NEXIQ Brake-Link™
®
®
Bendix
& Eaton
ABS Applications
Operator's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Brake-Link and is the answer not in the manual?

Questions and answers

Related Manuals for NEXIQ Technologies Brake-Link

Summary of Contents for NEXIQ Technologies Brake-Link

  • Page 1 NEXIQ Brake-Link™ ® ® Bendix & Eaton ABS Applications Operator’s Manual...
  • Page 2 Eaton Corporation. ® ® ® Roadranger is a combined registered trademark of Eaton Corporation and Dana Corporation. Brake-Link™ and NEXIQ™ are trademarks of NEXIQ Technologies. 2002−2009 IDSC Holdings LLC. All Rights Reserved. www.nexiq.com Part No. 192149B Revised 01/06/2009...

  • Page 3: Table Of Contents

    Safety Warnings & Cautions..............3 Using this Manual................4 Specialized Text ................... 4 Navigation Icons ................... 5 General Icons ..................5 Navigating Brake-Link™..............6 Home Button..................6 Enter Button..................6 Menu Buttons..................7 Direct Access Buttons................8 Light Emitting Diodes (LEDs).............. 13 ®...
  • Page 4 Establishing Connection ........15 Connecting Brake-Link™ Components ........16 Selecting a Protocol & Registering the ECU ....... 19 Enabling Enhanced PLC Mode ........... 30 Diagnosing EC-17, EC-30 & EC-30T ABS ....33 Using EC-17, EC-30 & EC-30T Diagnostic Options....34 Current Faults..................
  • Page 5 EC-17 SIDs & FMIs ..............90 EC-30 SIDs & FMIs ..............92 EC-30T SIDs & FMIs ..............95 Gen 4 & 5 Fault Code Tables ........ 97 Generation 4................98 Generation 5................100 ® ® NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...
  • Page 6 ® ® NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...

  • Page 7: Getting Started

    Safety Warnings & Cautions, page 3 Using this Manual, page 4 Navigating Brake-Link™, page 6 rake-Link™ is a hand-held diagnostic tool primarily designed to troubleshoot heavy- duty vehicle Anti-lock Braking Systems (ABS). It also provides a variety of utilities and configuration options.

  • Page 8: Getting Started

    • Getting Started Chapter Getting Started Brake-Link™ is a multi-faceted, hand-held, ABS diagnostic tool that offers are variety of utilities, diagnostic applications and configuration options. Figure 1.1 NEXIQ Brake-Link™ Component connection procedures and navigation vary depending on the util- ity or application you’re using. The connection and navigation sections in this manual are specific to the Bendix ®...

  • Page 9: Safety Warnings & Cautions

    Read and understand this manual before operating your NEXIQ Brake-Link™. NEXIQ Technologies recommends having an assistant drive the vehicle while you use NEXIQ Brake-Link™ if you need to test the vehicle in tran- sit. Never leave the vehicle unattended while testing.

  • Page 10: Using This Manual

    “From the main menu, select J1708/J1587 BUS .” • Screen titles : Once you select a menu item, Brake-Link™ presents the selected item’s screen. A screen may display information or present an- other list of menu items.

  • Page 11: Navigation Icons

    Navigation Icons Brake-Link™ offers two methods of navigation: menu and direct access but- tons. See “Navigating Brake-Link™”, on page 6. If a task can be performed with both, the manual provides separate instructions for each method. Topic introductions indicate when there are two sets of instructions and the following icons help you easily locate the desired set.

  • Page 12: Navigating Brake-Link

    This button does not function if the screen displays “[ENTER] Note: TO CONTINUE”. Enter Button Use the button to select a menu item, confirm a response, or instruct Brake-Link™ to proceed to the next step. ® ® NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...

  • Page 13: Menu Buttons

    Note: of the menu or list. • press to select the option the blinking cursor is on; • press to exit your selection and return to the previous menu or screen. ® ® NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...

  • Page 14: Direct Access Buttons

    • Getting Started Chapter Direct Access Buttons The direct access buttons reside on the lower portion of the Brake-Link™. No- tice they are grouped by functionality. The section provides a button overview for each button group. These buttons operate differently depending on the applica- Note: tion you’re using and/or controller you’re diagnosing.

