- Page 1 E70-433NW30S User Manual 433MHz 1W Star Network SMD Wireless Module...
-
Page 2: Table Of Contents
Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual CONTENT OVERVIEW .............................2 1.1 INTRODUCTION ............................. 2 1.2 F .........................................2 EATURES 2.SPECIFICATION AND PARAMETER .......................3 2.1 L ....................................3 IMIT PARAMETER 2.2 O ..................................3 PERATING PARAMETER 3 SIZE AND PIN DEFINITION ........................4 4 CONNECT TO MCU ........................... -
Page 3: Overview
E70-433NW30S is the first 433MHz wireless module in China that can support 200 nodes concurrent. It solves a series of problems caused by the traditional 433MHz wireless modules which can not send data packet concurrently. -
Page 4: Specification And Parameter
Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual 1.3 Application Home security alarm and remote keyless entry； Smart home and industrial sensors； Wireless alarm security system； Building automation solutions； Wireless industrial-grade remote control； Health care products；... -
Page 5: Size And Pin Definition
Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual Main parameter Description Remark Test condition：clear and open area, antenna gain: 5dBi， Distance for reference 6500m antenna height: 2.5m，air data rate: 5kbps TX length Transmission mode specification See transmission mode for details... - Page 6 Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual Reserved pin Reserved, to be floated Reserved pin Reserved, to be floated Reserved pin Reserved, to be floated Reserved pin Reserved, to be floated Reserved pin Reserved, to be floated Reserved pin...
-
Page 7: Connect To Mcu
Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual Reserved pin Reserved, to be floated Reserved pin Reserved, to be floated TTL UART inputs, connects to external (MCU, PC) TXD output pin. Can be Input configured as open-drain or pull-up input. -
Page 8: Firmware Transmitting Mode
Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual 5 Firmware Transmitting mode 5.1 Transparent transmission Summary When the coordinator is set to transparent transmission, the coordinator will send broadcast message. At this time, all non-dormant nodes in the entire network will receive data. -
Page 9: Device Status
Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual Node A address: AA BB CC 0A 01 AA 45 65 13 12 44 Node B address: AA BB CC 0A 01 AA 45 65 13 12 44 Node C address: 1 HEX... -
Page 10: Link Description
Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual 6.2 LINK description The LINK pin indicates the current network status, after the node is connected to the network, the current pin is pulled low. The external device can query the device network status through the pin level. In the coordinator mode, the pin indicates if the module establishes the network normally. -
Page 11: Dormant Node
Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual information Normal node Send and receive data at any time High real-time performance Low-power reception, sending data at any Receive delay, need to wake up the serial port for Dormant node time... -
Page 12: Configuration Mode
Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual dormant node is suitable for applications where the user requires low power consumption and does not require high real-time response.. 7.4 Configuration mode At any time and in any mode, as long as the M0M1 combination is set to 11, the system will switch to the configuration mode. - Page 13 Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual Figure 5- 1 Then enter "AT+WMCFG=0" with line breaks to configure the device as the coordinator mode, as shown in Figure 5-2: Figure 5-2 Then enter “AT+RSTART” with line breaks to restart the device. The coordinator configuration is complete. As...
- Page 14 Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual Figure 5-4 Then enter "AT+WMCFG=1" with line breaks to configure the device as the normal mode, as shown in Figure 5-5: Figure 5-5 Then enter “AT+RSTART” to restart the device with a line break. The normal node configuration is complete.
-
Page 15: At Command
Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual The coordinator and node device can communicate with each other normally. 9. AT Command When the serial port enters AT mode, it needs to open the serial port assistant, set the serial port (default parameter) baud rate 115200, data bit 8 bit, stop bit 1 bit, input "+++"... - Page 16 Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual Null Response: All instructions and help information Example：AT+HELP AT+ WMCFG Setting /Querying device working mode (restart to take effect) Description: Gets current working mode AT+ WMCFG =? Response： WMCFG：4 Description: Value：0~4 0，Coordinator；...
- Page 17 Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual 5：Output：Valid Data+transmitter’s Long Address+RSSI 6：Output：Valid Data+transmitter’s Short Address+RSSI 7：Output：Valid Data+transmitter’s Long Address+transmitter’s Short Address+RSSI Example：AT+ TFCFG=0 AT+ TFICFG Setting/Querying input data format settings (restart to take effect) Description: Gets input data format settings AT+ TFICFG=？...
- Page 18 Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual Example：AT+PIDCFG=65535 Note: The node can only join the network which has same PANID as it (any network can be added when it is configured as 65535) AT+ DMCFG Setting/Querying dormancy time configuration (restart to take effect)
- Page 19 Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual 7：115200 Example：AT+UBCFG=7 AT+UPCFG Setting /Querying the device parity parameter (restart to take effect) Description Gets the device parity parameter AT+UPCFG=? Response： UPCFG:0 Description： Value:0~2 0：None AT+UPCFG=Value 1：Odd parity 2：Even parity Example：AT+UPCFG=0 AT+PWCFG Setting /Querying the power parameter (restart to take effect) Description：...
- Page 20 Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual Description：Null AT+DFCFG Restore the default parameter Example：AT+DFCFG AT+RSTART Device Restart Description：Null AT+RSTART Device Restart Example：AT+RSTART AT+ECHO Sets up the AT instruction to turn off the back display Description: Value:0 or 1 AT+ECHO=Value 1：Close the echo...
-
Page 21: Hardware Design
Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual delay in sending data and the average power consumption of the nodes will increase; the lower the performance, the higher the real-time performance of the data sent by the nodes, but the data may be lost when the environment has large interference or multiple nodes transmit simultaneously.) -
Page 22: Faq
Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual 11 FAQ 11.1 Communication range is too short The communication distance will be affected when obstacle exists. Data lose rate will be affected by temperature, humidity and co-channel interference. The ground will absorb and reflect wireless radio wave, so the performance will be poor when testing near ground. -
Page 23: Reflow Soldering Curve
Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual Preheat Time (Tsmin to Tsmax)(ts) 60-120 sec 60-120 sec Average ramp-up rate(Tsmax to Tp) 3℃/second max 3℃/second max Liquidous Temperature (TL) 183℃ 217℃ Time（tL）Maintained Above（TL） 60-90 sec 30-90 sec Peak temperature（Tp） 220-235℃... -
Page 24: Antenna Recommendation
Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual E70-915NW14S 915M 2.5k~168k 16 * 26 IPEX/stamp hole E70-915NW30S 915M 2.5k~168k 24 * 38.5 IPEX/Stamp hole 14. Antenna recommendation 14.1 Antenna recommendation The antenna is an important role in the communication process. A good antenna can largely improve the communication system. -
Page 25: Package For Batch Order
Chengdu Ebyte Electronic Technology Co,;Ltd E70-433NW30S user manual 15. Package for batch order Revision history Version Date Description Issued by 2018-01-08 Initial version huaa 2018-04-16 content updating huaa 2018-07-20 name change Huaa 2018-10-29 module separating Huaa 2019-02-20 bug fixes 2019-03-29... -
Page 26: About Us
E70-433NW30S user manual About us Technical support: support@cdebyte.com Documents and RF Setting download link: https://www.cdebyte.com Thank you for using Ebyte products! Please contact us with any questions or suggestions: info@cdebyte.com ------------------------------------------------------------------------------------------------------------ Tel: +86-028-61543675 Web: https://www.es-ebyte.com Address: Building B5, Mould Industrial Park, 199# Xi-Qu Ave, West High-tech Zone, Chengdu, 611731, Sichuan, China Chengdu Ebyte Electronic Technology Co,;Ltd...
