Aurora Design SCRF-343A Quick Start Manual

Aurora Design SCRF-343A Standards Converter
525/30i (NTSC) to 343/30i with System A modulator.
(Positive video, AM audio, audio carrier level -6db)
Selector Channel
Position Assignment
0 Disabled
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
A 10
B 11
C 12
D 13
E 14
F Disabled
S elector Position Option Function
0 Converter Enable/Bypass Mode
1 Sleep Mode
2 Default Audio Tone
3 Equalization Pulses
Momentarily press Aux button to toggle between stored default images.
Note: To change an Option Setting, depress the Option Button for 1
second to enter the Option Setting Mode. Turn the Selector Switch to the
desired position. The Status LED will blink Green for enabled, Red for
disabled, and Yellow for not supported. Momentarily press the Option
Button to toggle the setting. When finished, depress the Option Button for
1 second to exit the Option Setting Mode. Note: the Option Setting Mode
will automatically exit if no changes are made for 1 minute.
www.tech-retro.com v4.0
Video Audio
Frequency Frequency
45.00 MHz 41.50 MHz
51.75 MHz 48.25 MHz
56.75 MHz 53.25 MHz
61.75 MHz 58.25 MHz
66.75 MHz 63.25 MHz
179.75 MHz 176.25 MHz
184.75 MHz 181.25 MHz
189.75 MHz 186.25 MHz
194.75 MHz 191.25 MHz
199.75 MHz 196.25 MHz
204.75 MHz 201.25 MHz
209.75 MHz 206.25 MHz
214.75 MHz 211.25 MHz
219.75 MHz 216.25 MHz
Aurora Design SCRF-343A Standards Converter
525/30i (NTSC) to 343/30i with System A modulator.
(Positive video, AM audio, audio carrier level -6db)
Selector Channel
Position Assignment
0 Disabled
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
A 10
B 11
C 12
D 13
E 14
F Disabled
S elector Position Option Function
0 Converter Enable/Bypass Mode
1 Sleep Mode
2 Default Audio Tone
3 Equalization Pulses
Momentarily press Aux button to toggle between stored default images.
Note: To change an Option Setting, depress the Option Button for 1
second to enter the Option Setting Mode. Turn the Selector Switch to the
desired position. The Status LED will blink Green for enabled, Red for
disabled, and Yellow for not supported. Momentarily press the Option
Button to toggle the setting. When finished, depress the Option Button for
1 second to exit the Option Setting Mode. Note: the Option Setting Mode
will automatically exit if no changes are made for 1 minute.
www.tech-retro.com v4.0
Video Audio
Frequency Frequency
45.00 MHz 41.50 MHz
51.75 MHz 48.25 MHz
56.75 MHz 53.25 MHz
61.75 MHz 58.25 MHz
66.75 MHz 63.25 MHz
179.75 MHz 176.25 MHz
184.75 MHz 181.25 MHz
189.75 MHz 186.25 MHz
194.75 MHz 191.25 MHz
199.75 MHz 196.25 MHz
204.75 MHz 201.25 MHz
209.75 MHz 206.25 MHz
214.75 MHz 211.25 MHz
219.75 MHz 216.25 MHz