  • Page 15: Mode Buttons

    Push to select the middle axle. Rear Push to select the rear axle. AXLE buttons work in conjunction with the SIDE and COM- Note: PONENT buttons. ® ® NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...

  • Page 16: Side Buttons

    COMPONENT Buttons Use the COMPONENT buttons to select the component that you wish to test. The available buttons are: Traction Push to temporarily disable the traction control on a Brake-Link™ ECU. This button supports EC-17, EC-30 and EC-30T diagnostics Note: only.

  • Page 17: Other Buttons

    For Gen 4 and 5 diagnostics, it presents ECU Information; see “To view ECU Information via button navigation:”, on page 102. Other Buttons Use the following buttons to select other Brake-Link™ options: Current Faults If you’re diagnosing: • EC-17, EC-30 or EC-30T systems, use to view and/or clear all current faults.
  • Page 18 • Gen 4 or 5 systems, use it to view the Data List which contains various system voltage data points. See “To access the Data List via button nav- igation:”, on page116. ® ® 12 NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...

  • Page 19: Light Emitting Diodes (Leds)

    Navigating Brake-Link™ Light Emitting Diodes (LEDs) The POWER LED indicates Brake-Link™ is receiving power. The COMM and MODE LEDs light up, according to the Brake-Link™ operation(s) you select. When you’re diagnosing EC-17, EC-30 or EC-30T systems, the AXLE, SIDE, COMPONENT and VOLT LEDs reflect the LED illumination on the ECU’s front panel.
  • Page 20 • Getting Started Chapter ® ® 14 NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...

  • Page 21: Establishing Connection

    EXIQ Brake-Link™ offers a variety of connection options. Quickly and easily attach Brake-Link™ to the vehicle, power up and register the ECU to begin a diagnostic session. This chapter details each step necessary to establish communication with the ABS ECU.

  • Page 22: Connecting Brake-Link™ Components

    • Establishing Connection Chapter Connecting Brake-Link™ Components Connect Brake-Link™ to the vehicle with one of the following adapters: • J560 PLC Cable Set. Attach to the tractor or trailer J560 Power Line Connector. Note: The ECU must be configured to support Enhanced PLC Mode in order to use this adapter.
  • Page 23 Connecting Brake-Link™ Components Use the following table to help you decide which adapter to use with the Ben- ® ® & Eaton ABS Applications. Then look at the connection diagram and complete the instructions that follow the table. BENDIX & EATON ABS APPlICATIONS Are you Connect to the...
  • Page 24 • Establishing Connection Chapter shows how to connect Brake-Link™ components for standard ABS Figure 2.1 diagnostics. Power/ Data Cable 6- or 9-Pin Deutsch Note: Where appli- cable, substitute with J560 PLC Cable Set (Figure 2.2) Figure 2.1 Connectivity diagram for standard ABS diagnostics.

  • Page 25: Selecting A Protocol & Registering The Ecu

    “on” position. Selecting a Protocol & Registering the ECU NEXIQ Brake-Link™ uses the SAE J1587 communication protocol to interact with the vehicle’s brake controllers. It sends and receives diagnostic informa- tion (i.e., J1587 messages) over the: •...
  • Page 26 These data bus options provide several ways to access brake ECUs. For ex- ample, if you’re testing a trailer that does not have a Deutsch Connector, use the J560 PLC Cable Set to obtain information over the power line. ® ® 20 NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...
  • Page 27 ABS Applications require you to select a hardware/ communication protocol in order to establish a connection to the ECU. In other words, you must tell Brake-Link™ which Data Bus to use for communications: J1708/J1587 BUS or PLC/ENHANCED MODE . Use the following table to help you decide which protocol best suites your needs.

