PARTS LIST & INSTRUCTION
Industrial Sewing Machines
2022 年 3 月 第 18 版 発行
18th edition: March 2022
No. 220029

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DLR Series and is the answer not in the manual?

Questions and answers

Summary of Contents for kansai DLR Series

  • Page 1 PARTS LIST & INSTRUCTION Industrial Sewing Machines 2022 年 3 月 第 18 版 発行 18th edition: March 2022 No. 220029...
  • Page 2 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 3: Introduction

    From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 4 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 5 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 6 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 7 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 8 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 9 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 10 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 11 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 12 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 13 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 14: Presser Foo T Mech A N I Sm

    From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 15: Lubrication Mechanism

    From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 16 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 17 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 18 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 19 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 20 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 21 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 22 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 23 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 24 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 25 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 26 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 27 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 28 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 29 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 30 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 31 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 32: Gauge Parts

    From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 33 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 34 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 35 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 36 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 37 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 38 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 39 From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 40 INDEX 1 REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. 品  番 品...
  • Page 41 INDEX 2 REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. MEMO 品  番 品  番 品  番 品  番 品  番 品  番 品  番 品...
  • Page 42 series Instruction Manual From the library of Merrow Superior - www.supsew.com • www.merrow.com...
  • Page 43: Table Of Contents

    CONTENTS INTRODUCTION 1. SPECIFICATIONS 10. ADJUSTING THE REAR PULLER DEVICE Thank you for your purchasing Kansai Special's DLR series. 1-1 Stitch type ················································ 1 10-1 Manual lever ········································· 12 1-2 Model ······················································ 1 10-2 To adjust the puller pressure ··················· 12...
  • Page 44: Specifications

    【1】SPECIFICATIONS 2-3 To thread the machine Thread the machine correctly by referring to the next page. 1-1 Stitch type Incorrect threading may cause skip stitching, thread breakage and/or uneven stitch JIS401 double chainstitch machines formation. When threading the looper, tilt the looper holder toward the front of the machine by means of the looper drawing bar.
  • Page 45: Machine Speed

    【3】MACHINE SPEED ■A,B,C,D : Needle threads E,F,G,H : Looper threads 3-1 Machine speed & direction in which the machine pulley runs Maximum speed : 4,500 rpm Standard speed : 4,000 rpm extend machine life, machine approximately 15-20% below the maximum speed for the first 200 hours of operation (approx.
  • Page 47: To Install The Machine

    6-2 Looper left-to-right movement 5-2 To install the machine When the point of the looper, moving to the left or Install the brackets on the underside of the table board (see the illustration below). right, has reached the center of the needle, the point Fit the rubber cushions onto the brackets.
  • Page 48: Needle Height

    6-4 Needle height 6-6 Length of the looper connecting bar When the point of the looper has reached the center On 1501 to 1504, the distance between the centers of of the back side of the needle with the machine both connecting rods should be 100mm.
  • Page 49: Adjusting The Feed Dog & Stitch Length

    【8】ADJUSTING THE FEED DOG & STITCH LENGTH 【9】ADJUSTING THE PRESSER FOOT 8-1 Feed dog height & tilt 9-1 Presser foot pressure When the feed dog is at the top of its stroke, the feed dog The presser foot pressure should be as light as possible, teeth should be 1.0~1.2mm above the top surface of the yet be sufficient to feed the fabric and produce uniform needle plate.
  • Page 50: Adjusting The Feeding Amount Of The Rear Puller

    10-3 Adjusting the feeding amount of the rear puller 10-6 Guide plate adjustment (Model SPF) The feeding amount of the rear puller should be the same as that of the feed dog. Adjust guide plate M & T according to the width of Loosen nut A to decrease the amount, move waist band.
  • Page 51: Position Of The Needle Thread Eyelet

    11-2 Position of the needle thread eyelet 11-5 Position of the looper thread take-up Secure needle thread eyelet C at the bottom end of Adjust thread guide E so that the clearance the slot. between thread guide E and the top surface of the guide plate is 6~7mm.
  • Page 52 HOUSE-09, FLAT-1/A & 1/B, ROAD-04, SECTOR-03, UTTARA, DHAKA-1230 BANGLADESH TEL: +88-02-8931702 FAX: +88-02-8931704 E-MAIL: salesbangladesh@kansaispecial.com.sg KANSAI (SHANG HAI) INDUSTRIAL SEWING MACHINE CO., LTD NO.55 LANE835, JIAXIN ROAD, MALU TOWN, JIADING DISTRICT, SHANGHAI 201818, CHINA TEL: +86-21-5990-1798 FAX: +86-21-5990-1538 E-MAIL: kansaish@spe.sina.net...
