Power Brush 36 Hydro
Model
Owner/Operator Manual
926515 – Power Brush 36 Hydro 12V
Gebruikershandleiding
(SN 000101 +)
Návod k obsluze
Betriebsanleitung
Instruktionsbog
Manual del propietario / operador
Käyttöohjekirja
Manuel du propriétaire / utilisateur
Manuale del proprietario /
operatore
Gebruikshandleiding
Brukerhåndbok
Instrukcja obslugi /
operatora
Instruktionsbok
04654100 10/13
E10
Printed in USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power Brush 36 Hydro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ariens Power Brush 36 Hydro

Summary of Contents for Ariens Power Brush 36 Hydro

  • Page 1 Power Brush 36 Hydro Model Owner/Operator Manual 926515 – Power Brush 36 Hydro 12V Gebruikershandleiding (SN 000101 +) Návod k obsluze Betriebsanleitung Instruktionsbog Manual del propietario / operador Käyttöohjekirja Manuel du propriétaire / utilisateur Manuale del proprietario / operatore Gebruikshandleiding Brukerhåndbok...
  • Page 2 PRZEPISAMI EC WYDANA PRZEZ PRODUCENTA – EG-DEKLARATIONEN OM ÖVERENSSTÄMMELSE UTFÄRDAD AV TILLVERKAREN We the undersigned, ARIENS COMPANY, certify that: Wij, de ondergetekende, ARIENS COMPANY, certificeren dat: My, nížepodepsaní, ARIENS COMPANY, prohlašujeme, že: Der Unterzeichnete, ARIENS COMPANY, bescheinigt, dass: Undertegnede, ARIENS COMPANY, attesterer, at: Nosotros, los abajo firmantes, ARIENS COMPANY, certificamos que: Allekirjoittanut, ARIENS COMPANY, vakuuttaa, että: Nous, soussignés ARIENS COMPANY, certifions que: La sottoscritta società...
  • Page 3 Správce shody výrobku a záruky (správce technické Päivämäärä – Date – dokumentace) / Director Product Conformance & Data – Datum – Dato Ariens Company Warranty (Archivar der technischen Akte) / Direktør – Data – Datum Brillion, WI 54110-1072 for produktoverholdelse & garanti (indehaver af teknisk fil) / Director de conformidad de los Signature –...

  • Page 4: Table Of Contents

    Model and Serial PRODUCT REGISTRATION numbers of your unit and engine. The Ariens Dealer must register the product Numbers are located on the product at the time of purchase. Registering the registration form in the unit literature product will help the company process package.
  • Page 5 6. Fill out Original Purchaser Registration UNAUTHORIZED REPLACEMENT Card and return the card to Ariens PARTS Company or go to www.ariens.com on Use only Ariens replacement parts. The the Internet. replacement of any part on this unit with anything other than an Ariens authorized...

  • Page 6: Safety

    SAFETY SAFETY DECALS AND WARNING: To avoid injury to LOCATIONS hands and feet, always disengage clutches, shut off engine, and wait ALWAYS replace missing or damaged Safety for all movement to stop before Decals. Refer to Figure 2 for safety decal unclogging or working on brush.
  • Page 7 Stop engine, remove key, read manual before Keep clear of brush while making any repairs or engine is running. adjustments. Read Owner/Operator Manual. NEVER use your hands to Allow operation only by clear blockages. properly trained adult, never children. Wear appropriate hearing Operating on irregular protection.
  • Page 8 Wear adequate penalties. Emission controls and components safety gear, including safety glasses with side can only be adjusted by an Ariens Company shields, and protective gloves. Wear proper Dealer or an authorized engine footwear to improve footing on slippery manufacturer's service center.
  • Page 9 Before starting engine, disengage control(s). DO NOT park unit on a slope unless absolutely necessary. When parking on a Use only approved extension cords and slope always block the wheels. receptacles when starting units equipped with electric starter. DO NOT connect electric ALWAYS shut off engine, remove key, and starter cord to any wiring system that is not a close fuel shut-off valve or drain fuel when...
  • Page 10 Explosive gases from battery can cause NEVER store unit with fuel in fuel tank, inside death or serious injury. Poisonous battery a building where any ignition sources are fluid contains sulfuric acid and its contact with present such as hot water heaters, space skin, eyes or clothing can cause severe heaters, or clothes dryers.

