Ariens MELTBUDDY 72601200 Quick Start Manual

Instruction Sheet
Kit Number: 72601200
MELTBUDDY™ ICE MELT SPREADER KIT
WARNING: FAILURE TO FOLLOW
INSTRUCTIONS could result in personal injury
and/or damage to unit.
Read, understand, and follow all safety practices
in Owner/Operator Manual before beginning.
Package Contents
Check contents of your kit for the parts listed (Figure 1):
Item Part No. Qty. Description
1 03848000 1
2 03848551 1
3 03848200 1
4 07400040 6
5 06809700 1
6 08300432 1
7 06900403 1
8 06900410 1
9 03854751 1
10 06100137 1
11 06536000 1
12 06212100 2
13 06545400 3
14 03387451 1
15 03854851 1
16 06220800 1
17 06305200 1
18 06100007 1
19 03848100 1
20 03965500 2
21 07800201 1
© Copyright 2009 • Ariens Company • Brillion, WI 54110-1072
Hopper
Gate Bracket
Base
10-24 x 1/2 in. Hex Stainless
Steel BosScrew
1/4 x 13/32 in.Clevis Pin
Extension Spring
Cable
Lever Assembly
Base Bracket
10-24 x 1/2 in. Hex Washer
Head Stainless Steel Screw
10-24 Locking Nylon Nut with
Insert
5/16 x 1-1/2 in. Round Head
Square Neck Bolt
5/16-18 in. Nyloc Flange Nut
Top Clamp
Clamp Bracket
5/16-18 x 3/4 in. Round Head
Square Neck Bolt
1/4 in. Internal Locking Washer
1/4-20 x 1-1/2 in. Oval Head
Machine Screw
Cover
Clamp Grip
MeltBuddy™ Decal
20
14
13
18
17
15
12
13
7
3
8
ASSEMBLY
Mounting Hopper
1. Remove protective backing from clamp grip
(item 20) and apply to inside center of clamp
bracket (item 15). Remove protective backing from
second clamp grip (item 20) and apply to inside
center of top clamp (item 14). See Figure 2.
20
15
10
11
16
4
9
1
6
2
5
Figure 1
20
14
Figure 2
03942400 7/09 Page 1 of 3
19
21
IS9000