  • Page 28: S Ele Ct A Ppli Cati On

    • Establishing Connection Chapter Once you connect Brake-Link™ to the vehicle, choose the application, select a navigation method & hardware/communication protocol, Brake-Link™ at- tempts to establish communication with the ECU. This process is called ECU registration. The discussions in Chapter 3 & 4 assume that you have registered the ECU.
  • Page 29 Enhanced Mode (see pg. 30). Use the keys to select the desired option: — J1708/J1587 BUS configures Brake-Link™ to communicate with the ECU via the J1708 Bus (accessed through the standard Deutsch Connection). Go to step 5. — PLC/ENHANCED MODE configures Brake-Link™ to communicate with the ECU(s) via the Power Line Carrier (accessed through the Deutsch or J560 Tractor/Trailer Power Line Connections).
  • Page 30 EC-17/30/30T Registration screens show ECU ID, sensor/modulator configuration and indicate whether there are active faults; if there are, Brake-Link™ illuminates the LEDs on the front panel to reflect the LED illumination on the ECU itself. BE NDIX TRA ILER...
  • Page 31 ® • the detected ECU is not a Bendix EC-17, EC-30, EC-30T, Gen- eration 4, or Generation 5 controller. If you selected EATON ABS and Brake-Link™ presents CAN NOT IDENTIFY ECU: ® • the detected ECU is not a Bendix Generation 4 or Generation 5 ®...
  • Page 32 EC-17/30/30T Registration screens show ECU ID, sensor/modulator configuration and indicate whether there are active faults; if there are, Brake-Link™ illuminates the LEDs on the front panel to reflect the LED illumination on the ECU itself. BE NDIX TRA ILER...
  • Page 33 • the ECU or Data Bus may be malfunctioning. Register ECU via direct access buttons : Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 16). Brake-Link™ boots up and presents the Select Application screen.
  • Page 34 EC-17/30/30T Registration screens show ECU ID, sensor/modulator configuration and indicate whether there are active faults; if there are, Brake-Link™ illuminates the LEDs on the front panel to reflect the LED illumination on the ECU itself. BE NDIX TRA ILER...
  • Page 35 ® • the detected ECU is not a Bendix EC-17, EC-30, EC-30T, Gen- eration 4, or Generation 5 controller. If you selected EATON ABS and Brake-Link™ presents CAN NOT IDENTIFY ECU: ® • the detected ECU is not a Bendix Generation 4 or Generation 5 ®...

  • Page 36: Enabling Enhanced Plc Mode

    • access all ECUs residing on the power line via a single diagnostic con- nection. For example, if the Tractor and Trailer are connected, attach Brake-Link™ to the Tractor Deutsch to access both Tractor and Trailer ABS ECUs. • access a Trailer ABS ECU when a Deutsch Connector isn’t available. It...
  • Page 37 PLC /ENH ANC ED M ODE S ET ENH ANC E PL C MO DE Brake-Link™ prompts you to select TRACTOR or TRAILER ; use the keys to select the desired option and press Next, Brake-Link™ displays your tractor/trailer selection and asks if you’d like to enable Enhanced PLC Mode permanently ( PERM ) or for...
  • Page 38 • Establishing Connection Chapter ® ® 32 NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...

  • Page 39: Diagnosing Ec-17, Ec-30 & Ec-30T Abs

    ABS Application to diagnose systems con- trolled by EC-17, EC-30 or EC-30T. See Chapter 4, "Diagnosing Gen 4 & 5 ABS" for in- structions on diagnosing Generation 4 and 5 ABS systems. ® ® NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...

  • Page 40: Using Ec-17, Ec-30 & Ec-30T Diagnostic Options

    The rest of this discussion details each of these options. Current Faults Brake-Link™ offers an option to view or clear all active (current) fault codes. Some ECUs do not clear active fault codes immediately after you make a re- pair. For example, a fault may continue to exist until the vehicle reaches a cer- tain speed.

  • Page 41: Viewing & Clearing All Active Fault Codes

    C UR RENT FA ULTS FAU LT H IST ORY DAT A LI ST TES TS Brake-Link™ prompts you to select VIEW ALL or CLEAR ALL . Use keys to select the desired option and press ® ® NEXIQ Brake-Link™ Bendix &...

  • Page 42: Clear All

    • Diagnosing EC-17, EC-30 & EC-30T ABS Chapter If you select VIEW ALL , Brake-Link™ presents the active faults one at a time. Brake-Link™ continuously queries for faults; the display updates as new faults are detected or existing faults are resolved. An arrow appears on the last line of the display if there is more than one fault;...
  • Page 43 Using EC-17, EC-30 & EC-30T Diagnostic Options If you select VIEW ALL , Brake-Link™ presents the active faults one at a time. Brake-Link™ continuously queries for fault codes; the display updates as new faults are detected or existing faults are resolved. An arrow appears on the last line of the display if there is more than one fault;...

