Aurora Design SCRF-343X Quick Start Manual

Aurora Design SCRF-343X Standards Converter
525/30i (NTSC) to 343/30i with System X1 modulator.
(Positive video, AM audio, audio carrier level -6db)
Selector Channel
Position Assignment
0 Disabled
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
A 10
B 11
C 12
D 13
E 14
F 15
S elector Position Option Function
0 Converter Enable/Bypass Mode
1 Sleep Mode
2 Default Audio Tone
3 Equalization Pulses
Momentarily press Aux button to toggle between stored default images.
Note: To change an Option Setting, depress the Option Button for 1
second to enter the Option Setting Mode. Turn the Selector Switch to the
desired position. The Status LED will blink Green for enabled, Red for
disabled, and Yellow for not supported. Momentarily press the Option
Button to toggle the setting. When finished, depress the Option Button for
1 second to exit the Option Setting Mode. Note: the Option Setting Mode
will automatically exit if no changes are made for 1 minute.
www.tech-retro.com v4.0
Video Audio
Frequency Frequency
44.75 MHz 47.00 MHz
49.75 MHz 52.00 MHz
54.75 MHz 57.00 MHz
62.75 MHz 65.00 MHz
67.75 MHz 70.00 MHz
72.75 MHz 75.00 MHz
77.75 MHz 80.00 MHz
82.75 MHz 85.00 MHz
112.75 MHz 115.00 MHz
117.75 MHz 120.00 MHz
122.75 MHz 125.00 MHz
127.75 MHz 130.00 MHz
132.75 MHz 135.00 MHz
137.75 MHz 140.00 MHz
142.75 MHz 145.00 MHz
Aurora Design SCRF-343X Standards Converter
525/30i (NTSC) to 343/30i with System X1 modulator.
(Positive video, AM audio, audio carrier level -6db)
Selector Channel
Position Assignment
0 Disabled
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
A 10
B 11
C 12
D 13
E 14
F 15
S elector Position Option Function
0 Converter Enable/Bypass Mode
1 Sleep Mode
2 Default Audio Tone
3 Equalization Pulses
Momentarily press Aux button to toggle between stored default images.
Note: To change an Option Setting, depress the Option Button for 1
second to enter the Option Setting Mode. Turn the Selector Switch to the
desired position. The Status LED will blink Green for enabled, Red for
disabled, and Yellow for not supported. Momentarily press the Option
Button to toggle the setting. When finished, depress the Option Button for
1 second to exit the Option Setting Mode. Note: the Option Setting Mode
will automatically exit if no changes are made for 1 minute.
www.tech-retro.com v4.0
Video Audio
Frequency Frequency
44.75 MHz 47.00 MHz
49.75 MHz 52.00 MHz
54.75 MHz 57.00 MHz
62.75 MHz 65.00 MHz
67.75 MHz 70.00 MHz
72.75 MHz 75.00 MHz
77.75 MHz 80.00 MHz
82.75 MHz 85.00 MHz
112.75 MHz 115.00 MHz
117.75 MHz 120.00 MHz
122.75 MHz 125.00 MHz
127.75 MHz 130.00 MHz
132.75 MHz 135.00 MHz
137.75 MHz 140.00 MHz
142.75 MHz 145.00 MHz
