Summary of Contents for Crumar MOJO
- Page 1 User Manual MADE IN ITALY...
- Page 2 INDEX 1. GENERAL WARNING. 2. PACKAGE AND HANDLING. 3. ACCESSORIES IN YOUR PACKAGE. 4. CONNECTIONS AND CONTROLS. 5. START-UP AND SHUT DOWN OF THE INSTRUMENT: USE. 6. EDIT AND PROGRAMMING MODE. 7. UPDATE. 8. MAINTENANCE. 9. ADDENDUM.
- Page 3 • Do not touch the AC plug with wet hands. • FACTORY DEFAULTS • Crumar Mojo will accept voltage from 100V to 240V AC 50-60Hz through the original AC adapter. Be sure that local electrical standards are compliant with the instrument.
- Page 4 • Do not expose it to electrostatic forces. • Do not place on it things with flames like candles etc… • Do not place on it vessels containing fluids. If anything enters the instrument, please contact your dealer or the official CRUMAR service support. N.B.
- Page 5 Please remove the organ from its packaging carefully. Crumar Mojo weights just over 17 If not placed in the original Crumar stand, we recommend to placed the organ on a stand rated at 20 KG, which will give a more than sufficient safety margin.
- Page 6 • 1 – Plug for power supply: it is located on the left side of the instrument: used for connect the original Crumar Mojo power supply (12 Volt CC). It’s recommended to use only the original power supply included in your package.
- Page 7 The instrument can be damaged or work in wrong way. • 7 – USB output: through this output is it possible to connect CRUMAR MOJO to a computer without needing of converter. It is useful in case you would like to play softwares or sounds inside a computer connected to the instrument.
- Page 8 • Power: Button for power on and off the instrument. When you press this button, Mojo starts the boot process; led on the button lights and the other leds on the panel lit in sequence indicating that the unit is booting. Holding down the button for 4 seconds turns the instrument off.
- Page 9 “pedal to lower” led will blink fast (to use this function, see section “programming”). • Drawbars section: Mojo has 20 drawbars arranged into two sections of 9 and a central section of 2. First section (or left set) refers to upper manual, second section (or right set) refers to lower manual, central section (or pedalboard set) is used to control the sound of the pedal.
- Page 10 From left to right each set is composed by: 16’ One octave under 8’ with repetition of first low octave. 5-1/3 A fifth above 8’ 8’ Fundamental 4’ An octave above 8’ 2-2/3 An octave and a fifth above 8’ Two ocatve above 8’...
- Page 11 XPE for example from a CD-ROM. Protect your XPE image (Crumar Mojo operating system) is very important in two ways: as Mojo doesn’t come with hard drives but all the system works using a flash...
- Page 12 CRUMAR MUSICAL INSTRUMENTS will not respond for any damage you can cause to the operating system, but, through our web site or by contacting CRUMAR, we always will be able to restore the system with the original settings.
- Page 13 “EWF” will be disabled. When finished, it is recommended to re-enable “EWF”. Crumar Mojo is factory set with VB3 HE II that autostart whenever you turn the instrument on: VB3 HE II actually is the most advanced electromagnetic organ emulation software and it offers significant advanced features to change the sound and timbre.
- Page 14 Fig. 3 “Tonewheel Generator Set” section offers the possibility to choose between 20 different types of tone generator, in fact 20 different settings of the same electromagnetic generator typical of the American tonewheel organs. “Generator” section provides the ability to vary the typical “Leakeage” and “CrossTalk” that makes the sounds unique and inimitable.
- Page 15 “EWF” filter is disabled through the “disable”, “commit changes” or “commit and disable – live” functions. The principles of working of Mojo is therefore expected that user can modify the sound through the various options offered by VB3 HE II software and acting first on “store” and then on “EWF”...
- Page 16 With these two buttons it’s possible to send midi messages of program change on channel 1 both on internal Mojo software both on midi out and USB out. Pressing “-“ or “+” you send messages in a descending or ascending way from 0 to 127. When you reach program change 0, led on button “program change channel 1 –“...
- Page 17 Pedal to Lower ► Panic! If you hold this button for 3 seconds, Mojo will send a “all notes off” message to all 16 midi channels and then will reboot the midi processor.
- Page 18 Lower manual preset 6 ► Velocity on/off. With this button it is possible to set both keyboards of Mojo for working in velocity mode (for example for playing sound that need touch response) or on velocity off mode with fast action (for controlling organ sounds).
- Page 19 Drive ► Crosstalk Control Change 91. Keyclick ► Keyclick length Control Change 92. Reverb ► Reverb Lenght Control Change 93. Bass ► Rotary Balance Control Change 94. Treble ► Percussion Volume Control Change 95. Pedalboard Drawbar 16’ ► Pedalboard sustain Control Change 96.
- Page 20 The new update file from CRUMAR is sent to the instrument via a laptop or desktop equipped with a midi cable that has to be connected to midi in of Mojo as specified in the “readme” file supplied with the firmware package.
- Page 21 The wooden and iron parts of Mojo should be cleaned only with a soft, not too moist cloth to prevent entering of water into the panel through the slits of the buttons or anything.
- Page 22 9) ADDENDUM. CRUMAR MOJO MIDI IMPLEMENTATION CHART FUNCTION TRASMITTED RECOGNIZED REMARKS Basic Channel Default: :1-2 Changed: :1-2 : 3 with pedal to lower Mode Messages Default: Altered: Note Number 0-127 True Voice _______________ Velocity Note On Note Off Aftertouch Keys:...
- Page 24 E-mail: info@crumar.it Manual Rev.3 October 2011 Crumar brand name and logo are trademarks of the respective owners. Asio is a trademark of Steiberg Media Technologies GmbH Fatar and Waterfall touch are trademarks of Fatar s.r.l. VST is a trademark of Steinberg Soft-und Hardware GmbH Microsoft, Windows XP, and Windows XP embedded are trademarks of Microsoft Corporation All rights are reserved.