  • Page 44: Fault History

    CUR REN T FA ULTS F AU LT HISTO R Y DAT A L IST TES TS Brake-Link™ prompts you to select VIEW ALL or CLEAR ALL . Use keys to select the desired option and press ® ® 38 NEXIQ Brake-Link™ Bendix &...
  • Page 45 Using EC-17, EC-30 & EC-30T Diagnostic Options If you select VIEW ALL , Brake-Link™ presents the inactive faults one at a time. An arrow appears on the last line of the display if there is more than one fault; use the keys to scroll through the fault codes.

  • Page 46: Data List

    • Diagnosing EC-17, EC-30 & EC-30T ABS Chapter If you select VIEW ALL , Brake-Link™ presents the inactive faults one at a time. An arrow appears on the last line of the display if there is more than one fault; use the keys to scroll through the fault codes.
  • Page 47 † PLC Status indicates whether the tractor ECU is configured to support J2497 communications. See Chapter 3, “Using Generic PLC Test”, in the “Introducing Brake-Link™ Operator’s Manual”. Use menu navigation to access a complete data list; use direct access but- tons to retrieve Wheel Speed and/or Battery Voltage.
  • Page 48 • Diagnosing EC-17, EC-30 & EC-30T ABS Chapter To access a complete Data List via menu navigation: Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).
  • Page 49 Select Application screen. To retrieve battery voltages via button navigation . Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).

  • Page 50: Tests

    Load Battery Voltage Test * These tests reside on the Special Tests menu. See “Running Special Test”, on page 51. Brake-Link™ will not perform any test if it detects a wheel Note: speed of 5mph or greater upon initiating the TESTS option.
  • Page 51 CUR RENT FA ULTS FAU LT H IST ORY DAT A LI ST T ES TS Brake-Link™ displays a list of tests; scroll to CHUFF MODULATORS with the keys and press If you’re connected to the tractor ECU, Brake-Link™ presents:...
  • Page 52 • Diagnosing EC-17, EC-30 & EC-30T ABS Chapter To chuff the modulators via button navigation: Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).

  • Page 53: Testing Sensor Sequence

    For example, if you spin the right front wheel, Brake-Link™ displays the right front wheel speed. If it doesn’t, the sensor may be malfunctioning. If it shows a wheel speed for a different wheel, the sensor is connected to the wrong wheel.
  • Page 54 • Diagnosing EC-17, EC-30 & EC-30T ABS Chapter Brake-Link™ displays a list of tests; scroll to SENSOR SEQUENCE TEST with the keys and press Brake-Link™ displays the following screen. RF WHEEL <1mph RM WHEEL <1mph RR WHEEL <1mph LR WHEEL <1mph...

  • Page 55: Testing Trailer On Plc

    CUR RENT FA ULTS FAU LT H IST ORY DAT A LI ST T ES TS Brake-Link™ displays a list of tests; scroll to TEST TRAILER ON PLC with the key and press Brake-Link™ reports the test: — successful if the tractor only receives “off” messages during the 1 second test.

  • Page 56: Disabling Traction

    The rest of this section explains how to temporarily disable traction control with each navigation method. To temporarily Disable Traction Control via menu navigation : Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).

  • Page 57: Running Special Test

    Some of these applications are also accessible via direct access buttons. When you initiate a special test with direct access buttons, Brake-Link™ en- ables test mode for the duration of the test. If you disconnect the Brake-Link™ before exiting the SPECIAL TESTS menu, the ECU remains in test mode (i.e., not in normal operating state).
  • Page 58 CUR REN T FA ULTS FAU LT HISTO R Y DAT A L IST T ES TS Brake-Link™ displays a list of tests; scroll to SPECIAL TESTS with the keys and press Then it displays the Special Test menu; use the keys to select EXHAUST MODULATORS and press If you’re connected to the tractor ECU, Brake-Link™...
  • Page 59 Using EC-17, EC-30 & EC-30T Diagnostic Options To exhaust the modulators via button navigation: Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).
  • Page 60 EXHAUST MODULATOR and press . Brake-Link™ configures the ECU for test mode; then, it exhausts the selected modulator and returns TEST IS COMPLETE; press Brake-Link™ returns the ECU to regular mode and returns you to the screen. Modulator Test Selection Press...
  • Page 61 Select Application screen. To hold the modulators via button navigation : Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).
  • Page 62 HOLD MODULTOR and press Brake-Link™ configures the ECU for test mode; then, it holds the selected modulator and returns TEST IS COMPLETE; press Brake-Link™ returns the ECU to regular mode and returns you to the screen. Modulator Test Selection...

