- Page 1 KSOZ002 AS S EMBLY IN STR UC TIO N WWW.K-SPORT-DE.DE...
- Page 2 KSOZ002 1 x 3 2 x 2 3 x 2 800 mm 1100 mm 1000 mm 6 x 2 4 x 2 5 x 1 1500 mm 300 mm 250 mm 8 x 40 9 x 12 7 x 1...
- Page 3 KSOZ002 17mm...
- Page 4 KSOZ002 8 11...
- Page 5 KSOZ002 After the assembly of the upper part of the de- vice, measure the distance between the profiles or place the construction on the ground and dig the hole (at least 60 cm deep). The anchors ( part number 1) should be placed vertically in the gro-und with the help of the spirit level, so its upper edge is 20 cm above the ground level.
- Page 6 KSOZ002 To prevent movement of the clamp, place a piece of a rubber be- tween the rod and the clamp.
- Page 7 17. If the assembly of the device is not possible because of the technical errors (missing or missplaced holes, uneven parts), contact us on the given e-mail adress: info@k-sport-de.de . In the message include photos of defected parts.
