- Page 1 E10-433MS1W User Manual SI4463 433MHz 1W SMD Wireless Module...
-
Page 2: Table Of Contents
Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MS1W User Manual Contents Disclaimer....................................2 1 Overview..................................... 3 1.1 Brief introduction................................3 1.2 Feature..................................3 1.3 Application................................3 2 Specification and parameter............................. 4 2.1 Limit parameter.................................4 2.2 Operating parameter..............................4 3 Size and pin definition............................... 5 4. -
Page 3: Disclaimer
E10-433MS1W User Manual Disclaimer EBYTE reserves all rights to this document and the information contained herein. Products, names, logos and designs described herein may in whole or in part be subject to intellectual property rights. Reproduction, use, modification or disclosure to third parties of this document or any part thereof without the express permission of EBYTE is strictly prohibited. -
Page 4: Overview
Based on originally imported RF IC SI4463 form Silicon Labs, E10 series are small size Sub-1GHz SMD wireless transceiver module, with SPI interface and 26M crystal oscillator, developed by Chengdu Ebyte. The 30dBm module with PA and LNA, the communication stability and distance are largely improved. -
Page 5: Specification And Parameter
Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MS1W User Manual 2 Specification and parameter 2.1 Limit parameter Performance Main parameter Remark Min. Max. Voltage over 5.5V will cause permanent Power supply（V） damage to module Chances of burn is slim when modules are Blocking power（dBm）... -
Page 6: Size And Pin Definition
Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MS1W User Manual 3 Size and pin definition Copyright ©2012–2018，Chengdu Ebyte Electronic Technology Co.,Ltd. -
Page 7: Basic Operation
Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MS1W User Manual Pin No. Pin item Pin direction Pin application Input Ground The module working enable control the pin, Input its low level when working (See SI4463 manual for more details) GPIO3 Output... -
Page 8: Software Editing
Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MS1W User Manual High-frequency digital routing, high-frequency analog routing, and power routing must be avoided under the module. If it is necessary to pass through the module, assume that the module is soldered to the Top Layer, and the copper is spread on the Top Layer of the module contact part(well grounded), it must be close to the digital part of the module and routed in the Bottom Layer；... -
Page 9: Basic Application
Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MS1W User Manual 5 Basic application 5.1 Basic circuit diagram 6 FAQ 6.1 Communication range is too short The communication distance will be affected when obstacle exists. Data lose rate will be affected by temperature, humidity and co-channel interference. -
Page 10: Ber(Bit Error Rate) Is High
Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MS1W User Manual Please make sure antistatic measure are taken when installing and using, high frequency devices have electrostatic susceptibility. Please ensure the humidity is within limited range, some parts are sensitive to humidity. -
Page 11: Reflow Soldering Curve
Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MS1W User Manual 7.2 Reflow soldering curve 8 E10 Series Frequency Tx power Test distance Model No. Package Antenna (Hz) (dBm) E10-868MS30 SI4463 868M Stamp hole/IPEX E10-915MS20 SI4463 915M Stamp hole/IPEX E10-868MS20 SI4463 868M... -
Page 12: Antenna Guidance
Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MS1W User Manual 9 Antenna guidance 9.1 Antenna recommendation The antenna is an important role in the communication process. A good antenna can largely improve the communication system. Therefore, we recommend some antennas for wireless modules with excellent performance and reasonable price. -
Page 13: Package Method For Bulk Order
Huaa About us Technical support: support@cdebyte.com Documents and RF Setting download link: www.ebyte.com Thank you for using Ebyte products! Please contact us with any questions or suggestions: info@cdebyte.com ------------------------------------------------------------------------------------------------------------ Fax: 028-64146160 ext. 821 Web: www.ebyte.com Address: Innovation Center B333-D347, 4# XI-XIN Road,Chengdu, Sichuan, China...