  • Page 11: Assembly

    ASSEMBLY WARNING: AVOID INJURY. Read and understand the entire Safety section before proceeding. Tools Required • Tire Gauge • Pliers • 1/2", 3/8", 7/16", and 9/16" Wrench and/or Adjustable Wrench Unpacking Unit WARNING: Dropping or tipping over boxed unit could result in personal injury or damage to unit.
  • Page 12 CAUTION: Avoid injury! Explosive separation of tire and rim parts is possible when they are serviced incorrectly: • Do not attempt to mount a tire without proper equipment and experience to perform the job. • Do not inflate tires above recommended pressure.

  • Page 13: Controls And Features

    CONTROLS AND FEATURES Figure 4 1. Traction Drive Clutch Lever 11. Fuel Shut-off Valve 2. Speed Selector Lever 12. Fuel Fill Cap 3. Attachment Clutch Lever 13. Choke Control Lever 4. Brush Angle Lock Lever 14. Oil Drain Plug 5. Recoil Starter Handle 15.

  • Page 14: Operation

    OPERATION IMPORTANT: If belt squeals when CONTROLS AND FEATURES attachment clutch lever is engaged, the attachment drive may be frozen. Immediately WARNING: AVOID INJURY. Read release attachment clutch lever and move and understand the entire Safety unit into a heated area to thaw. section before proceeding.
  • Page 15 The fuel shut-off valve has two positions: Speed Selector Lever 1. CLOSED (Item 2) Use to service, Position speed transport or store selector in appropriate unit. position to control forward and reverse travel. 2. OPEN Use to run unit. Forward: (2) Fastest (1) Slowest Electric Starter...
  • Page 16 8. Remove lock pin while supporting caster Brush Position Locked arm. Lower arm on top of remaining spacers. Put spacers that were removed in the caster spindle above the support tube as shown. See Figure 7. 9. Reinstall lock pin into top hole and flip over the lock ring to secure remaining spacers and pin.
  • Page 17 • Do not modify the fuel system to use appropriately sized dispensing spout when different fuels. filling the tank. Do not use a funnel or other device that obstructs the view of the tank • Never mix oil and gasoline. filling process.
  • Page 18 NOTE: When operating unit in winter months, 4. Check Engine Fuel and Crankcase recoil guard foam cover must be installed. Oil Levels See Recoil Guard Foam Cover Installation on page 23. WARNING: AVOID INJURY. Read 6. Repeat until engine starts. (If engine and understand the entire Safety does not start, see Troubleshooting on section before proceeding.

  • Page 19: Maintenance

    DO NOT transport machine while engine is damaging the lawn. running. MAINTENANCE Ariens Dealers will provide any service or To separate the brush attachment from adjustments which may be required to keep traction unit: your unit operating at peak efficiency. Should 1.
  • Page 20 10. While brush attachment is supported on MAINTENANCE SCHEDULE traction unit lower pivot rod, remove The chart below shows the recommended attachment drive belts from attachment maintenance schedule that should be pulley. performed on a regular basis. More frequent 11. Separate brush attachment from traction service may be required due to working unit.
  • Page 21 CHECK CLUTCH OPERATION CHECK TIRE PRESSURE Brush must stop quickly when attachment Keep tires at pressure listed on tire sidewall. See Check Tire Pressure on page 11. clutch lever is released. Wheels must stop quickly when traction drive GENERAL LUBRICATION clutch lever is released.
  • Page 22 2. Locate fuse holder on wiring harness Clean Battery and remove fuse. See Figure 11. WARNING: AVOID INJURY. Read Fuse Holder and understand the entire Safety section before proceeding. Fuse IMPORTANT: Battery is maintenance-free. Do not tamper with or attempt to open battery. See Service and Adjustments on page 23 for charging procedures.

