- Page 1 S M A R T W E I G H IN G S O L U T I O N S D732 Remote Displays Installation Manual D730-600 Rev 1.5.0...
- Page 2 Rinstrum Pty Ltd. Disclaimer Rinstrum Pty Ltd reserves the right to make changes to the products contained in this manual in order to improve design, performance or reliability. The information in this manual is believed to be accurate in all respects at the time of publication, but is subject to change without notice.
-
Page 3: Table Of Contents
4 Communication connections Earthing Requirements for Cable Shields ............. 6 Serial Connection ..................6 5 Setup Command Rinstrum Remote Display Configurator ............9 6 Mounting Options Wall Mounting .................... 11 Weather Hood (Optional) ................11 Optional Mounting Plate ................11... -
Page 4: Specifications
Installation Manual Rev 1.5.0 1. SPECIFICATIONS Display Display D732 – Six (6) LED digits with decimal points for displaying numeric, semi- alpha characters at 120 degrees viewing angle. · Character size (H x W) – 75mmx40mm (3"x1.6") · 28 LEDs per digit ·... - Page 5 D732 will also display the trailing zero. Example: With the count set to 20, an indicator displays 00 at zero load. The D732 will also show 00 at zero as there is no leading zero blanking. NTEP is the National Type Evaluation Program in the US.
-
Page 6: Installation
2. INSTALLATION 2.1 Introduction The D732 is a 7 segment super bright LED remote with 75mm (3") high digits and traffic lights. The D732 remote display is capable of interpreting and displaying formatted weight transmissions from digital weight indicators. Additionally it can be used to display semi-alpha text. The D732 can display up to 6 semi-alpha/numeric digits in 7 segment format. - Page 7 Installation Manual Rev 1.5.0 connector. Make sure the environment is dry when terminating to prevent moisture ingress into sealed connectors. Disconnect power before opening cable connector D730-600 Rev 1.5.0 Enter the help project title here © 2024 Enter your company name...
-
Page 8: Power Connection
Installation Manual Rev 1.5.0 3. POWER CONNECTION 3.1 AC Variant Use an AC power source of 110-240VAC. The Protective Earth pin 4 MUST be connected to AC mains earth for both safety and EMC regulation compliance. Note: The power connection should be performed in accordance with local regulations. Use a power cable of min 0.75mm2 (AWG 20) to max 2.5mm2... -
Page 9: Communication Connections
Installation Manual Rev 1.5.0 4. COMMUNICATION CONNECTIONS 4.1 Earthing Requirements for Cable Shields Cable shields should ideally be connected to earth at one end for the communications option below. As there is no provision for the shield connection at the communications connection end of the display, it is recommended the shield be terminated at the indicator (source) end. - Page 10 Installation Manual Rev 1.5.0 Recommended maximum cable distance for RS232 is 15m. Figure 6: RS232 Socket connection 4.2.2 RS-485 Receive Only RS485 is the preferred serial connection for long cable runs. Multi-dropping is supported. A 120 resister is provided for termination. Recommended maximum cable distance for...
-
Page 11: Setup Command
Installation Manual Rev 1.5.0 5. SETUP COMMAND The display will auto-detect the Protocol on start-up when the string is being streamed to it. The display will try and display all data received when in a locked state even if the protocol does not match. -
Page 12: Rinstrum Remote Display Configurator
The Configuration String can be streamed from a PC running terminal software such as "RealTerm", Android App "Slick USB" or similar. Alternatively you can use the custom string format in the Rinstrum R400 series indicators to send the string (this method cannot currently be used for displays with Ethernet option). - Page 13 Installation Manual Rev 1.5.0 · Determine what settings need to be changed as based on the Configuration String. Set the suitable options in the software or create your custom one with the connected R400. · Send the Configuration String out to the display until Proto 40 then –OK— is shown, (at least 6 times at 1 sec intervals best).
-
Page 14: Mounting Options
Installation Manual Rev 1.5.0 6. MOUNTING OPTIONS Two stainless steel mounting brackets are used to mount the unit on a flat surface. These brackets are bolted to rear of the housing using the shake-proof nuts provided. The outer mounting holes are 8mm in diameter. - Page 15 Installation Manual Rev 1.5.0 Figure 10: Optional Mounting Plate Figure 11: VESA, RAM and Pole mounting examples D730-600 Rev 1.5.0 Enter the help project title here © 2024 Enter your company name...
-
Page 16: Error Messages
Installation Manual Rev 1.5.0 7. ERROR MESSAGES Error Description --U-- Underweight - the weight is below the minimum allowable weight reading. Check source device. --O-- Overweight - The weight is above the maximum allowable weight reading. Check source device. --E-- Error - The source device is reporting an error in it status as detected in the protocol. -
Page 17: Appendix A : Supported Protocols
Serial Traffic NTEP Protocol commonly used by indicators light support multi from: zero support Ranger A Rinstrum, GSE, HBM & PT Ranger C Rinstrum GSE, HBM & PT Ranger D Rinstrum PCMODE Custom software Condec UMC, GSE, Rice Lake, Cardinal, Fairbanks, Eaton, Transcell Refer Remote Display Protocol Manual for detailed protocol descriptions. -
Page 18: Appendix B: Ascii Codes
Installation Manual Rev 1.5.0 9. APPENDIX B: ASCII CODES Code Char Code Char Code Char Code Char Code Char 000 (*) NULL ‘4’ ‘N’ ‘h’ (0x1A) (0x34) (0x4E) (0x68) ‘5’ ‘O’ ‘I’ (0x01) (0x1B) (0x35) (0x4F) (0x69) ‘6’ ‘P’ ‘j’ (0x02) (0x1C) (0x36) - Page 19 Installation Manual Rev 1.5.0 ‘,’ ‘F’ ‘`’ ‘z’ (0x12) (0x2C) (0x46) (0x60) (0x7A) ‘-‘ ‘G’ ‘a’ ‘{‘ (0x13) (0x2D) (0x47) (0x61) (0x7B) ‘.’ ‘H’ ‘b’ ‘|’ (0x14) (0x2E) (0x48) (0x62) (0x7C) ‘/’ ‘I’ ‘c’ ‘}’ (0x15) (0x2F) (0x49) (0x63) (0x7D) ‘0’...
