 Assembly: Install the front axle and front wheels ❶ Install the front axle. • Remove the nuts and washers from the ends of the axles. • Using the small end of the wrench remove the bolt, washers and nut from the axle ❶...
  • Page 9 Attach the handlebar assembly, fender, engine block and seat ❶ Attach the Handlebars. ❷ • Insert the steering column down the center of the handlebar opening and through the front axle • Insert a washer over the end of the steering column and fasten with the nut.
  • Page 10 WARNING • The battery contains hazardous material that may cause • A damaged supply cord, connector, or charger could cause serious injury or death if handled, connected, or charged burns to the skin, an electrical fire, serious injury, death, or improperly.
  • Page 11 Controls and Functions Headlights turn on with the power button Press the pedal to accelerate On/Off button Lift foot off pedal to stop...

  • Page 12: Maintenance

    Maintenance Battery Replacement and Disposal This ride-on toy contains a sealed lead acid The battery will eventually lose the ability to hold a charge. Depending on the amount of use, and varying conditions, the NON SPILLABLE BATTERY. This battery must be recycled.
  • Page 13 Service Do not return this product to the place of purchase. If your ride-on protection against harmful interference in a residential installation. toy needs service, repairs or replacement parts, call: This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the Pacific Cycle Consumer Relations instructions, may cause harmful interference to radio Hours: 8:00 am –...

  • Page 14: Warranty Limitations

    To make a claim under this warranty you must contact us at www.kidtraxtoys.com; fax us at 1-800-858-2800, 24 hours a day; write to Kid Trax Consumer Relations Department, Kid Trax Toys,P.O. Box 344 Olney, IL 62450 or call 1-877-741-6154 from 8 a.m.
