Aurora Design SCRF-441M Quick Start Manual

Aurora Design SCRF-441M Standards Converter
525/30i (NTSC) to 441/30i with System M modulator.
(Positive video, AM audio, audio carrier level -6db)
Selector Channel
Position Assignment
0 Disabled
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
A 10
B 11
C 12
D 13
E 14
F 15
S elector Position Option Function
0 Converter Enable/Bypass Mode
1 Sleep Mode
2 Default Audio Tone
Momentarily press Aux button to toggle between stored default images.
Note: To change an Option Setting, depress the Option Button for 1
second to enter the Option Setting Mode. Turn the Selector Switch to the
desired position. The Status LED will blink Green for enabled, Red for
disabled, and Yellow for not supported. Momentarily press the Option
Button to toggle the setting. When finished, depress the Option Button for
1 second to exit the Option Setting Mode. Note: the Option Setting Mode
will automatically exit if no changes are made for 1 minute.
www.tech-retro.com v4.0
Video Audio
Frequency Frequency
45.25 MHz 49.75 MHz
55.25 MHz 59.75 MHz
61.25 MHz 65.75 MHz
67.25 MHz 71.75 MHz
77.25 MHz 81.75 MHz
83.25 MHz 87.75 MHz
175.25 MHz 179.75 MHz
181.25 MHz 185.75 MHz
187.25 MHz 191.75 MHz
193.25 MHz 197.75 MHz
199.25 MHz 203.75 MHz
205.25 MHz 209.75 MHz
211.25 MHz 215.75 MHz
471.25 MHz 475.75 MHz
477.25 MHz 481.75 MHz
Aurora Design SCRF-441M Standards Converter
525/30i (NTSC) to 441/30i with System M modulator.
(Positive video, AM audio, audio carrier level -6db)
Selector Channel
Position Assignment
0 Disabled
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
A 10
B 11
C 12
D 13
E 14
F 15
S elector Position Option Function
0 Converter Enable/Bypass Mode
1 Sleep Mode
2 Default Audio Tone
Momentarily press Aux button to toggle between stored default images.
Note: To change an Option Setting, depress the Option Button for 1
second to enter the Option Setting Mode. Turn the Selector Switch to the
desired position. The Status LED will blink Green for enabled, Red for
disabled, and Yellow for not supported. Momentarily press the Option
Button to toggle the setting. When finished, depress the Option Button for
1 second to exit the Option Setting Mode. Note: the Option Setting Mode
will automatically exit if no changes are made for 1 minute.
www.tech-retro.com v4.0
Video Audio
Frequency Frequency
45.25 MHz 49.75 MHz
55.25 MHz 59.75 MHz
61.25 MHz 65.75 MHz
67.25 MHz 71.75 MHz
77.25 MHz 81.75 MHz
83.25 MHz 87.75 MHz
175.25 MHz 179.75 MHz
181.25 MHz 185.75 MHz
187.25 MHz 191.75 MHz
193.25 MHz 197.75 MHz
199.25 MHz 203.75 MHz
205.25 MHz 209.75 MHz
211.25 MHz 215.75 MHz
471.25 MHz 475.75 MHz
477.25 MHz 481.75 MHz