  • Page 63: Warning Lamp

    FAU LT H IST ORY DAT A LI ST T ES TS Brake-Link™ displays a list of tests; scroll to SPECIAL TESTS with the keys and press Next, Brake-Link™ displays the Special Test menu; use the keys to select TEST WARNING LAMP and press If this is the first special test performed since you entered the Special menu, Brake-Link™...
  • Page 64 FAU LT HISTO R Y DAT A L IST T ES TS Brake-Link™ displays a list of tests; scroll to SPECIAL TESTS with the keys and press Next, Brake-Link™ displays the Special Test menu; use the keys to select TEST TRACTION LAMP and press If this is the first special test performed since you entered the Special menu, Brake-Link™...
  • Page 65 FAU LT H IST ORY DAT A LI ST T ES TS Brake-Link™ displays a list of tests; scroll to SPECIAL TESTS with the keys and press Next, Brake-Link™ displays the Special Test menu; use the keys to select TEST TR ABS WAR LAMP and press ®...
  • Page 66 TESTS and press CUR REN T FA ULTS FAU LT HISTO R Y DAT A L IST T ES TS Brake-Link™ displays a list of tests; scroll to SPECIAL TESTS with the keys and press ® ® 60 NEXIQ Brake-Link™ Bendix &...
  • Page 67 The rest of this section describes running this test with each navigation meth- To run a Load Battery Voltage Test via menu navigation : Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20).
  • Page 68 CUR REN T FA ULTS FAU LT HISTO R Y DAT A L IST T ES TS Brake-Link™ displays a list of tests; scroll to SPECIAL TESTS with the keys and press Then it displays the Special Test menu; use the keys...

  • Page 69: Ecu Information

    Brake-Link™ configures the ECU for test mode; then, it presents the battery voltage prior to exhausting the modulators and the lowest volt- age detected during the test; press Brake-Link™ returns the ECU to regular mode and returns you to the screen. Battery Test Selection...

  • Page 70: R Evis Ion Numb E R

    Select Application To view ECU Information via button navigation : Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).

  • Page 71: Reset Ecu

    The rest of this section describes resetting the ECU with each navigation meth- To reset ECU via menu navigation : Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).

  • Page 72: Configuration

    • Diagnosing EC-17, EC-30 & EC-30T ABS Chapter Brake-Link™ displays a countdown while it resets the ECU; then it returns to the EC-17/30/30T Diagnostic Options menu. Press to return to the screen. Select Application To reset ECU via button navigation : Connect Brake-Link™...
  • Page 73 SELF CONFIG and press Brake-Link™ prompts you for confirmation; use the keys to select YES and press Brake-Link™ displays a countdown while it configures the ECU; then it returns to the Configuration Option menu. Press to return to the Bendix ABS Application main menu or ®...

  • Page 74: Modifying System Configuration

    The rest of this section describes configuring the ECU with each navigation method. To configure individual ECU parameters via menu navigation : Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).
  • Page 75 Brake-Link™ prompts you for confirmation; use the and keys to select YES and press Brake-Link™ displays a countdown while it configures the ECU; then it reports the success of the configuration; press to return to the menu.
  • Page 76 When you’re done editing parameters, press Brake-Link™ prompts you for confirmation; use the keys to select YES and press Brake-Link™ displays a countdown while it configures the ECU; then it reports the success of the configuration; press to return to the menu.

  • Page 77: Diagnosing Gen 4 & 5 Abs

    ® continue to provide fleet and dealer sales and service support for the Bendix ® Knorr-Bremse ABS product line. For more information, call 1-800-AIR-BRAKE (1-800-247-2725) or visit www.bendix.com. ® ® NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...