  • Page 23: Service & Adjustments

    SERVICE AND ADJUSTMENTS HANDLEBAR HEIGHT WARNING: AVOID INJURY. ADJUSTMENT Read and understand the entire Safety section before CAUTION: AVOID INJURY. Adjust proceeding. the attachment clutch, speed selector and traction drive clutch RECOIL GUARD FOAM COVER after changing handlebar height. See Attachment Clutch Adjustment INSTALLATION on page 24, Traction Drive Clutch See Figure 12.
  • Page 24 5. Check and adjust speed selector. See ATTACHMENT CLUTCH Speed Selector Adjustment on page 24. ADJUSTMENT 6. Check and adjust auger and traction clutch cables. See Attachment Clutch WARNING: IMPROPER Adjustment on page 24 and Traction ADJUSTMENT could result in Drive Clutch Adjustment on page 26.
  • Page 25 Some components removed for clarity of illustration. Check idler arm position here. 1. Engine Sheave 2. Attachment Drive Belts Roller should be 3. Idler Pulley Adjustment Nut 12,7 – 22,2 mm (1/2 – 7/8") from the frame 4. Idler Arm when the attachment clutch is engaged.
  • Page 26 TRACTION DRIVE BELT Check belt finger clearance here. REPLACEMENT See Figure 19. NOTE: Replacement will be easier with brush attachment and frame tipped apart and bottom cover off. 1. Remove attachment drive belts. (See Attachment Drive Belts Replacement on page 26.) 2.
  • Page 27 BATTERY Charging 1. Place unit on level surface and shut off engine. 2. Remove two wing nuts retaining battery cover and remove cover. 3. Disconnect negative (–) cable first, then positive (+) cable. 4. Remove battery. Place battery on bench or other well-ventilated place.
  • Page 28 1. Flanged Bolts 2. End Plate 3. Support Shaft Assembly Figure 23 7. Remove used brush segments from top half of brush and discard. 8. Install new brush segments on top half 1. U-Joint of brush head. Align locator pins on 2.
  • Page 29 Locator Pins Drive Drive Core Tube Core Tube Figure 24 9. Install end plate and secure with three bolts. (See Figure 23.) NOTE: Compress disks to install end plate. 10. Stand brush assembly upright on other end. 11. Repeat Steps 6 – 9. 12.

  • Page 30: Storage

    STORAGE 5. Run engine outdoors for 5 minutes to be WARNING: AVOID INJURY. Read sure that treated gasoline has replaced and understand the entire Safety the untreated gasoline in carburetor. section before proceeding. 6. Slow engine to an idle speed. 7.

  • Page 31: Troubleshooting

    TROUBLESHOOTING PROBLEM PROBABLE CAUSE CORRECTION 1. Fuel tank is empty. 1. Fill fuel tank. See Filling Fuel Tank on Engine will page 16. not crank / start. 2. Fuel shut-off valve closed. 2. Open fuel shut-off valve. See Fuel Shut-off Valve on page 15.

  • Page 32: Service Parts

    SERVICE PARTS ACCESSORIES See your authorized Ariens Dealer to add Order the following parts through your the additional accessories available to your Dealer: Sno-Thro. Part No. Description Part No. Description 07200631 Traction Drive Belt 72408000 Sno Cab 07200601 Attachment Drive Belt (Set of 2) 72602300 36"...

  • Page 33: Warranty

    ® ® Sno-Thro , Sno-Tek Chore Performing Equipment Limited Warranty Ariens Company (Ariens) warrants to the original purchaser that Ariens, Gravely, Parker, and Countax ® ® brand chore performing equipment (including Sno-Thro and Sno-Tek equipment) purchased on or after 1/1/2013 will be free from defects in material and workmanship for the time period noted in the chart below.
  • Page 34 Register the product immediately at the time of sale. If the dealer does not register the product, the customer must complete the product registration card in the literature package and return it to Ariens Company, or register the unit online at www.ariens.com, www.gravely.com, www.countax.com or www.parkersweeper.com.
  • Page 35 Exclusions – Items Not Covered by This Warranty • Parts that are not genuine Ariens, Gravely, Parker or Countax service parts are not covered by this warranty and may void the warranty. • Damages resulting from the installation or use of any part, accessory, or attachment which is not approved by the Ariens Company for use with product(s) identified herein are not covered by this warranty.
  • Page 36 Ariens 655 West Ryan Street Brillion, WI 54110 920-756-4688 Fax 920-756-2407 www.ariens.eu...
