Summary of Contents for Rinstrum D730

  • Page 1 D730 Remote Display Installation Manual...
  • Page 2 Rinstrum Pty Ltd. Disclaimer Rinstrum Pty Ltd reserves the right to make changes to the products contained in this manual in order to improve design, performance or reliability. The information in this manual is believed to be accurate in all respects at the time of publication, but is subject to change without notice.
  • Page 3: Table Of Contents

    D730 Installation Manual Rev 1.01 Table of Contents SPECIFICATIONS ...................... 2 INSTALLATION ......................4 2.1. Introduction ....................... 4 2.2. Important......................4 2.3. Power Connection .................... 5 2.4. Communication connections ................5 2.4.1. Earthing Requirements for Cable Shields .......... 5 2.4.2.
  • Page 4: Specifications

    D730 Installation Manual Rev 1.01 Specifications Display Display D730 – Six (6) LED digits with decimal points for displaying numeric, semi-alpha characters at 120 degrees viewing angle. • Character size (H x W) – 75mmx40mm (3"x1.6") • 28 LEDs per digit •...
  • Page 5 Zero the D730 will also display the trailing zero. Example: With the count set to 20, an indicator displays 00 at zero load. The D730 will also show 00 at zero as there is no leading zero blanking.
  • Page 6: Installation

    2.1. Introduction The D730 is a 7 segment super bright LED remote with 75mm (3") high digits and traffic lights. The D730 remote display is capable of interpreting and displaying formatted weight transmissions from digital weight indicators. Additionally it can be used to display semi-alpha text.
  • Page 7: Power Connection

    D730 Installation Manual Rev 1.01 2.3. Power Connection Use an AC power source of 110-240VAC. The Protective Earth pin 4 MUST be connected to AC mains earth for both safety and EMC regulation compliance. Note: The power connection should be performed in accordance with local regulations.
  • Page 8: Mounting Options

    D730 Installation Manual Rev 1.01 ♦ RS-232 Receive Only RS232 is not recommended for long cable runs or electrically noisy environments. Recommended maximum cable distance for RS232 is 15m. Figure 5 - RS232 Socket connection ♦ RS-485 Receive Only RS485 is the preferred serial connection for long cable runs. Multi-dropping is supported.
  • Page 9: Weather Hood (Optional)

    D730 Installation Manual Rev 1.01 2.5.2. Weather Hood (Optional) The optional weather hood can be used to minimise effects of direct sunlight. The Weather Hood mounting holes line up with the wall mounting holes on the brackets for easy fitment.
  • Page 10: Error Messages

    D730 Installation Manual Rev 1.01 Error Messages Error Description --U-- Underweight - the weight is below the minimum allowable weight reading. Check indicator --O-- Overweight - The weight is above the maximum allowable weight reading. Check indicator --E-- Error - The indicator is reporting an error. Check indicator --//-- No valid data from indicator and unit has timed out.
  • Page 11: Appendix A : Supported Protocols

    D730 Installation Manual Rev 1.01 Appendix A : Supported Protocols On power up the display will attempt to automatically detect one of the following protocols. Note that compatibility is not guaranteed and manufacturers may change their protocol at any time without notice.