  • Page 78: Using The Gen 4 & 5 Diagnostic Options

    • Software Number • Part Number • System Configuration • Manufacture Date • Diagnostic Version • Serial Number The rest of this section describes retrieving ECU information with each naviga- tion method. ® ® 72 NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...
  • Page 79 Using the Gen 4 & 5 Diagnostic Options To view ECU Information via menu navigation : Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).

  • Page 80: Faults

    Gen 4 and Gen 5 controllers report fault code information differently. Generation 4 controllers store all detected fault codes and report them one code at a time. Brake-Link™ offers an option for viewing the stored fault and clearing faults from the ECU.

  • Page 81: Viewing Existing Faults

    This option is only available for Gen 5 controllers. Note: To view existing fault codes via menu navigation : Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).
  • Page 82 — Line 4 shows the FMI value in decimal and hexadecimal, and an oc- currence count. If the ECU doesn’t support occurrence count report- ing, Brake-Link™ displays N/A . If there is more than one code, a down arrow appears next to the occurrence count; scroll the display with the keys.

  • Page 83: Viewing Stored Faults

    — Line 4 shows the FMI value in decimal and hexadecimal, and an oc- currence count. If the ECU doesn’t support occurrence count report- ing, Brake-Link™ displays N/A . If there is more than one code, a down arrow appears next to the occurrence count; scroll the display with the keys.
  • Page 84 • Diagnosing Gen 4 & 5 ABS Chapter Register the ECU (see “Register ECU via menu navigation:”, on page 28). Brake-Link™ presents the Gen 4/5 Diagnostic Options menu; use the keys to scroll to FAULTS and press ECU IN FORM ATIO N F AU LTS...
  • Page 85 Using the Gen 4 & 5 Diagnostic Options To view stored fault codes via button navigation: Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).

  • Page 86: Clearing Faults

    The rest of this section explains how to clear faults with each method of navi- gation. To clear fault codes via menu navigation : Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).
  • Page 87 Using the Gen 4 & 5 Diagnostic Options If there: — are no problems in the ABS, Brake-Link™ confirms that the faults have been cleared; press to return to the Faults Menu . — is a problem in the ABS, Brake-Link™ displays the following screen.
  • Page 88 • Diagnosing Gen 4 & 5 ABS Chapter If there: — are no problems in the ABS, Brake-Link™ confirms that the faults have been cleared; press to return to the CONTINUE BY PRESSING BUTTONS prompt. — is a problem in the ABS, Brake-Link™ displays the following screen.

  • Page 89: Data List

    The rest of this section explains how to view the data list with each method of navigation. To access the Data List via menu navigation: Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).
  • Page 90 Select Application screen. To access the Data List via button navigation: Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).

  • Page 91: Tests

    The vehicle must be stationary in order to perform this test. Note: To test selected modulator valve via menu navigation : Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).

  • Page 92: Testing Warning Lamp

    Note: wheel speeds to verify that speeds are less than 5 kph. If wheel speeds are not less than 5 kph, the Brake-Link™ displays a mes- sage indicating that the test cannot be performed. To test Trailer ABS Warning Lamp via menu navigation : Connect Brake-Link™...

  • Page 93: Self-Configuration

    If wheel speeds are greater than 5 kph, Brake-Link™ dis- Note: plays a message indicating that the test cannot be performed. Brake-Link™ blinks the lamp 4 times; while performing the test, it dis- plays the following message. A CTIV ATI NG WA RNIN G L AMP O N A ND O FF..
  • Page 94 • Diagnosing Gen 4 & 5 ABS Chapter To run self-configuration via menu navigation: Connect Brake-Link™ to the tractor or trailer and power-up (see “Con- necting Brake-Link™ Components”, on page 20). Register the ECU (see “Register ECU via menu navigation:”, on page 28).

  • Page 95: Ec-30T Sid/Fmi Tables

    Failure Mode ID (FMI) descriptions, as defined by Bendix , may be longer than 20 characters; since the Brake-Link™ LCD is 20 characters wide, it may display a short- ened version of the description. This appendix provides a SID (Sub-system ID)/FMI table for each supported ECU.

