Aurora Design SCRF-819F Quick Start Manual

Aurora Design SCRF-819F Standards Converter
625/25i (PAL) to 819/25i (Belgian) with System F modulator.
(Positive video, AM audio, audio carrier level -6db)
Selector Channel
Position Assignment
0 Disabled
1 1
2 1A
3 2
4 2A
5 3
6 4
7 4A
8 5
9 6
A 7
B 8
C 9
D 10
E 11
F 12
S elector Position Option Function
0 Converter Enable/Bypass Mode
1 Sleep Mode
2 Default Audio Tone
Momentarily press Aux button to toggle between stored default images.
Note: To change an Option Setting, depress the Option Button for 1
second to enter the Option Setting Mode. Turn the Selector Switch to the
desired position. The Status LED will blink Green for enabled, Red for
disabled, and Yellow for not supported. Momentarily press the Option
Button to toggle the setting. When finished, depress the Option Button for
1 second to exit the Option Setting Mode. Note: the Option Setting Mode
will automatically exit if no changes are made for 1 minute.
www.tech-retro.com v4.0
Video Audio
Frequency Frequency
41.25 MHz 46.75 MHz
42.25 MHz 47.75 MHz
48.25 MHz 53.75 MHz
49.75 MHz 55.25 MHz
55.25 MHz 60.75 MHz
62.25 MHz 67.75 MHz
82.25 MHz 87.75 MHz
175.25 MHz 180.75 MHz
182.25 MHz 187.75 MHz
189.25 MHz 194.75 MHz
196.25 MHz 201.75 MHz
203.25 MHz 208.75 MHz
210.25 MHz 215.75 MHz
217.25 MHz 222.75 MHz
224.25 MHz 229.75 MHz
Aurora Design SCRF-819F Standards Converter
625/25i (PAL) to 819/25i (Belgian) with System F modulator.
(Positive video, AM audio, audio carrier level -6db)
Selector Channel
Position Assignment
0 Disabled
1 1
2 1A
3 2
4 2A
5 3
6 4
7 4A
8 5
9 6
A 7
B 8
C 9
D 10
E 11
F 12
S elector Position Option Function
0 Converter Enable/Bypass Mode
1 Sleep Mode
2 Default Audio Tone
Momentarily press Aux button to toggle between stored default images.
Note: To change an Option Setting, depress the Option Button for 1
second to enter the Option Setting Mode. Turn the Selector Switch to the
desired position. The Status LED will blink Green for enabled, Red for
disabled, and Yellow for not supported. Momentarily press the Option
Button to toggle the setting. When finished, depress the Option Button for
1 second to exit the Option Setting Mode. Note: the Option Setting Mode
will automatically exit if no changes are made for 1 minute.
www.tech-retro.com v4.0
Video Audio
Frequency Frequency
41.25 MHz 46.75 MHz
42.25 MHz 47.75 MHz
48.25 MHz 53.75 MHz
49.75 MHz 55.25 MHz
55.25 MHz 60.75 MHz
62.25 MHz 67.75 MHz
82.25 MHz 87.75 MHz
175.25 MHz 180.75 MHz
182.25 MHz 187.75 MHz
189.25 MHz 194.75 MHz
196.25 MHz 201.75 MHz
203.25 MHz 208.75 MHz
210.25 MHz 215.75 MHz
217.25 MHz 222.75 MHz
224.25 MHz 229.75 MHz