  • Page 96: Ec-17 Sids & Fmis

    Off Failure Right Front Modula- Open Left Rear Modulator Shorted Right Rear Modula- Lock Time Out ASIC Shorted or Open Solenoid Shorted Traction SIDs Description FMIs Description Traction Modulator Open Shorted ® ® 90 NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...
  • Page 97 Battery Voltage SIDs Description FMIs Description Battery Voltage High SIDs Description FMIs Description Intermittent Watchdog ASIC Analog Feedback NVRAM CSUM Failure Stack Overrun Watchdog Failure SSIO Communication Lost Invalid NVRAM Data ® ® NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...

  • Page 98: Sids & Fmis

    Connection has corrosion; sen- sor loose in block, output noisy. Sensor or exciter ring needs adjustment, output intermit- tent, wobble run in exciter ring Abnormal speed Invalid tire size; gross mis- match ® ® 92 NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...
  • Page 99 FMIs Description Traction Modula- Shorted to VBAT Open Shorted to ground Shorted Lamps SIDs Description FMIs Description ABS Warning Open Lamp Traction Lamp Shorted Trailer ABS Warn- ing Lamp (Dash mounted) ® ® NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...
  • Page 100 Battery Voltage High SIDs Description FMIs Description ECU Fault ECU Fault ECU Fault ECU Fault ECU Fault ECU Fault ECU Fault ECU Fault ECU Fault ECU Fault ECU Fault ECU Fault ® ® 94 NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...

  • Page 101: Ec-30T Sids & Fmis

    Invalid tire size; gross mis- match Modulators SIDs Description FMIs Description Modulator 2 Open Modulator 1 Shorted to ground Not responding; sensor out of adjustment or modulator issue Shorted between Solenoid shorted ® ® NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...
  • Page 102 SIDs Description FMIs Description Battery Voltage High SIDs Description FMIs Description ECU Fault ECU Fault ECU Fault ECU Fault ECU Fault ECU Fault ECU Fault ECU Fault ECU Fault ECU Fault ® ® 96 NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...

  • Page 103: Gen 4 & 5 Fault Code Tables

    Gen 4 & 5 Fault Code Tables Generation 4, page 98 Generation 5, page 100 his appendix provides a list of all supported Generation 4 & 5 Trailer ABS Fault Codes. ® ® NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...

  • Page 104: Generation 4

    SPEED SENSOR C: excessive wheel lock SPEED SENSOR C: C - 4 air gap too large SPEED SENSOR C: air gap too large SPEED SENSOR C: C - 4 high decel/shorted ® ® 98 NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...
  • Page 105 VALVE A/B: C - 11 short to low POWER SUPPLY: C - 12 low voltage CONTROLLER: C - 14 defective CONTROLLER: C - 14 defective CONTROLLER: C - 14 defective ® ® NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...

  • Page 106: Generation 5

    1 - 1 SPEED SENSOR A: 2 - 1 air gap too large SPEED SENSOR A: air gap too large SPEED SENSOR A: 2 - 3 noisy signal, tone r ® ® 100 NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...
  • Page 107 SPEED SENSOR C: 4 - 5 high decel/shorted SPEED SENSOR C: short hi/low or open SPEED SENSOR D: 5 - 1 air gap too large SPEED SENSOR D: air gap too large ® ® NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...
  • Page 108 VALVE B: rel sol shorted low VALVE B: 9 - 3 rel sol open ckt VALVE B: valve cmn open ckt VALVE B: 9 - 5 hld sol shorted high ® ® 102 NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...
  • Page 109 VALVE D: 11 - 4 valve cmn open ckt VALVE D: 11 - 5 hld sol shorted high VALVE D: 11 - 6 hld sol shorted low ® ® NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...
  • Page 110 15 - 7 defective 15 - 9 invalid config 15 - 10 defective 15 - 11 defective VOLTAGE 16 - 1 over voltage 24h/25h VOLATGE 16 - 2 low voltage ® ® 104 NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...
  • Page 111 17 - 5 whl dia mismatch WL SHORTED HIGH OR 17 - 10 SAE A short to ground SENSOR MEMORY CHECK 17 - 12 drive vehicle SENSORS LEFT/RIGHT 17 - 13 mismatched ® ® NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...
  • Page 112 • Gen 4 & 5 Fault Code Tables Appendix ® ® 106 NEXIQ Brake-Link™ Bendix & Eaton ABS Applications...
